Internal Finisher SR3250
Machine Code: D3FG
Field Service Manual
Ver. 1.0
Latest Release: December, 2018
Initial Release: December, 2018
Copyright (c) 2018 Ricoh Co.,Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR3250 and is the answer not in the manual?

Questions and answers

Related Manuals for Ricoh SR3250

Summary of Contents for Ricoh SR3250

  • Page 1 Internal Finisher SR3250 Machine Code: D3FG Field Service Manual Ver. 1.0 Latest Release: December, 2018 Initial Release: December, 2018 Copyright (c) 2018 Ricoh Co.,Ltd.
  • Page 3 Adobe Systems Incorporated in the United States and/or other countries. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Ricoh Company, Ltd. is under license. Firefox and Thunderbird are registered trademarks of the Mozilla Foundation.
  • Page 4 Dropbox is a registered trademark or trademark of Dropbox, Inc. Google, Android, and Chrome are trademarks of Google Inc. Java is a registered trademark of Oracle and/or its affiliates. Macintosh, OS X, Bonjour, Safari, and TrueType are trademarks of Apple Inc., registered in the U.S. and other countries.
  • Page 5 Microsoft® Windows® 8 Microsoft® Windows® 8 Pro Microsoft® Windows® 8 Enterprise • The product names of Windows 10 are as follows: Microsoft® Windows® 10 Home Premium Microsoft® Windows® 10 Pro Microsoft® Windows® 10 Enterprise Microsoft® Windows® 10 Education • The product names of Windows Server 2003 are as follows: Microsoft®...

  • Page 7: Table Of Contents

    Table of Contents Detailed Descriptions .......................... 3 Changes from the Previous Machine ..................... 3 Specifications............................4 Parts Layout ............................6 Mechanism ............................10 Straight Paper Ejection Mechanism ....................10 Shift Eject Mechanism ........................10 Staple Eject Mechanism ........................11 Paper Press Mechanism ........................15 Tray Drive Mechanism ........................
  • Page 8 Entrance Motor (M10) ........................34 Tray Lift Motor (M15) ........................35 Stack Height Lever Motor (M6)......................35 Paper Exit Guide Plate Motor (M12) ....................36 Positioning Roller Motor (M14) ......................36 Shift Motor (M11) ..........................37 Stapler Retreat Motor (M13) ......................39 Jogger Fence Motor (Front) (M4), Jogger Fence Motor (Rear) (M5) ..........

  • Page 9: Detailed Descriptions

    1.Detailed Descriptions 1. Detailed Descriptions Changes from the Previous Machine Jogger Mechanism (Paper Alignment) The paper alignment changes according to the paper size. • If Corner Stapling on Paper Other than B5Y or Larger Paper When the paper is fed into the staple tray, the rear jogger fence [1] moves to align the paper according to the paper size.

  • Page 10: Specifications

    1.Detailed Descriptions Specifications Paper size: A3 SEF, A4 SEF/LEF, A5 SEF/LEF, A6 SEF, B4 JIS SEF, B5 JIS SEF/LEF, B6 JIS SEF, 11 x 17 SEF, 8 x 14 SEF, 8 x 13 LEF, 8 x 11 SEF/LEF, 8 x 14 SEF, 8 x 13 SEF, 8 x 13 SEF, 8 x 10 SEF, 7 x 10 SEF/LEF, 5...
  • Page 11 1.Detailed Descriptions Staple position: Top 1, Bottom 1, Left 2, Top 2 • Power consumption: 47 W or less (without punch unit) (Power is supplied from the main unit.) • 60 W or less (with punch unit) (Power is supplied from the main unit.) Dimensions (W x D 546 x 523 x 170 mm (21.5 x 20.6 x 6.7 inches) x H):...

