  • Page 1 Leica TPS1200 Technical Reference Manual Version 5.5 English...
  • Page 2 The type and the serial number of your product are indicated on the type plate. Enter the type and serial number in your manual and always refer to this information when you need to contact your agency or Leica Geosystems authorized service workshop. Type: _________________________ Serial No.:...

  • Page 3: Table Of Contents

    Table of Contents In this manual Chapter Page Instrument Protection with PIN Configurable Keys Hot Keys USER Key Quick Settings - SHIFT USER Overview QUICK SET Change Settings to: Quick Setting Functions 3.3.1 Orientation With Compass 3.3.2 Positioning Hz/V 3.3.3 Move by Joystick 3.3.4 Check Recorded Point / Backsight Point...
  • Page 4 Table of Contents TPS1200 Programs... Manage... Convert... Config... Tools... Manage...\Jobs Overview Accessing Job Management Creating a New Job Editing a Job Managing Job Codes Manage...\Data Overview Accessing Data Management Point Management 6.3.1 Terminology 6.3.2 Creating a New Point 6.3.3 Editing a Point 6.3.4 Mean Page Line/Area Management...
  • Page 5 6.6.2 Point, Line and Area Code Filter 6.6.3 Stakeout Filter Manage...\Codelists Terminology Overview Accessing Codelist Management Creating/Editing a Codelist Managing Codes 7.5.1 Accessing MANAGE Codes 7.5.2 Creating a New Code 7.5.3 Editing a Code Managing Code Groups Coding Overview Thematical Coding 8.2.1 Thematical Coding with Codelist 8.2.2...
  • Page 6 Table of Contents TPS1200 8.6.1 Code Mismatch 8.6.2 Attribute Mismatch Linework Overview Performing Linework Combining Linework and Coding Manage...\Coordinate Systems 10.1 Overview 10.2 Terminology 10.3 Accessing Coordinate System Management 10.4 Coordinate Systems 10.4.1 Creating a New Coordinate System 10.4.2 Editing a Coordinate System 10.5 Transformations 10.5.1...
  • Page 7 10.8.2 Accessing Geoid Model Management 10.8.3 Creating a New Geoid Model from the CompactFlash Card / Inter- nal Memory 10.9 CSCS Models Manage...\Configuration Sets 11.1 Overview 11.2 Accessing Configuration Set Management 11.3 Creating a New Configuration Set 11.4 Editing a Configuration Set Manage...\Reflectors 12.1 Overview...
  • Page 8 Table of Contents TPS1200 Convert...\Copy Points Between Jobs Config...\Survey Settings... 16.1 ID Templates 16.1.1 Overview of Templates 16.1.2 Accessing ID Template Configuration 16.1.3 Creating a New ID Template 16.1.4 Editing an ID Template 16.1.5 Deleting an ID Template 16.1.6 Working Example 16.2 Display Settings 16.3...
  • Page 9 18.6 Start Up & Power Down Interfaces, Ports, Devices 19.1 Overall Concept 19.2 Interfaces 19.2.1 Overview of Interfaces 19.2.2 Accessing CONFIGURE Interfaces 19.3 Ports 19.4 Devices 19.4.1 Overview of Devices 19.4.2 Accessing CONFIGURE Devices / CONFIGURE GPRS Internet Devices 19.4.3 Creating a New Device 19.4.4 Editing a Device...

