Funkwerk bintec R230aw User Manual

Hide thumbs Also See for bintec R230aw:
Table of Contents

Advertisement

Quick Links

See also: Technical Data Manual
User's Guide
bintec R230a / R230aw / R232b / R232bw
System
©
Copyright
April 26, 2006 Funkwerk Enterprise Communications GmbH
Version 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the bintec R230aw and is the answer not in the manual?

Questions and answers

Related Manuals for Funkwerk bintec R230aw

Summary of Contents for Funkwerk bintec R230aw

  • Page 1 User’s Guide bintec R230a / R230aw / R232b / R232bw System © Copyright April 26, 2006 Funkwerk Enterprise Communications GmbH Version 2.0...
  • Page 2 Liability While every effort has been made to ensure the accuracy of all information in this manual, Funkwerk Enterprise Communications GmbH cannot assume liability to any party for any loss or damage caused by errors or omissions or by statements of any kind in this document and is only liable within the scope of its terms of sale and delivery.

  • Page 3: Table Of Contents

    System Menu ......... . . 3 Submenu External Activity Monitor .
  • Page 4 bintec User’s Guide System...

  • Page 5: System Menu

    System Menu System Menu The fields of the S menu are described below. YSTEM R232bw Setup Tool Funkwerk Enterprise Communications GmbH [SYSTEM]: Change System Parameters MyGateway System Name r232bw Local PPP ID (default) r232bw Location Contact BINTEC Syslog Output on Serial Sonsole...
  • Page 6 System Menu Field Description Location Indicates where your gateway is located. Is shown, for example, on the HTML system information page or in the login message. Contact Indicates the responsible contact person. Here you can enter the e-mail address of the system administrator, for example.
  • Page 7 System Menu Field Description Message Level for the Specifies the priority of the syslog messages to Syslog Table be recorded internally. Possible values: ■ emerg: emergency messages (highest pri- ority) ■ alert: alert messages ■ crit: critical messages ■ err: error messages ■...
  • Page 8 System Menu bintec User’s Guide System...

  • Page 9: Submenu

    Submenu External Activity Monitor The fields of the E submenu are described below. XTERNAL CTIVITY ONITOR R232bw Setup Tool Funkwerk Enterprise Communications GmbH [SYSTEM]: [ACTIVMON]: External Activity Monitor MyGateway Client IP Address 255.255.255.255 Client UDP Port 2107 Type Update Interval (sec)
  • Page 10 Submenu External Activity Monitor ■ Start and configure the Windows application on your PC (see BRICKware for Windows). The E menu consists of the following fields: XTERNAL CTIVITY ONITOR Field Description Client IP Address IP address to which the gateway sends the UDP packets.

  • Page 11: External System Logging

    XTERNAL YSTEM OGGING ➜ The S menu shows the log host settings. YSTEM XTERNAL YSTEM OGGING R232bw Setup Tool Funkwerk Enterprise Communications GmbH [SYSTEM][LOGGING][ADD] MyGateway Log Host Level info Facility local0 Type Timestamp none Method SAVE CANCEL ➤➤...
  • Page 12 Submenu External System Logging ➜ The settings for saving syslog messages externally are made in S YSTEM ➜ ADD/EDIT. XTERNAL YSTEM OGGING The menu consists of the following fields: Field Description ➤➤IP address of the host to which syslog Log Host messages are passed.
  • Page 13 Submenu External System Logging Field Description Method Protocol for sending syslog messages. Possible values: ■ udp (default value) ■ Table 3-1: menu fields XTERNAL YSTEM OGGING System bintec User’s Guide...
  • Page 14 Submenu External System Logging bintec User’s Guide System...