  • Page 12: Parts Layout

    1.Detailed Descriptions Parts Layout Description Description Paper exit tray Transport roller Paper ejection roller Entrance roller Paper exit guide plate Stapler Positioning roller Staple tray (jogger) Shift roller Stack height detection lever Reverse roller Full sensor Description Description Paper exit guide plate Transport roller Paper exit guide plate motor (M12) Reverse roller...
  • Page 13 1.Detailed Descriptions Description Description Paper exit tray Stapler Stack height detection lever Jogger motor Staple tray (jogger) Stapler retreat motor (M13) Shift motor (M11) Stack height lever motor (M6) Shift roller Tray lift motor (M15) Description Description Entrance motor (M10) Transport motor (M8) Transport sensor (S13) Paper exit motor (M9)
  • Page 14 1.Detailed Descriptions Description Description Positioning roller motor (M14) Shift roller HP sensor (S11) Positioning roller HP sensor (S10) Paper exit guide plate motor (M12) Paper exit guide plate HP sensor (S7) Shift motor (M11) Description Description Stapler retreat motor (M13) Jogger fence motor (front) (M4) Jogger fence HP sensor (rear) (S16) Jogger fence HP sensor (front) (S15)
  • Page 15 1.Detailed Descriptions Description Description Stack height lever HP sensor (S18) Controller board (PCB1) Paper surface sensor (S17) Cooling fan motor (FAN1) Stack height lever motor (M6) Paper exit full sensor (S8) Cover open/closed switch (SW1) Tray lift motor (M15)

  • Page 16: Mechanism

    1.Detailed Descriptions Mechanism Straight Paper Ejection Mechanism Paper ejected from the printer unit is transported by a transport roller and eject roller via an entrance roller. These are driven by entrance motor, transport motor and eject motor which permit linear speed correspondence.

  • Page 17: Staple Eject Mechanism

    1.Detailed Descriptions • Return to original position: Leading edge of succeeding sheet passes transport sensor The shift roller detects the home position by the shift roller HP sensor. The shift motor operates CW/CCW, and shifts the paper from front to back. The home position is located at the back of the displacement range, and is detected by the shift roller HP sensor.
  • Page 18 1.Detailed Descriptions Positioning roller ascent/descent mechanism The positioning roller unit is made to ascend/descend by a positioning roller motor (the motor operates CW/CCW), and its position is detected by the positioning roller HP sensor. The positioning roller rotates in the opposite direction to the transport roller, and has the function of transporting paper to the back of the staple tray.
  • Page 19 1.Detailed Descriptions • If Corner Stapling on B5 SEF or Larger Paper The movement is basically the same except that the front jogger fence, not the rear jogger fence, moves for paper alignment when the paper is fed into the tray. The jogger fences (rear and front) stand by 7 to 12 mm away from the paper, and again moves 7 mm [A] towards the paper in order to perform paper alignment, so it moves a total of 14 to 19 mm [B].
  • Page 20 1.Detailed Descriptions Description Description Stapler HP sensor Stapler retreat motor Stapler The stapler moves from the home position to the paper size to be stapled, and temporarily stands by. Next, the paper is transported, and after the jogger operation (paper alignment), stapling is performed. The following picture shows the stapler standby position according to various stapling positions.

  • Page 21: Paper Press Mechanism

    1.Detailed Descriptions Paper Press Mechanism For ejected paper, a paper press unit is provided to immobilize the paper above the tray. It is driven by the stack height lever motor (motor operates CW/CCW) The paper press unit is provided with a paper surface sensor which detects the upper part of the paper, and the stack height lever HP sensor which detects the home position of the paper press unit.

  • Page 22: Replacement And Adjustment

    2.Replacement and Adjustment 2. Replacement and Adjustment Removing the Internal Finisher Disconnect the interface cable connected to the main machine. Open the front cover [A]. Remove the left upper cover [A] ( ×1). Remove the left rear cover [A] ( ×2, hook×1).
  • Page 23 2.Replacement and Adjustment Remove the internal finisher [A] ( ×1). Remove the bridge guide plate [A] ( ×2).

  • Page 24: Exterior Covers And Trays

    2.Replacement and Adjustment Exterior Covers and Trays Finisher Front Cover Pull the finisher [A]. Remove the finisher front cover [A] ( ×2). Finisher Upper Cover Remove the finisher front cover (Finisher Front Cover).

  • Page 25: Finisher Rear Cover

    2.Replacement and Adjustment Remove the finisher upper cover [A] ( ×2). Finisher Rear Cover Remove the internal finisher (Removing the Internal Finisher). Remove the finisher rear cover [A] ( ×2). Paper Exit Tray Remove the left lower cover [A] ( ×2).

  • Page 26: Paper Exit Cover

    2.Replacement and Adjustment Remove the paper exit tray [A] ( ×2). Paper Exit Cover Remove the paper exit tray (Paper Exit Tray). Remove the paper exit cover [A] ( ×3, ×3, ×2).