  • Page 10: Tps1200

    Table of Contents TPS1200 Config...\Interfaces... - Controlling The Device 21.1 Digital Cellular Phones 21.1.1 Overview 21.1.2 Configuring a GSM Connection 21.1.3 Configuring a CDMA Connection 21.2 Modems 21.3 Radios for GPS Real-Time 21.4 Radios for Remote Control 21.5 RS232 21.6 GPRS / Internet Devices 21.7 Internet...
  • Page 11 22.2 Point Occupation Settings 22.3 Satellite Settings 22.4 Local Time Zone 22.5 Quality Control Settings 22.6 Logging of Raw Obs Tools...\Format Memory Device Tools...\Transfer Objects... Tools...\Upload System Files... 25.1 Application Programs 25.2 System Languages 25.3 Instrument Firmware Tools...\Calculator 26.1 Overview 26.2 Accessing the Calculator 26.3...
  • Page 12 Table of Contents TPS1200 Tools...\File Viewer Tools...\Licence Keys Tools...\Check & Adjust 29.1 Overview 29.2 Details on Instrument Errors 29.3 Accessing Check & Adjust Menu 29.4 Configure Check & Adjust 29.5 Combined Adjustment (l, t, i, c and ATR) 29.6 Tilting Axis Adjustment (a) 29.7 Compensator Adjustment (l, t) 29.8...
  • Page 13 30.8.2 Real-Time Status 30.8.3 Current Position 30.9 Logging Status 30.9.1 SmartAntenna System Info Telescope Positioning Functions 32.1 32.2 Prism Search Methods 32.2.1 32.2.2 PowerSearch 32.3 Follow Moving Prisms - LOCK 32.4 32.5 32.6 Illumination NTRIP via Internet 33.1 Overview 33.2 Configuring SmartStation for Using NTRIP Service 33.2.1 Configuring an Access to the Internet...

  • Page 14: Tps1200

    Table of Contents TPS1200 34.4.2 Screen Area 34.4.3 Toolbar 34.4.4 Point Symbols 34.5 Map Mode 34.5.1 MapView in Map Mode 34.5.2 Selecting Points, Lines and Areas 34.6 Plot Mode - MapView Screen Area 34.7 Survey Mode 34.7.1 MapView in Survey Mode 34.7.2 MapView in Staking Out Survey Mode 34.7.3...
  • Page 15 36.6 COGO Calculation - Intersections Method 36.6.1 Intersection with Bearing - Bearing 36.6.2 Intersection with Bearing - Distance 36.6.3 Intersection with Distance - Distance 36.6.4 Intersection with By Points 36.6.5 Intersection with TPS Observation - TPS Observation 36.7 COGO Calculation - Line Calculations Method 36.7.1 Line Calculation - Base Point 36.7.2...

  • Page 16: Tps1200

    Table of Contents TPS1200 37.3 Configuring Determine Coordinate System 37.3.1 Configuring Determine Coordinate System - Normal 37.3.2 Configuring Determine Coordinate System - One Point Localisa- tion Determine Coordinate System - Normal 38.1 Overview 38.2 Determining a New Coordinate System 38.3 Updating a Coordinate System 38.4 Matching Points...
  • Page 17 40.2 Management of Antennas 40.2.1 Overview 40.2.2 Accessing Antenna Management 40.2.3 Creating a New Antenna 40.2.4 Editing an Antenna 40.2.5 Antenna Heights Hidden Point 41.1 Overview 41.2 Accessing Hidden Point 41.3 Configuring Hidden Point 41.4 Measuring Hidden Points Reference Line 42.1 Overview 42.2...
  • Page 18 Table of Contents TPS1200 42.7.1 Gridstaking the Points 1014 42.7.2 Working Example 1022 Reference Plane & Face Scan 1026 43.1 Overview 1026 43.2 Accessing Reference Plane 1031 43.3 Configuring Reference Plane 1034 43.4 Managing Reference Planes 1038 43.5 Measuring Points to a Reference Plane 1046 43.6 Scanning a Plane...
  • Page 19 45.4 Setup with SmartStation 1107 45.5 Setup with SmartPole 1111 45.6 Setup Methods 1115 45.6.1 Setup Reminder 1115 45.6.2 Set Azimuth 1117 45.6.3 Known Backsight Point 1125 45.6.4 Orientation and Height Transfer 1131 45.6.5 Resection/Resection Helmert 1137 45.6.6 Local Resection 1139 45.7 Setup Results...

