Task
Clear the protocol packet statistics for a PPPoE
session.

PPPoE configuration examples

PPPoE server configuration example

Network requirements
As shown in
the router performs local authentication and assigns IP addresses to the clients.
Figure 12 Network diagram
Host A
Host B
Configuration procedure
# Create a PPPoE user.
<Router> system-view
[Router] local-user user1 class network
[Router-luser-network-user1] password simple pass1
[Router-luser-network-user1] service-type ppp
[Router-luser-network-user1] quit
# Configure Virtual-Template 1 to use CHAP for authentication and use a PPP address pool for IP
address assignment.
[Router] interface virtual-template 1
[Router-Virtual-Template1] ppp authentication-mode chap domain system
[Router-Virtual-Template1] ppp chap user user1
[Router-Virtual-Template1] remote address pool 1
[Router-Virtual-Template1] ip address 1.1.1.1 255.0.0.0
[Router-Virtual-Template1] quit
# Configure a PPP address pool that contains nine assignable IP addresses.
[Router] ip pool 1 1.1.1.2 1.1.1.10
# Enable the PPPoE server on GigabitEthernet 1/0/1, and bind the interface to Virtual-Template 1.
[Router] interface gigabitethernet 1/0/1
[Router-GigabitEthernet1/0/1] pppoe-server bind virtual-template 1
[Router-GigabitEthernet1/0/1] quit
# Configure local authentication for the default ISP domain (system).
Figure 12, Host A and Host B run PPPoE client dialup software. The PPPoE server on
Router
GE1/0/1 Ser2/1/0
Command
reset pppoe-client
[ dial-bundle-number number ]
Internet
54
session packet
