If PIN verification fails after a maximum number of attempts, the SIM/UIM card is locked, and a PIN
Unlocking Key (PUK) is required to unlock the card. The maximum number of attempts depends on
the 3G/4G modem model.
To configure PIN verification:
Step
1. Enter system view.
2. Enter cellular interface view.
3. Enable PIN verification.
4. Specify
verification.
5. (Optional.) Specify a PUK to
unlock the SIM/UIM card.
6. (Optional.) Modify the PIN of
the SIM/UIM card.

Configuring DM

Diagnostic and monitoring (DM) allows third-party debugging tools to diagnose and monitor the
3G/4G modem through cellular interface debugging output. For more information about DM, see
related 3G/4G modem user manuals.
DM is supported on SIC-4G modems, and EM770, EM660, and EM770W 3G modems.
To enable DM:
Step
1. Enter system view.
2. Enter cellular interface view.
3. Enable DM.

Setting RSSI thresholds for a 3G/4G modem

Perform this task to monitor signal strength changes of a 3G/4G modem.
To set RSSI thresholds for a 3G/4G modem:
Command
system-view
controller
interface-number
pin verification enable [ pin ]
the PIN for
pin verify { cipher | simple }
string
pin unlock puk new-pin
pin modify current-pin new-pin
Command
system-view
controller
interface-number
dm-port open
cellular
cellular
159
Remarks
N/A
N/A
The default setting depends on
the modem model.
Requirement for the current PIN
varies by device model.
By default, no PIN is configured
on a device for 3G/4G modem
verification.
This command saves the PIN on
the device.
After the SIM/UIM
unlocked, execute the pin verify
command to save the new PIN on
the device.
The new PIN is saved in the
SIM/UIM card.
After the PIN is modified, execute
the pin verify command to save
the new PIN on the device.
Remarks
N/A
N/A
The default setting depends on
the modem model.
card is