  • Page 20: Tps1200

    Table of Contents TPS1200 47.2 Surveying Points 1201 Survey - Auto Points 1206 48.1 Overview 1206 48.2 Configuring Auto Points 1208 48.3 Auto Points 1217 48.4 Offset Points of Auto Points 1222 48.4.1 Overview 1222 48.4.2 Configuring Offset Points 1225 48.4.3 Working Example 1230...
  • Page 21 51.2 Accessing Traverse 1276 51.3 Configuring Traverse 1279 51.4 Traverse Methods 1283 51.4.1 Starting Traverse 1283 51.4.2 Measuring Traverse 1285 51.4.3 Closing Traverse 1287 51.5 Traverse Point Statistics 1291 51.6 Traverse Results 1293 Volume Calculations 1296 52.1 Overview 1296 52.2 Accessing Volume Calculations 1298 52.3...

  • Page 22: Tps1200

    GSA - GNSS DOP and Active Satellites 1358 F.10 GSV - GNSS Satellites in View 1360 F.11 LLK - Leica Local Position and GDOP 1362 F.12 LLQ - Leica Local Position and Quality 1364 F.13 RMC - Recommended Minimum Specific GNSS Data 1366 F.14...
  • Page 23 Table of Contents TPS1200...

  • Page 24: Instrument Protection With Pin

    Instrument Protection with PIN TPS1200 Instrument Protection with PIN Description • The instrument can be protected by a Personal Identification Number. • If the PIN protection is activated, the instrument will always prompt for a PIN code entry after starting up and before TPS1200 Main Menu comes up. •...
  • Page 25 TPS1200 Enter Security PIN Code OK (F4) To accept the PIN code and to continue with the subsequent screen. SHIFT QUIT (F6) To turn off the instrument. Description of fields Field Option Description PIN Code User input The PIN code as previously defined in CONFIGURE Start Up &...
  • Page 26 Instrument Protection with PIN TPS1200 IF the PIN code THEN entered is wrong refer to paragraph " TPS1200 Enter Security PIN Code Error: 479". wrong the fifth time the PUK code is required. Refer to paragraph " TPS1200 Enter Secu- rity PIN Code Error: 478".
  • Page 27 IF the PIN code THEN entered is wrong the fifth time the PUK code is required. Refer to paragraph " TPS1200 Enter Secu- rity PIN Code Error: 478". TPS1200 Enter Security PIN Code Error: 478 OK (F4) To continue with the subsequent screen. Next step OK (F4) to access TPS1200 Enter Security PUK Code.
  • Page 28 Description of fields Field Option Description PUK Code User input The PUK code as generated by Leica Geosystems. • For receivers delivered with firmware version 2.10 or higher, the PUK code comes with the receiver. • For receivers delivered with firmware versions lower than v2.10, contact a Leica representative...
  • Page 29 Next step IF the PUK code THEN entered is correct the old PIN code is cleared and the PIN protection is deactivated. TPS1200 Main Menu is displayed. Refer to "4 Main Menu". wrong GPS1200 keeps asking for the correct PUK code. SHIFT QUIT (F6) to turn off the receiver.

  • Page 30: Configurable Keys

    Configurable Keys TPS1200 Configurable Keys Hot Keys Description • Two levels of hot keys exist: • The first level are the keys F7, F8, ..., F12 • The second level is the combination of SHIFT and F7, F8, ..., F12 Functionality •...
  • Page 31 Step Description For User Menu select <1: CONF Coding & Linework Settings>. CONT (F1). CONT (F1). Press F7 to access CONFIGURE Coding & Linework. Press USER and 1 to access CONFIGURE Coding & Linework. Configurable Keys TPS1200...

  • Page 32: User Key

    Configurable Keys TPS1200 USER Key Description The USER key opens the user defined menu. User defined menu The user defined menu can be configured to contain the most used functions or application programs. The user defined menu can not be accessed while in a CONFIGURE XX screen. Refer to "18.2 Hot Keys &...
  • Page 33 Define USER key To define the USER key is the same as for the hot keys. Refer to paragraph "Define hot step-by-step key/user menu step-by-step". Configurable Keys TPS1200...

  • Page 34: Quick Settings - Shift User

    Quick Settings - SHIFT USER TPS1200 Quick Settings - SHIFT USER Overview Description Frequently used settings can be accessed quickly and changed with three key strokes. For example press SHIFT USER and 1 to turn the ATR on or off. The change is immediately applied and the screen where QUICK SET Change Settings to: was accessed from opens.