  • Page 15: Submenu Schedule & Monitor

    Submenu Schedule & Monitor Submenu Schedule & Monitor The fields of the S & M submenu are described below. CHEDULE ONITOR The S & M menu offers access to other submenus: CHEDULE ONITOR ■ & I EEPALIVE ONITORING OSTS ■ &...
  • Page 16 Submenu Schedule & Monitor : hosts HAT TO MONITOR R232bw Setup Tool Funkwerk Enterprise Communications GmbH [SYSTEM][KEEPALIVE MONITORING][ADD]: Host Monitoring MyGateway Group IPAddress Interval Trials Source IP DownAction down FirstIfIndex 10001 Range 4999 SAVE CANCEL ➜ If hosts has been selected, the K...
  • Page 17 Submenu Schedule & Monitor Field Description Source IP The IP address that the gateway uses as source address of the packet sent to the host to be monitored. DownAction Defines how the status of the gateway inter- faces selected in F and R is set IRST...
  • Page 18 19, the interfaces with the indices 10001 to 10020 are affected. hosts Table 4-1: Fields in K menu EEPALIVE ONITORING : Interfaces HAT TO MONITOR VR232bw Setup Tool Funkwerk Enterprise Communications GmbH [SYSTEM][KEEPALIVE MONITORING][ADD]: Interface Monitoring MyGateway Interface Trigger down Action none SAVE CANCEL bintec User’s Guide...
  • Page 19 Submenu Schedule & Monitor If W : interfaces has been selected, the K HAT TO MONITOR EEPALIVE ONITORING ➜ ADD/EDIT menu consists of the following fields: Field Description Interface Defines the interface to be monitored in the gateway. Enter the interface I here.

  • Page 20: Submenu Event Scheduler

    Submenu Schedule & Monitor Field Description FirstIfIndex Defines the first interface of an interface range in the gateway, for which the action (down or up) defined under D is to be exe- CTION cuted. Possible values: 100 .. 65536 Default value: 10001 Interfaces with indices from 10001 to 14999 are provided for dialup connections to WAN part- ners.

  • Page 21: Configuration Of Triggers (Events)

    The event scheduler is configured in the S & M YSTEM CHEDULE ONITOR & SNMP) menu: VENT CHEDULER R232bw Setup Tool Funkwerk Enterprise Communications GmbH [SYSTEM][SCHEDULED]: Event Schedule MyGateway Event Scheduler disabled Schedule Events > Schedule Commands > SAVE CANCEL...
  • Page 22 Submenu Schedule & Monitor Menu with = time: TYPE R232bw Setup Tool Funkwerk Enterprise Communications GmbH [SYSTEM][SCHEDULED][SCHED_EVT][ADD]: Scheduler Events MyGateway Index Description NextIndex none Type time Condition daily Start time (hh:mm) End time (hh:mm) Status notavail SAVE CANCEL Menu with...
  • Page 23 Submenu Schedule & Monitor The menu contains the following fields depending on the setting: Field Description Index The gateway assigns an index number for the entry automatically. This value can also be edited. The index defines the order of display in ➜...
  • Page 24 Submenu Schedule & Monitor Field Description Monitored event Only for T = value. Here you can choose between different events. Possible settings: ■ user defined - The event is defined depend- ing on the value of a specific MIB variable (default value).
  • Page 25 Submenu Schedule & Monitor Field Description Index variable Only for M = user defined. ONITORED EVENT Here you enter the name of the MIB variable in that is to be used as "index" to clearly ABLE define one specific data record in the table, e.g. ConnIfIndex.
  • Page 26 Submenu Schedule & Monitor Field Description Condition For T = time: ■ daily - The trigger becomes active daily (de- fault value). ■ <day of week> - The trigger becomes re- peatedly active on a certain day of the week. ■...
  • Page 27 Submenu Schedule & Monitor Field Description ■ Compare value For M = user defined and ONITORED EVENT = value. The compare value relevant for V ARIABLE For C = range this is the start value ONDITION of the range. ■ For M not user defined and ONITORED EVENT...