  • Page 27: Board

    2.Replacement and Adjustment Board Controller Board (PCB1) • When a controller board is replaced, use the same DIP switch settings as those of the controller board before replacement. Remove the finisher front cover. (Finisher Front Cover) Remove the controller board (PCB1). ( ×3, ×all, plastic rivet×1) Release four clamps and remove the harness bracket [A] on the controller board bracket.

  • Page 28: Controller Board Bracket

    2.Replacement and Adjustment Controller Board Bracket Remove the controller board (Controller Board (PCB1)). Release the clamps on the controller board bracket. Tilt the controller board bracket [A] towards the front.
  • Page 29 2.Replacement and Adjustment Remove the harness guide [A].

  • Page 30: Sensors

    2.Replacement and Adjustment Sensors Entrance Sensor (S9) Remove the internal finisher (Removing the Internal Finisher). Remove the Open/Closed upper cover [A] ( ×2). Remove the entrance sensor unit [A] ( ×1, ×1, ×1). Remove the entrance sensor (S9) [A].

  • Page 31: Paper Exit Full Sensor (S8)

    2.Replacement and Adjustment Paper Exit Full Sensor (S8) Remove the paper exit tray (Paper Exit Tray). Remove the paper exit full sensor (S8) [A] ( ×1, ×1). Stack Height Lever HP Sensor (S18) Remove the paper exit cover (Paper Exit Cover).

  • Page 32: Transport Sensor (S13)

    2.Replacement and Adjustment Remove the paper surface sensor (S17) [A] ( ×1). Transport Sensor (S13) Remove the finisher upper cover (Finisher Upper Cover). Remove the transport sensor unit [A] ( ×1, ×1, ×1). Remove the transport sensor (S13) [A].

  • Page 33: Positioning Roller Hp Sensor (S10)

    2.Replacement and Adjustment Positioning Roller HP Sensor (S10) Remove the following parts. • Finisher Upper Cover • Finisher Rear Cover Rotate the timing belt [A], and release the positioning roller arm unit [B] from the positioning roller HP sensor (S10) [C]. Remove the positioning roller HP sensor unit [A].

  • Page 34: Paper Exit Guide Plate Hp Sensor (S7)

    2.Replacement and Adjustment Paper Exit Guide Plate HP Sensor (S7) Remove the controller board (Controller Board (PCB1)). Rotate the paper exit guide plate gear [A] counterclockwise, and release the paper exit guide plate [B] from the paper exit guide plate HP sensor (S7) [C]. Remove the paper exit guide plate HP sensor (S7) [A] ( ×1).

  • Page 35: Stapler Move Hp Sensor (S12)

    2.Replacement and Adjustment Remove the shift roller HP sensor (S11) [A]. Stapler Move HP Sensor (S12) Remove the controller board bracket (Controller Board Bracket) Remove the knob [A]. Remove the entrance cover [A] ( ×2).

  • Page 36: Jogger Fence Hp Sensor (Front) (S15)

    2.Replacement and Adjustment Remove the stapler move HP sensor unit [A] ( ×1, ×1). Remove the stapler move HP sensor (S12) [A]. • If it is difficult to remove or attach the sensor, push the stapler unit inside. Jogger Fence HP Sensor (Front) (S15) Remove the paper exit cover (Paper Exit Cover).

  • Page 37: Jogger Fence Hp Sensor (Rear) (S16)

    2.Replacement and Adjustment Remove the jogger fence HP sensor (front) (S15) [A]. Jogger Fence HP Sensor (Rear) (S16) Remove the paper exit cover (Paper Exit Cover). Remove the jogger fence HP sensor (rear) unit [A] ( ×1, ×1). Remove the jogger fence HP sensor (rear) (S16) [A].

  • Page 38: Stapler Tray Jam Sensor (S14)

    2.Replacement and Adjustment Stapler Tray Jam Sensor (S14) Remove the paper exit cover (Paper Exit Cover). Remove the paper exit roller unit [A] ( ×1). Remove the stapler tray jam sensor unit [A] ( ×1, ×1, ×1). Remove the stapler tray jam sensor (S14) [A] ( ×1).
  • Page 39 2.Replacement and Adjustment Remove the jogger fence motor (rear) bracket [A] ( ×2, ×3). Remove the paper sensor unit [A] ( ×1, ×1, ×1). Remove the paper sensor (S19) [A]. • When installing this sensor, be careful not to damage the sensor actuator.