  • Page 35: Quick Set Change Settings To

    QUICK SET Change Settings to: Access Press SHIFT USER. QUICK SET The appearance of the QUICK SET Change Settings to: screen may change, depending Change Settings To: on whether the instrument is equipped with motorisation, ATR, reflectorless EDM or Power- Search.
  • Page 36 Quick Settings - SHIFT USER TPS1200 Description of fields Field Option Description Turn ON To activate ATR, <Automation: ATR>. Turn OFF To deactivate ATR, <Automation: None>. LOCK Unavailable for SmartStation. Turn ON To activate LOCK, <Automation: LOCK>. Turn OFF To deactivate LOCK, <Automation: None>. EDM Type Change to IR To activate measurements to reflectors, <EDM...
  • Page 37 Field Option Description PS Window Turn ON To activate the PowerSearch window, <PS Window: On>. Prisms are searched for with PowerSearch in the PS window when PS (F6) is pressed. Turn OFF To deactivate the PowerSearch window <PS Window: Off>. A 360° search is performed when PS (F6) is pressed.
  • Page 38 Quick Settings - SHIFT USER TPS1200 THEN the instrument is to COMPS (F1), Hz/V (F2) or JSTCK (F3) to access the subsequent be automatically screen. Refer to "3.3 Quick Setting Functions". turned to a specific position a point or the instru- CHKPT (F4) to access the QUICK SET Check Recorded Pt/Back- ment orientation is to sight Pt screen.

  • Page 39: Quick Setting Functions

    Quick Setting Functions 3.3.1 Orientation With Compass Description By using a conventional magnetic compass while remotely controlling the instrument, it is possible to determine the general direction towards which the instrument should turn in order to perform a target search to locate the prism. Access Press COMPS (F1) in the QUICK SET Change Settings to: screen.
  • Page 40 Quick Settings - SHIFT USER TPS1200 Step Description Refer to chapter Look through the telescope with <Hz: 0.0000 g> to select an object which is easily recognisable. Standing at the instrument point the compass to the selected object and turn the rotating dial until the "N" lines up with the north end of the compass needle.
  • Page 41 Step Description Refer to chapter CONT (F1) to access SURVEY Survey: Job Name. The instrument turns to the reflector. For <Automation: ATR> an ATR measurement is performed. If no prism was found, the instrument turns to the position typed in for <Hz- Compass:>...

  • Page 42: Positioning Hz/V

    Quick Settings - SHIFT USER TPS1200 3.3.2 Positioning Hz/V Description The QUICK SET Positioning Hz/V screen is used when the instrument is remote controlled and the telescope should be turned to a certain direction. On the Absolute page, angular values for <Hz-Angle:> and <V-Angle:> related to the set orientation can be typed in.
  • Page 43 Step Description <V-Angle:> Vertical direction for the instrument to turn to>. Continue with step 8. PAGE (F6) to access QUICK SET Positioning Hz/V, Relative page. QUICK SET Positioning Hz/V, Relative page <∆Hz:> Angular difference for the horizontal angle to turn to. <∆V:>...

  • Page 44: Move By Joystick

    Quick Settings - SHIFT USER TPS1200 3.3.3 Move by Joystick Description In QUICK SET Move by Joystick the instrument can be turned using the arrow keys on the keyboard of the instrument or the RX1200 or the arrow keys displayed on the touch screen. When QUICK SET Move by Joystick is accessed, the EGL is turned on automatically.
  • Page 45 Description of fields Field Option Description Speed Output Displays the rotating speed of the instrument. Press the same arrow key to change the speed from ----- to slow to medium to fast. Next step CONT (F1) to exit the QUICK SET Move by Joystick screen. Move by joystick step- The following table explains the most common settings.

