User'sGuide
bintec R230a / R230aw / R232b/ R232bw
External Systems
©
Copyright
April 13, 2006 Funkwerk Enterprise Communications GmbH
Version 2.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the bintec R230a and is the answer not in the manual?

Questions and answers

Summary of Contents for Funkwerk bintec R230a

  • Page 1 User’sGuide bintec R230a / R230aw / R232b/ R232bw External Systems © Copyright April 13, 2006 Funkwerk Enterprise Communications GmbH Version 2.0...
  • Page 2 Liability While every effort has been made to ensure the accuracy of all information in this manual, Funkwerk Enterprise Communications GmbH cannot assume liability to any party for any loss or damage caused by errors or omissions or by statements of any kind in this document and is only liable within the scope of its terms of sale and delivery.
  • Page 3 External Systems Menu ........3 Submenu artem Access Point Discovery/Configuration ....3 1.1.1 Submenu Initiate Discovery .
  • Page 4 bintec User’s Guide External Systems...
  • Page 5 External Systems Menu External Systems Menu The fields of the E menu are described below. XTERNAL YSTEMS In the E menu external systems can be configured resp. mon- XTERNAL YSTEMS itored. Presently only the artem Access Point discovery is implemented. Submenu artem Access Point Discov- ery/Configuration The fields of the...
  • Page 6 External Systems Menu In ex works state the displayed list contains no entries. The following screenshot shows an example: R232bw Setup Tool Funkwerk Enterprise Communications GmbH [EXT][artem AP][DISCOV]: artem AP Discovery MyGateway Press 'd' to run discovery on selected interface...
  • Page 7 External Systems Menu Column Description Result Displays the result of the operation. This value is updated automatically. Make sure that the network cable is plugged in to the required interface. The values are read-only: ■ no Error: No discovery initiated or discovery was a success.
  • Page 8 YSTEMS ARTEM CCESS OINT ISCOVERY ONFIGUR ATION NITIATE ➜ ADD: ISCOVERY R232bw Setup Tool Funkwerk Enterprise Communications GmbH [EXT][artem AP][DISCOV][ADD]: Add Interfaces for MyGateway artem AP Discovery Interface en1-0 Operation none SAVE CANCEL The menu contains the following fields: Field...
  • Page 9 ➜ ➜ XTERNAL YSTEMS ARTEM CCESS OINT ISCOVERY ONFIGURATION ONFIGURE R232bw Setup Tool Funkwerk Enterprise Communications GmbH [EXT][artem AP][CONF]: Discovered artem Access Points MyGateway Interface AP MAC Address Node Name IP Address / Mask en1-0 00:01:cd:0e:a5:01 XAIR AP1 192.168.0.1...
  • Page 10 IP configuration. You can change a number of values by selecting an entry and confirming with Return: R232bw Setup Tool Funkwerk Enterprise Communications GmbH [EXT][artem AP][CONF][EDIT]: artem AP Configuration MyGateway Interface...
  • Page 11 External Systems Menu Field Description IP Status Displays by which mechanism the access point has received its IP configuration. Possible values are: ■ unknown: The information cannot be col- lected from the access point. ■ static: The IP configuration was carried out manually.
  • Page 12 External Systems Menu Field Description Result Displays the result of a "set" operation. Possible values are: ■ no Error: The access point has reported success or a configuration modification with SET has not yet been initiated. ■ no Reply: The access point has not replied. ■...
  • Page 13 External Systems Menu Field Description Netmask Here you can change the netsmask of the dis- covered access point. Gateway Address Here you can change the gateway address of the discovered access point. Admin. Password Here you must enter the admin password of the access point.
  • Page 14 External Systems Menu bintec User’s Guide External Systems...
  • Page 15 Index: External Systems Access Points Admin. Password AP MAC Address Authentisierungsverhandlung Calling Party Number CLID Discovery discovery Gateway Address 4, 6, 8 Interface IP Address IP Status Last Change Last Run Netmask Node Name 4, 7, 9 Operation 5, 10 Result External Systems bintec User’s Guide...
  • Page 16 bintec User’s Guide External Systems...
