Configuring the Windows server
For Microsoft Windows users, the server must be Windows 2000 or later such as Windows XP. This
example uses Windows XP.
To create a dialup connection with callback capability enabled:
1. Right-click the My Network Places icon, and select the Properties option from the menu that
appears.
The Network and Dial-up Connections window appears.
2. Right-click the Make New Connection icon, and select the New Connection...option from the
menu that appears.
The Network Connection Wizard window appears.
3. Click Next.
The Network Connection Type dialog box appears.
4. Select Set up an advanced connection, and click Next.
5. Select the Accept incoming connections option, and click Next to set the devices for
incoming connections. Click Next.
The Incoming Virtual Private Network (VPN) Connection window appears.
6. Select the Allow virtual private connections option if the server is connected to the Internet
to provide Internet access requests for the client. Otherwise, select the Do not allow virtual
private connections. Then click Next.
The User Permissions window appears. Set the usernames and passwords for the clients
allowed to call back.
7. Click Add. In the New User dialog box that appears, add the username and password for the
PPP callback client and click OK.
An icon for the new user account appears in the box in the User Permissions window.
8. Select the new user and click Properties.
The properties setting dialog appears.
9. On the Callback tab, perform one of the following tasks:
Select the Do not allow callback option.

After the PPP authentication is passed in a call, this option prevents the callback server
from disconnecting the current connection and calling back. Instead, the server will maintain
the current connection and allow the client to access the LAN or the Internet.
Select the Allow the caller to set the callback number option.

After the PPP authentication is passed in a call, the server will disconnect and then call back
the client at the number configured in the ppp callback ntstring dial-number command.
This option is the same as the last option except that the charges are paid by the server end
instead of the client end.
Select the Always use the following callback number option to set a callback number.

10. Click Next.
The Networking Software window appears.
11. Set the networking components, and use the default settings for the network protocols. Click
Next.
12. Assign a name to your connection.
13. Click Finish to complete the creation.