  • Page 46: Check Recorded Point / Backsight Point

    Quick Settings - SHIFT USER TPS1200 3.3.4 Check Recorded Point / Backsight Point Description • The QUICK SET Check Recorded Pt/Backsight Pt screen is to check if a measured point is identical to a point already stored in the job or if the instruments orientation to a backsight point is still correct.
  • Page 47 MORE (F5) To display additional information. LAST (F6) To recall <Point ID:> of the last checked point. SHIFT POSIT (F4) To position to the selected point. For <Automation: ATR>, the instrument does an ATR search. For <Automation: LOCK> the instrument tries to lock on to a reflector.
  • Page 48 Quick Settings - SHIFT USER TPS1200 Step Description POSIT (F5) to position to the point. DIST (F2) to measure a distance. SETBS (F3) to set the station and orientation of the instrument by taking a single measurement to a known backsight point. CONT (F1) to return to the screen QUICK SET Change Settings to: was accessed from.

  • Page 49: L.go (F5)/L.int (F5)

    3.3.5 L.GO (F5)/L.INT (F5) L.GO (F5) When L.GO (F5) is pressed, an ATR search is performed, the instrument locks onto the reflector without a measurement. <Automation: LOCK> is set. Unavailable for Smart- Station. L.GO (F5) can be used to lock onto a prism located on an unstable surface for example on a boat or near to the instrument.

  • Page 50: Ps Powersearch

    Quick Settings - SHIFT USER TPS1200 3.3.6 PS PowerSearch Description When PS (F6) is pressed, the instrument searches for the prism with PowerSearch. Refer to "32.2.2 PowerSearch" for more information on the functionality of PowerSearch.

  • Page 51: Working Examples

    Working examples 3.4.1 Working Example 1 - ATR Description Application: Measure points with ATR. Working technique: Application program Survey. Goal: Find prism with ATR. Requirement <Automation: ATR>. Prism search with ATR Step Description step-by-step Press ALL(F1) in SURVEY Survey: Job Name. Press DIST (F2) to measure a distance.

  • Page 52: Working Example 2 - Lock

    Quick Settings - SHIFT USER TPS1200 3.4.2 Working Example 2 - LOCK Description Application: Measure points with LOCK. Working technique: Application program Survey. Goal: Find prism with LOCK activated. Requirement <Automation: LOCK>. This working example can also be applied if the instrument is remotely controlled by an RX1200.

  • Page 53: Working Example 3 - Loss Of Lock

    3.4.3 Working Example 3 - Loss of LOCK Description Application: Points were measured with LOCK until loss of lock. Working technique: Application program Survey. Goal: Prism search after loss of lock. Requirements • <Automation: LOCK> • The instrument is locked onto the prism. •...
  • Page 54 Quick Settings - SHIFT USER TPS1200 Step Description If no prism was found during prediction, a search is started depending on the setting of <Search with:> in CONFIGURE Automatic Prism Search • For <Search with: No Search>: No search is started. •...

  • Page 55: Working Example 4 - Ps

    3.4.4 Working Example 4 - PS Description Application: Search for a prism with PowerSearch. Working technique: Application program Survey. Goal: Find prism with PowerSearch. Requirement <PS Window: Off> Prism search with PS Step Description step-by-step QUICK SET Change Settings to: PS (F6).

  • Page 56: Main Menu

    Main Menu TPS1200 Main Menu Main Menu Functions Description The main menu is normally the first screen displayed when the instrument is switched on. If the PIN protection is active, TPS1200 Enter Security PIN Code is displayed first. After typing in the correct PIN code, the main menu is displayed. If desired, the instrument can be configured to start up with a user defined screen.
  • Page 57 Description of the main Main menu function Description Refer to menu functions chapter Survey • To start measuring. Programs... • To select and start application programs. Manage... • To manage jobs, data, codelists, configurations sets, reflectors and coordinate systems. Convert... •...
  • Page 58 Main Menu TPS1200 Main menu function Description Refer to chapter • To view files on the CompactFlash card or the internal memory. • To manually type in a licence key. • To calibrate the instrument.

  • Page 59: Survey

    Survey Access Select Main Menu: Survey. Description Survey provides the functionality used to perform the survey. SURVEY CONT (F1) Survey Begin To accept settings and to continue with screen SURVEY Survey: Job Name. CONF (F2) To configure auto point and remote point measurements functionality.

