Liability While every effort has been made to ensure the accuracy of all information in this manual, Funkwerk Enterprise Communications GmbH cannot assume liability to any party for any loss or damage caused by errors or omissions or by statements of any kind in this document and is only liable within the scope of its terms of sale and delivery.
R3000w bintec R3000w Delivery size Your gateway is supplied with the following parts: ■ Cable sets/power supply: – Ethernet cable – ISDN cable – Serial cable – DSL cable – Power supply ■ Antennas: – two standard antennas ■...
Page 6
R3000w Feature Data Dimensions/weight (B x H x D): Dimensions without cables 295 mm x 160 mm + 8mm (antenna connections) x 41 mm Weight 1250 g Transport weight (incl. documenta- approx. 2.6 kg tion, cabling, packaging) Memory 32 MB SDRAM,...
Page 7
R3000w Feature Data Available interfaces: ADSL interface Built-in ADSL modem for Annex A and Annex B Ethernet IEEE 802.3 LAN Built-in (twisted-pair only), (4 port switch) 10/100 Mbps, auto sensing, MDIX; one port with serial interface mode supports the following baud rates:...
R3000w Antenna Diversity The two antennas do not have equal funtion. The one named "Main", "Primary" Note or "1" (at R3000 Series devices the antenna next to the power switch) is used for sending and receiving, the other one only for receiving. The AP (Access point) verifies, which of the two antennas receives the better signal, which is then used for decoding.
R3000w Status Information ISDN-0 B/D upper line: ISDN D channel is active. lower line: One ISDN B channel is active. flashing Both ISDN B channels are active. ISDN-1 B/D upper line: ISDN D channel is active. lower line: One ISDN B channel is active.
R3000w The connections are arranged as follows: 1. I/O Power Switch Ethernet interface ETH2 - ETH4 Socket for power Ethernet interface supply ETH1/ with serial interface mode Console Ethernet interface ISDN interfaces DMZ/ETH5 ISDN-0 ISDN-1 RSMA connection 8. ADSL...
Page 11
R3000w The DMZ/ETH5 interface can be used to connect an optional DSL modem or a DMZ. An RJ45 socket is used for connecting: Figure 1-3: Ethernet 10/100Base-T interface (RJ45 socket) The Ethernet sockets have the following pin assignment: Function...
R3000w Function RX (Console) GND (Console) RD - (Ethernet) GND (Console) TX (Console) Table 1-4: RJ45 socket for Ethernet connection resp. serial interface (Console) 1.5.2 ADSL Interface The ADSL interface is connected using a RJ45 socket. The supplied cable combines the RJ11 plug required by most ADSL splitters and the RJ45 plug required by the gateway.
R3000w Function line b not assigned not assigned not assigned Table 1-5: ADSL interface (RJ45 socket) 1.5.3 ISDN Basic Rate Interface bintec R3000w provides an ISDN S interface, which can be used, e.g., for backup purposes. A RJ45 socket is used for connecting: 1 .
Page 14
R3000w Function Send (-) Not used Not used Table 1-6: RJ45 socket for ISDN connection bintec User’s Guide Technical Data...
bintec R3400 bintec R3400 Delivery size Your gateway is supplied with the following parts: ■ Cable sets/power supply: – Ethernet cable – ISDN cable – Serial cable – DSL cable – Power supply ■ bintec Companion CD ■ Documentation: – Quick Install Guide (printed) –...
Page 16
bintec R3400 Feature Data Dimensions/weight (B x H x D): Dimensions without cables 295 mm x 160 mm x 41 mm Weight 1250 g Transport weight (incl. documenta- approx. 2,6 kg tion, cabling, packaging) Memory 32 MB SDRAM, 8 MB Flash-ROM LEDs 18 (1x Power, 1x Status, 5x2 Ethernet, 4x2 Function)
Page 17
bintec R3400 Feature Data Available interfaces: SHDSL interface Built-in SHDSL 4-wire modem for Annex A and Annex B Bonding technology with 2-/4-wire Can also be used as invers multi- plexer - with IMA according to ATM Forum Ethernet IEEE 802.3 LAN Built-in (twisted-pair only), (4 port switch) 10/100 Mbps, auto sensing, MDIX;...
bintec R3400 LEDs The LEDs on your bintec R3400 Gateway indicate the states and the activ- ity of the gateway. They are arranged as follows: Figure 2-1: LEDs on bintec R3400 In operational mode the LEDs display the following status information: Status Information Power...
bintec R3400 Status Information SHDSL-2/1 upper line: The wire pair 4-5 is synchronized with the DSLAM of the SHDSL-Provider. flashing Data traffic via the SHDSL wire pair 4-5. lower line: The wire pair 7-8 is synchronized with the DSLAM of the SHDSL-Provider. flashing Data traffic via the SHDSL wire pair 7-8.
bintec R3400 The connections are arranged as follows: 1. I/O Power Switch Ethernet interface ETH2- ETH4 Socket for power Ethernet interface supply with serial interface ETH1/ mode Console Ethernet interface 7. ISDN ISDN interface DMZ/ETH5 8. SHDSL SHDSL interface Figure 2-2: bintec R3400 rear Pin Assignments...
