HPE FlexNetwork MSR series Configuration Manual page 43

Protocol: (s) - spoofing
Interface
S2/1/0
The output shows that Serial 2/1/0 has obtained IP address 200.1.1.10 through PPP
negotiation.
# Verify that Router B can ping Serial 2/1/0 of Router A.
[RouterB-Serial2/0] ping 200.1.1.1
Ping 200.1.1.1 (200.1.1.1): 56 data bytes, press CTRL_C to break
56 bytes from 200.1.1.1: icmp_seq=0 ttl=128 time=3.197 ms
56 bytes from 200.1.1.1: icmp_seq=1 ttl=128 time=2.594 ms
56 bytes from 200.1.1.1: icmp_seq=2 ttl=128 time=2.739 ms
56 bytes from 200.1.1.1: icmp_seq=3 ttl=128 time=1.738 ms
56 bytes from 200.1.1.1: icmp_seq=4 ttl=128 time=1.744 ms
--- Ping statistics for 200.1.1.1 ---
5 packet(s) transmitted, 5 packet(s) received, 0.0% packet loss
round-trip min/avg/max/std-dev = 1.738/2.402/3.197/0.576 ms
# Display PPP address pool aaa on Serial 2/1/0 of Router A.
[RouterA-Serial2/1/0] display ip pool aaa
Group name: AAA
Pool name
aaa
In use IP addresses:
IP address
200.1.1.10
The output shows that one IP address has been assigned.
Using the PPP address pool associated with an ISP domain
Network requirements
As shown in
associated with the ISP domain to Serial 2/1/0 of Router B through PPP negotiation.
Figure 8 Network diagram
Ser2/1/0
200.1.1.1/16
Router A
Configuration procedure
1. Configure Router A:
# Configure PPP address pool aaa that contains IP addresses 200.1.1.10 through 200.1.1.20
for the group AAA.
<RouterA> system-view
[RouterA] ip pool aaa 200.1.1.10 200.1.1.20 group AAA
# Configure a PPP address pool route.
[RouterA] ppp ip-pool route 200.1.1.1 24
# Create a local user for Router B.
[RouterA] local-user userb class network
# Set a password for the local user.
Link Protocol Main IP
UP UP
Start IP address
200.1.1.10
Interface
S2/1/0
Figure 8, configure Router A to allocate an IP address from the PPP address pool
200.1.1.10
End IP address
200.1.1.20
Ser2/1/0
Router B
34
Description
Free In use
10 1