  • Page 60: Programs

    Main Menu TPS1200 Programs... Access Select Main Menu: Programs..Press PROG. Description Programs... accesses the application programs menu. The screen of the application programs menu is called TPS1200 Programs. TPS1200 The application programs menu contains all loaded application programs including Survey Programs and Setup.
  • Page 61 For Main Menu: Programs...\Alignment Tool Kit Refer to the separate manual For Main Menu: Programs...\COGO Refer to chapter 36 For Main Menu: Programs...\Determine Coordinate SystemRefer to chapter 37 For Main Menu: Programs...\GPS Survey Refer to chapter 40 For Main Menu: Programs...\Hidden Point Refer to chapter 41 For Main Menu: Programs...\MGuide Refer to the separate manual...

  • Page 62: Manage

    Main Menu TPS1200 Manage... Access Select Main Menu: Manage..Description Manage... is used to manage the following: • jobs. • data. • codelists. • coordinate systems. • configuration sets. • reflectors. Management functions include creating, selecting, editing and deleting. TPS1200 Management CONT (F1) To select the highlighted option and to continue...
  • Page 63 Next step For Main Menu: Manage...\Jobs Refer to chapter 5. For Main Menu: Manage...\Data Refer to chapter 6. For Main Menu: Manage...\Codelists Refer to chapter 7. For Main Menu: Manage...\Coordinate Systems Refer to chapter 10. For Main Menu: Manage...\Configuration Sets Refer to chapter 11.

  • Page 64: Convert

    Main Menu TPS1200 Convert... Access Select Main Menu: Convert..Description Convert... provides access to data exchange options. TPS1200 Convert Data CONT (F1) To select the highlighted option and to continue with the subsequent screen. Next step For Main Menu: Convert...\Export Data from Job Refer to chapter 13.

  • Page 65: Config

    Config... Access Select Main Menu: Config..Press USER and then CONF (F2). Description Config... accesses all configuration parameters related to a survey, the instrument, the inter- faces and SmartStation. Any changes made are stored in the configuration set. TPS1200 Configuration: Configuration Set CONT (F1) To select the highlighted option and to continue...

  • Page 66: Tools

    Main Menu TPS1200 Tools... Access Select Main Menu: Tools..Description Tools... provides functionality which is not directly related to surveying data. TPS1200 Tools Menu CONT (F1) To select the highlighted option and to continue with the subsequent screen. Next step For Main Menu: Tools...\Format Memory Device Refer to chapter 23 For Main Menu: Tools...\Transfer Objects...
  • Page 67 Main Menu TPS1200...

  • Page 68: Overview

    Manage...\Jobs TPS1200 Manage...\Jobs Overview Description Jobs • structure surveying projects. • contain all points, lines, areas and codes that are recorded and stored. • can be downloaded to LGO for post-processing or for data transfer to a further program. • can be uploaded from LGO, for example, for stakeout operations.

  • Page 69: Manage

    Accessing Job Management Access Select Main Menu: Manage...\Jobs. Press a hot key configured to access the screen MANAGE Jobs (Device). Refer to "2.1 Hot Keys" for information on hot keys. Press USER. Refer to "2.2 USER Key" for information on the USER key. From a choicelist in some screens, e.g.
  • Page 70 Manage...\Jobs TPS1200 DATA (F5) To view, edit and delete points, lines and areas stored with the job. Points, lines and areas are shown on separate pages. Selected sort and filter settings apply. Refer to "6.3 Point Management". CFCRD (F6) or INTL (F6) Available for instruments with internal memory.

  • Page 71: Creating A New Job

    Creating a New Job Access Refer to "5.2 Accessing Job Management" to access MANAGE Jobs (Device). Create job step-by-step The following table explains the most common settings. Refer to the stated chapter for more information on screens. Step Description Refer to chapter In MANAGE Jobs (Device) highlight a job.
  • Page 72 Manage...\Jobs TPS1200 Step Description Refer to chapter MANAGE New Job, General page <Name:> A unique name for the new job. The name may be up to 16 characters long and may include spaces. Input required. <Description:> Two lines for a detailed description of the job. This can be for example, work to be performed or the classes contained in the job.
  • Page 73 Step Description Refer to chapter In order to check measurements, the same point can be measured 6.3.4 more than once. If activated, an average or an absolute difference is calculated. <Averaging Mode:> Defines the averaging principles for multiple measured points. <Averaging Mode: Average> computes the average for the position and the height.
  • Page 74 Manage...\Jobs TPS1200 Step Description Refer to chapter <Points to Use:> The type of points which will be taken into account for absolute differences. From <Easting:> to <Cartesian Z:> The acceptable absolute differences for each coordinate component. • For <Averaging Mode: Off>: No other fields are available.

