Ricoh D014 Service Manual page 805

Rev. 08/2008
1 1st Fold:A3 SEF
2 1st Fold:B4 SEF
3 1st Fold:A4 SEF
4 1st Fold:DLT SEF
5 1st Fold:LG SEF
6 1st Fold:LT SEF
7 1st Fold:12"x18"
8 1st Fold:Other
9 2nd Fold:A3 SEF
10 2nd Fold:B4 SEF
11 2nd Fold:A4 SEF
12 2nd Fold:DLT SEF
13 2nd Fold:LG SEF
14 2nd Fold:LT SEF
15 2nd Fold:12"x18"
16 2nd Fold:Other
6350 Input Check:Mail Box
Use these SP codes to perform the input checks for sensors and switches in
the mailbox.
1 Paper Detect Sn 1
2 Vert Transport Sn:Bin1
3 Paper Overflow Sn 1
SM
CÓPIA NÃO CONTROLADA
[-4 ~ +4/0/ 0.2 mm]
Refer to the illustration above.
Adjusts the position of the first fold [A] to
decrease or increase the distance A between
the leading edge [B] and the crease of the 2nd
fold [C].
[-4 ~ +4/0/ 0.2 mm]
Refer to the illustration above.
Adjusts the position of the 2nd fold [C] to
decrease or increase the length L1 of the
sheet between the trailing edge [D] and the
2nd fold.
9-Bin Mailbox B762
5-263
CÓPIA NÃO CONTROLADA
Group 6000
D014/D015/D078/D079
