Step
2. Enter VT interface view.
3. Enable the LNS to initiate
IMSI
authentication requests.
4. (Optional.)
separator for the received
authentication information.
5. (Optional.)
client username with the
IMSI or SN information for
authentication.
Configuring IMSI/SN binding authentication on the client
Step
1. Enter system view.
2. Enter VT interface view.
3. Enable the client to accept
the IMSI or SN binding
authentication requests from
the LNS.
4. (Optional.)
IMSI/SN information on the
client.
5. (Optional.)
separator
authentication information.

Configuring optional L2TP parameters

The optional L2TP parameter configuration tasks apply to both LACs and LNSs.

Configuring L2TP tunnel authentication

Tunnel authentication allows the LAC and LNS to authenticate each other. Either the LAC or the LNS
can initiate a tunnel authentication request.
You can enable tunnel authentication on both sides or either side.
To ensure a successful tunnel establishment when tunnel authentication is enabled on both sides or
either side, set the same non-null key on the LAC and the LNS. To set the tunnel authentication key,
use the tunnel password command.
When neither side is enabled with tunnel authentication, the key settings of the LAC and the LNS do
not affect the tunnel establishment.
Command
interface
virtual-template-number
or SN binding
ppp lcp { imsi | sn } request
Configure the
ppp user accept-format imsi-sn
split splitchart
Replace the
ppp user replace { imsi | sn }
Command
system-view
interface
virtual-template-number
ppp lcp { imsi | sn } accept
Configure the
ppp lcp { imsi | sn } string info
Configure the
ppp user attach-format imsi-sn
for the sent
split splitchart
virtual-template
virtual-template
82
Remarks
By default, no VT interface is
created.
By default, the LNS does not
initiate IMSI or SN
authentication requests.
By default, no separator
configured for the
authentication information.
If no IMSI or SN information is
received from the peer during the
authentication process,
or SN information split from the
received authentication
information is used.
By default, the client username is
used for authentication.
Remarks
N/A
By default, no VT interface is
created.
By default, the client does not
accept IMSI or SN
authentication requests.
By default, the client automatically
obtains the IMSI or SN information
from its SIM card.
By default, no separator
configured for the
authentication information.
binding
is
received
t
he IMSI
binding
is
sent