  • Page 75: Editing A Job

    Editing a Job Access Refer to "5.2 Accessing Job Management" to access MANAGE Jobs (Device). Edit job step-by-step The following table explains the most common settings. Refer to the stated chapter for more information on screens. Step Description Refer to chapter In MANAGE Jobs (Device) highlight a job to be edited.
  • Page 76 Manage...\Jobs TPS1200 Step Description Refer to chapter • If no, continue with step 6. • If yes, continue with step 8. No codes are stored in the job. MANAGE Edit Job: Job Name, Codelist page <Codelist: <None>> This default setting can be changed. Choosing a codelist copies the codes to the job.
  • Page 77 Step Description Refer to chapter The functionality on this page is identical with the creation of a new PAGE (F6) changes to the Avge page. MANAGE Edit Job: Job Name, Avge page The functionality on this page is identical with the creation of a new job.

  • Page 78: Managing Job Codes

    Manage...\Jobs TPS1200 Managing Job Codes Description To view, edit, group and sort all codes currently stored in the job. The functionality of this screen is mainly the same as for MANAGE Codes. For simplicity, the functionality which is different from MANAGE Codes is explained here. Refer to "7.5 Managing Codes" for infor- mation on MANAGE Codes.

  • Page 79: Manage

    MANAGE Job Codes CONT (F1) To return to MANAGE Edit Job: Job Name, Codelist page. NEW (F2) To create a new code. Refer to "7.5.2 Creating a New Code". EDIT (F3) To edit the highlighted code. Accesses MANAGE Edit Code where new attributes can be added to a code and line styles can be changed.
  • Page 80 Manage...\Jobs TPS1200 Next step THEN the job codes do not CONT (F1) closes the screen and returns to the screen from where need to be changed MANAGE Job Codes was accessed. a new job code is to NEW (F2). Refer to "7.5.2 Creating a New Code". be created an existing job code highlight the job code and EDIT (F3).
  • Page 81 Type of code Description Point codes • New attributes can be added with NEW-A (F2). Free codes Line codes • New attributes can be added with NEW-A (F2). • The line style can be changed. This new line style is stored to the Area codes code.

  • Page 82: Overview

    Manage...\Data TPS1200 Manage...\Data Overview Description • Data is a generic term for points, lines and areas. • Data management is the administration of data stored in the active job. This includes • viewing data with their related information. • editing data. •...

  • Page 83: Accessing Data Management

    Accessing Data Management Access Select Main Menu: Manage...\Data. Press a hot key configured to access the screen MANAGE Data: Job Name. Refer to "2.1 Hot Keys" for information on hot keys. Press USER. Refer to "2.2 USER Key" for information on the USER key. From a choicelist in some screens for example in application programs.
  • Page 84 Manage...\Data TPS1200 MANAGE Data: Job Name, Points page CONT (F1) To close the screen and return to the screen from where this screen was accessed. NEW (F2) To create a point. EDIT (F3) To edit the highlighted point. DEL (F4) To delete the highlighted point.
  • Page 85 Next step THEN a point is to be highlight the point and NEW (F2). Refer to "6.3.2 Creating a New created Point". a point is to be highlight the point and EDIT (F3). Refer to "6.3.3 Editing a Point". edited a line/area is to be PAGE (F6) changes to the Lines (X) and Areas (X) page.
  • Page 86 Manage...\Data TPS1200 MORE (F5) To display information about the codes if stored with any line/area, the start time, the end time of when the last point was added to the line/area, the length of the line, the perimeter and the area of the area. PAGE (F6) To change to another page on this screen.
  • Page 87 Next step IF the line/area THEN management is CONT (F1) closes the screen and returns to the screen from where completed this screen was accessed. is to be opened highlight the line/area and OPEN (F4). which was last used press a hot key configured to re-open last used line/area. This hot key is to be opened can be used at any time.

