5985 Device Setting
The NIC and USB support features are built into the GW controller. Use this
SP to enable and disable these features. In order to use the NIC and USB
functions built into the controller board, these SP codes must be set to "1".
1 On Board NIC
[0 to 2 / 1 / 1 /step]
0: Disable, 1: Enable, 2: Function limitation
When the "Function limitation" is set, "On board NIC" is limited for use with
only NRS or LDAP/NT authentication.
⇒
Note:
Other network applications such as WebImageMonitor, @Remote, or
LDAP/NT authentication are not available when this SP is set to "2".
Even if you can change the initial settings of those network applications,
the settings will not work
2 On Board USB
[0 or 1 / 0 / 1/step]
0: Disable, 1: Enable
5990 SP Print Mode (SMC Print)
In the SP mode, press Copy Window to move to the copy screen, select the
paper size, then press Start. Select A4/LT (Sideways) or larger to ensure that all
the information prints. Press SP Window to return to the SP mode, select the
desired print, and press Execute.
1 All (Data List)
2 SP (Mode Data List)
3 User Program Data
4 Logging Data
5 Diagnostic Report