  • Page 28: Configuration Of The Action (Command)

    Submenu Schedule & Monitor Field Description Status This field cannot be edited and shows the sta- tus of the trigger. Possible values: ■ error - An error has occurred; the configura- tion of the trigger is not consistent. ■ notavail - The status cannot be determined, e.g.
  • Page 29 Submenu Schedule & Monitor Menu with E XECUTE = user defined COMMAND R232bw Setup Tool Funkwerk Enterprise Communications GmbH [SYSTEM][SCHEDULED][SCHED_CMD][ADD]: Scheduler Commands MyGateway Index Description Mode enable 1. Event Index none Eventlist Condition Execute command user defined Table Variable Index variable...
  • Page 30 Submenu Schedule & Monitor The menu contains the following fields depending on the setting selected: Field Description Index The gateway assigns an index number for the entry automatically. This value can also be edited. The index defines the order of display in ➜...
  • Page 31 Submenu Schedule & Monitor Field Description Eventlist Condition Here you define how many entries of the selected event chain must occur before an action is executed. Possible settings: ■ all - The action is to be active if all events of the event chain are active (default value).
  • Page 32 Submenu Schedule & Monitor Field Description Table Only for E = user defined. XECUTE OMMAND Here you enter the name of the MIB table con- taining the variable to be set, e.g. ifTable. Variable Only for E = user defined. XECUTE OMMAND Here you enter the name of the MIB variable to...
  • Page 33 Submenu Schedule & Monitor Field Description Notify Here you select if syslog messages or traps are generated for this action. Possible values: ■ all - Both SNMP traps and syslog messages can be generated. (Default value) ■ snmptrap - Only traps can be generated. ■...
  • Page 34 Submenu Schedule & Monitor bintec User’s Guide System...

  • Page 35: Submenu Password Settings

    Submenu Password Settings Submenu Password Settings The fields of the P submenu are described below. ASSWORD ETTINGS R232bw Setup Tool Funkwerk Enterprise Communications GmbH [SYSTEM][PASSWORDS]: Change System Passwords MyGateway admin Login Password/SNMP Community ****** read Login Password/SNMP Community ****** write Login Password/SNMP Community...
  • Page 36 Submenu Password Settings All bintec gateways are shipped with the same user name and password. As long as the password remains unchanged, they are not protected against unau- thorized use. Attention! Change the password to prevent unauthorized access to the gateway. As long as the password remains unchanged, the following warning appears on logging in: "Password not changed".

  • Page 37: Submenu Time And Date

    Submenu Time and Date The fields of the T submenu are described below. IME AND R232bw Setup Tool Funkwerk Enterprise Communications GmbH [SYSTEM][TIME]: Control System Time and Date MyGateway Current System Time: Wed 2005/Feb/28 19:19:37 setby: None Change System Time:...
  • Page 38 Submenu Time and Date The menu consists of the following fields: Field Description Current System Time Here the current date and system time are dis- played. The entry cannot be changed. displays how the time has been set. SET BY Change System Time Here you can manually set the current date and system time.
  • Page 39 Submenu Time and Date Field Description Protocol Here you choose the protocol used for querying the time server. Possible values: ■ SNTP - This server uses the Simple Net- work Time Protocol with UDP port 123. ■ disabled - This time server is currently not used for time retrieval.
  • Page 40 Submenu Time and Date bintec User’s Guide System...

  • Page 41: Index: System

    Index: System Numerics 1st Event index Action Activity Monitor Basic system data Central server Change System Time CLID Client IP address Client UDP port Compare value Condition Contact Current System Time 21, 28 Description DownAction End time End value Event protocol Eventlist condition Execute command External Activity Monitor...
  • Page 42 Hosts 21, 28 Index 23, 30 Index value 23, 30 Index variable 17, 29 Interface Interfaces Interval IP address Keepalive Monitoring Last change Level Local PPP ID (default) Location 9, 10 Log host Maximum Number of Acctlog Entries Maximum number of syslog entries Message level for the syslog table Method Mode...
  • Page 43 Password settings Activity Monitor admin Ex works state HTTP server read write Protocol 16, 18 Range Set value active Source IP Start time 26, 31 Status Subsystems Syslog messages Syslog output on serial console System name System time Accounting Automatic Manual System Time Offset from GMT 22, 30...
  • Page 44 Value inactive 22, 30 Variable bintec User’s Guide System...

This manual is also suitable for:

Bintec r230aBintec r232bBintec r232bw
