Specifying The Primary And Backup Profiles; Configuring Pin Verification - HPE FlexNetwork MSR series Configuration Manual

Step
6. Return to system view
7. (Optional.) Delete the profile.

Specifying the primary and backup profiles

By default, profile 1 is used for 3G/4G modem dialup. The dialup fails if profile 1 does not exist.
You can also specify the primary and backup profiles for 3G/4G modem dialup. The primary profile
always has priority over the backup profile. For each dialup connection establishment, the 3G or 4G
modem uses the backup profile only when it has failed to dial up using the primary profile.
You must configure the same username and password for the primary and backup profiles.
To specify the primary and backup profiles for a 3G modem:
Step
1. Enter system view.
2. Enter cellular interface view.
3. Specify the primary and
backup profiles
To specify the primary and backup profiles for a 4G modem:
Step
1. Enter system view.
2. Enter Eth-channel interface
view.
3. Specify primary and backup
profiles for the 4G modem.

Configuring PIN verification

A UIM card is used in the CDMA network and a SIM card is used in other mobile networks. Each
SIM/UIM card has a Personal Identification Number (PIN). PIN verification prevents unauthorized
access to the SIM/UIM card.
To perform PIN verification, you need to save the PIN of the SIM/UIM card on the device by using the
pin verify command and enable PIN verification. The pin verify command can be executed before
and after you enable PIN verification. After the PIN is saved on the device, the PIN is used for
verification automatically when required.
When PIN verification is enabled, PIN verification is performed after you perform any of the following
tasks:
•
Install a 3G/4G modem.
•
Reboot the device where a USB 3G/4G modem is attached.
•
Execute the modem reboot command to reboot a 3G/4G modem.
•
Hot swap a USB 3G/4G modem.
•
Cold boot the device where a SIC-3G/4G modem is installed.
Command
quit
undo apn-profile profile-name
Command
system-view
controller
interface-number
profile main main-profile-number
backup backup-profile-number
Command
system-view
interface eth-channel
interface-number
apn-profile apply profile-name
[ backup profile-name ]
158
Remarks
N/A
N/A
Remarks
N/A
cellular
N/A
By default, profile 1 is used for 3G
modem dialup.
Remarks
N/A
N/A
By default,
specified for 4G modem dialup.
no profiles are