Page 21
bintec R3400 An RJ45 socket is used for connecting: Figure 2-3: Ethernet 10/100Base-T interface (RJ45 socket) The Ethernet sockets have the following pin assignment: Function TD + TD - RD + Not used Not used RD - Not used Not used Table 2-3: RJ45 socket for Ethernet connection The combined Serial-Ethernet-sockets have the following pin assignment:...
bintec R3400 Function GND (Console) RD - (Ethernet) GND (Console) TX (Console) Table 2-4: RJ45 socket for Ethernet connection resp. serial interface (Console) 2.5.2 SHDSL Interface The SHDSL interface is connected using a RJ45 socket. The supplied ca- ble combines the RJ45 plug required for the SHDSL connection and the RJ45 plug required by the gateway.
bintec R3400 Function not assigned line a2 line b2 Table 2-5: SHDSL interface (RJ45 socket) 2.5.3 ISDN Basic Rate Interface bintec R3400 provides an ISDN S interface, which can be used, e.g., for backup purposes. A RJ45 socket is used for connecting: 1 .
Page 24
bintec R3400 Function Not used Not used Table 2-6: RJ45 socket for ISDN connection bintec User’s Guide Technical Data...
bintec R3800 bintec R3800 Delivery size Your gateway is supplied with the following parts: ■ Cable sets/power supply: – Ethernet cable – ISDN cable – Serial cable – DSL cable – Power supply ■ bintec Companion CD ■ Documentation: – Quick Install Guide (printed) –...
Page 26
bintec R3800 Feature Data Dimensions/weight (B x H x D): Dimensions without cables 295 mm x 160 mm x 41 mm Weight 1250 g Transport weight (incl. documenta- approx. 2,6 kg tion, cabling, packaging) Memory 32 MB SDRAM, 8 MB Flash-ROM LEDs 18 (1x Power, 1x Status, 5x2 Ethernet, 4x2 Function)
Page 27
bintec R3800 Feature Data Available interfaces: SHDSL interface Built-in SHDSL 8-wire modem for Annex A and Annex B Bonding technology with 2-/4-/6-/8- wire Can also be used as inverse multi- plexer - with IMA according to ATM Forum Ethernet IEEE 802.3 LAN Built-in (twisted-pair only), (4 port switch) 10/100 Mbps, auto sensing, MDIX;...
bintec R3800 LEDs The LEDs on your bintec R3800 Gateway indicate the states and the activ- ity of the gateway. They are arranged as follows: Figure 3-1: LEDs on bintec R3800 In operational mode the LEDs display the following status information: Status Information Power...
bintec R3800 Status Information SHDSL-2/1 upper line: The wire pair 4-5 is synchronized with the DSLAM of the SHDSL-Provider. flashing Data traffic via the SHDSL wire pair 4-5. lower line: The wire pair 7-8 is synchronized with the DSLAM of the SHDSL-Provider. flashing Data traffic via the SHDSL wire pair 7-8.
bintec R3800 The connections are arranged as follows: 1. I/O Power Switch Ethernet interface ETH2 - ETH4 Socket for power Ethernet interface supply with serial interface ETH1/ mode Console Ethernet interface 7. ISDN ISDN interface DMZ/ETH5 8. SHDSL SHDSL interface Figure 3-2: bintec R3800 rear...
Page 31
bintec R3800 An RJ45 socket is used for connecting: Figure 3-3: Ethernet 10/100Base-T interface (RJ45 socket) The Ethernet sockets have the following pin assignment: Function TD + TD - RD + Not used Not used RD - Not used Not used Table 3-3: RJ45 socket for Ethernet connection The combined Serial-Ethernet-sockets have the following pin assignment:...
Page 32
bintec R3800 Function GND (Console) RD - (Ethernet) GND (Console) TX (Console) Table 3-4: RJ45 socket for Ethernet connection resp. serial interface (Console) 3.5.2 SHDSL Interface The SHDSL interface is connected using a RJ45 socket. The supplied ca- ble combines the RJ45 plug required for the SHDSL connection and the RJ45 plug required by the gateway.
Page 33
bintec R3800 Function line b3 line a2 line b2 Table 3-5: SHDSL interface (RJ45 socket) 3.5.3 ISDN Basic Rate Interface bintec R3800 provides an ISDN S interface, which can be used, e.g., for backup purposes. A RJ45 socket is used for connecting: 1 .
Page 34
bintec R3800 Function Not used Not used Table 3-6: RJ45 socket for ISDN connection bintec User’s Guide Technical Data...