  • Page 40: Motors

    2.Replacement and Adjustment Motors Entrance Motor (M10) Remove the internal finisher (Removing the Internal Finisher). Remove the finisher right rear bracket [A] ( ×2) Remove the rear cover [A] ( ×2). Remove the entrance motor (M10) [A] ( ×2, ×1, Timing belt×1).

  • Page 41: Tray Lift Motor (M15)

    2.Replacement and Adjustment Tray Lift Motor (M15) Remove the paper exit tray (Paper Exit Tray). Remove the tray lift motor unit [A] ( ×2, ×1, ×1). Remove the cam [A], bearing [B] ( ×1). Remove the tray lift motor (M15) [A] ( ×2).

  • Page 42: Paper Exit Guide Plate Motor (M12)

    2.Replacement and Adjustment Remove the stack height lever motor (M6) [A] ( ×2, ×1). Paper Exit Guide Plate Motor (M12) Remove the controller board (Controller Board (PCB1)). Remove the paper exit guide plate motor (M12) [A] ( ×2, ×1, ×1). Positioning Roller Motor (M14) Remove the paper exit cover (Paper Exit...

  • Page 43: Shift Motor (M11)

    2.Replacement and Adjustment Remove the rear rail [A]. Remove the positioning roller motor (M14) [A]. Shift Motor (M11) • After attaching, rotate the knob, and check that all gear trains can rotate. • After attachment, when the cam [A] is rotated, check that the link [B] interlocks. Remove the controller board bracket (Controller Board (PCB1)).
  • Page 44 2.Replacement and Adjustment Remove the pulley [A], timing belt [B] ( ×1). Remove the shift motor unit [A] ( ×2, ×1, ×1). Remove the shift motor (M11) [A] ( ×2).

  • Page 45: Stapler Retreat Motor (M13)

    2.Replacement and Adjustment Stapler Retreat Motor (M13) • When placing the finisher upside down, be careful not to deform the frame. Remove the paper exit cover (Paper Exit Cover). Release the four clamps ( ×4). Place the internal finisher upside down on the table while holding the parts shown below [A]. •...

  • Page 46: Jogger Fence Motor (Front) (M4), Jogger Fence Motor (Rear) (M5)

    2.Replacement and Adjustment Remove the stapler retreat motor (M13) [A]( ×2, ×1). Jogger Fence Motor (Front) (M4), Jogger Fence Motor (Rear) (M5) Remove the base cover (Stapler Retreat Motor (M13)). Remove the jogger fence motor (front) (M4) [A] ( ×2, ×1, Timing belt×1).

  • Page 47: Transport Motor (M8)

    2.Replacement and Adjustment Remove the jogger fence motor (rear) (M5) [A] ( ×2, ×1, Timing belt×1). • During re-assembly, check that the motor pulley has not separated from the timing belt. Transport Motor (M8) Remove the following parts. • Paper Exit Cover •...

  • Page 48: Paper Exit Motor (M9)

    2.Replacement and Adjustment Paper Exit Motor (M9) Remove the following parts. • Transport Motor (M8) • Controller Board Bracket Remove the gear [A] ( ×1). Remove the two clip rings [A] and shaft bracket [B] ( ×2). Remove the screws of the fan [A] and then lay it down ( ×2).
  • Page 49 2.Replacement and Adjustment Remove the paper exit motor (M9) [A] ( ×2, ×1).

  • Page 50: Stapler Unit

    2.Replacement and Adjustment Stapler Unit Remove the controller board bracket (Controller Board (PCB1)). Insert the stapler unit [A] into the rear. Pull the rear trailing edge fence and remove it. Remove the stapler home position sensor (Stapler Move HP Sensor (S12)).
  • Page 51 2.Replacement and Adjustment Move the stapler unit to the front, and remove the cartridge [A]. • During re-assembly, install the cartridge last. Remove the unit fixing screw of the stapler unit [A]. Remove the harnesses. Notes on Stapler Unit Installation If you install the stapler unit with the harness twisted, the unit may fail to move to the stapling position or the harness may be twisted or bent while moving.
  • Page 52 2.Replacement and Adjustment When you install the stapler unit, keep the following points in mind: Be sure not to twist the harness during installation. Make sure the bracket of the stapler unit is not snagged after installation.
