To configure a dialer interface to place calls:
Step
1. Enter system view.
2. Create a dialer interface and
enter its view.
3. Enable bundle DDR on the
interface.
4. Specify a dial string.
5. Return to system view.
6. Enter physical interface view.
7. Assign the physical interface
to a dialer bundle.

Configuring a dialer interface to receive calls

To configure a dialer interface to receive calls, you only need to enable DDR on the interface. At the
receiving end, configure PAP or CHAP authentication (see "Configuring PPP and MP") on the
physical interface and the dialer peer-name command on the dialer interface.
To configure an interface to receive calls:
Step
1. Enter system view.
2. Create a dialer interface and
enter its view.
3. Enable bundle DDR on the
interface.
4. Configure the host name of
the remote device.
5. Return to system view.
6. Enter physical interface view.
Command
system-view
interface dialer number
dialer bundle enable
dialer number dial-number
quit
interface
interface-type
interface-number
dialer bundle-member number
[ priority priority ]
Command
system-view
interface dialer number
dialer bundle enable
dialer peer-name username
quit
interface interface-type
interface-number
174
Remarks
N/A
N/A
By default, bundle
disabled.
N/A
N/A
N/A
By default, a physical interface
does not belong to a dialer
bundle.
Make sure the
arguments in the interface
dialer and
bundle-member commands use
the same value.
Remarks
N/A
N/A
By default, bundle
disabled.
The device compares the remote
username obtained
authentication with the
names configured by using the
dialer peer-name command.
Then, the device determines
which dialer interface receives
which call.
You can configure a maximum
number of 255
usernames for a dialer interface.
This enables one dialer interface
to receive calls from multiple
physical interfaces.
N/A
N/A
DDR is
number
dialer
DDR is
in PPP
host
remote
