Ipsec; Ipsec Tunnels - Funkwerk R1202 Reference Manual

Funkwerk Enterprise Communications GmbH
bintec Rxxx2/RTxxx2
Field
Subsystem
Message

24.2 IPSec

24.2.1 IPSec Tunnels

A list of all configured IPSec tunnels is displayed in the Monitoring->IPSec->IPSec Tun-
nels menu.
Monitoring IPSec
Fig. 205: ->
Values in the IPSec Tunnels list
Field
Description
Remote IP
Remote Networks
Security Algorithm
Status
Action
Details
You change the status of the IPSec tunnel by pressing the
Actioncolumn.
By pressing the button, you display detailed statistics on the IPSec connection.
Description
Displays which subsystem of the device generated the mes-
sage.
Displays the message text.
IPSec Tunnels
->
Description
Displays the name of the IPSec tunnel.
Displays the IP address of the remote IPSec Peers.
Displays the currently negotiated subnets of the remote termin-
al.
Displays the encryption algorithm of the IPSec tunnel.
Displays the operating status of the IPSec tunnel.
Enables you to change the status of the IPSec tunnel as dis-
played.
Opens a detailed statistics window.
24 Monitoring
button or button in the
507