  • Page 88: Point Management

    Manage...\Data TPS1200 Point Management 6.3.1 Terminology Description • This chapter describes technical terms related to data management. Coordinate triplet • A measured point consists of three coordinate components - two horizontal components and one vertical component. The generic term for the three coordinate components is coordinate triplet.
  • Page 89 Class Characteristic Description • Reference point received by a real-time rover. Instrument source TPS, GPS or LGO. Number of triplets One. AVGE Type Averaged point calculated when more than one coordinate triplet of class MEAS exist for the same point ID unless <Averaging Mode: Off>. Instrument source TPS or GPS.
  • Page 90 Manage...\Data TPS1200 Class Characteristic Description Instrument source LGO. Possible number of One. triplets NONE Type Measured points with angles. Instrument source TPS. Possible number of Unlimited. triplets Sub class The sub class describes certain classes in detail. It indicates the status of the position when a coordinate triplet was measured and how the coordinates were determined.
  • Page 91 Sub class Description Instrument source GPS Fixed Direct coordinate determination with phase fixed solution. GPS Float Direct coordinate determination with autonomous solution coming from LGO. Hidden Point Indirect coordinate determination with hidden GPS or TPS point measurements. Additional sub classes for SmartStation with the ATX1230 GG antenna: GNSS Code Only Direct coordinate determination with code solu- tion.
  • Page 92 Manage...\Data TPS1200 Source Originated Instrument from application program/functionality source Arc Segmt Pt COGO, Arc Calculation - Segmentation GPS or TPS Backward Brg-Dist Hidden point measurements, Backward Bearing and Distance Bearing-Distance Hidden point measurements, Bearing and Distance Chainage-Offset Hidden point measurements, Chainage and Offset GPS COGO Area Divsn.
  • Page 93 Source Originated Instrument from application program/functionality source LandXML Design to Field in LGO converting data from LandXML software to be used in the field Line Base Pt COGO, Line Calculation - Base Point GPS or TPS Line Offset Pt COGO, Line Calculation - Offset Point GPS or TPS Line Segmt Pt COGO, Line Calculation - Segmentation...
  • Page 94 Manage...\Data TPS1200 Source Originated Instrument from application program/functionality source Srvy Auto Offset Survey Auto Points, automatically recorded with GPS or TPS offsets Stakeout Stakeout GPS or TPS Survey Survey, measured Survey (Auto) Survey Auto Points, automatically recorded Survey (Event) Survey, Event input Survey (Instant) Survey, measured with <Pt Occupation: Instan- taneous>...
  • Page 95 Coordinate quality Description The Coordinate Quality is an indicator for the estimated quality of the point coordinates. The coordinate quality of the measurements is used in point averaging. Column Description Est 3D CQ Estimated 3D coordinate quality of computed position. Est 2D CQ Estimated plan coordinate quality of computed position.
  • Page 96 Manage...\Data TPS1200 Standard deviation of distance measurement σ Standard deviation of distance measure- σ + ppm * D ment. Constant part of EDM accuracy. ppm part of EDM accuracy. TPS12_077 Slope Distance. 1D estimated coordinate quality 1D CQ = σ V + σ...
  • Page 97 Working Example 1 Instrument: TXA1202 Angular accuracy: 2" = 6.1728*10 gon => σHz,V = 2"* EDM accuracy: 2 mm + 2 ppm for an IR measurement Slope distance: 150 m 210 gon 83 gon 1D CQ = 0.00207 m 2.1 mm 2D CQ = 0.00303 m 3.0 mm 3D CQ = 0.00367 m...

  • Page 98: Creating A New Point

    Manage...\Data TPS1200 6.3.2 Creating a New Point Access Refer to "6.2 Accessing Data Management" to access MANAGE Data: Job Name. Create point The following table explains the most common settings. Refer to the stated chapter for more step-by-step information on screens. Step Description Refer to...
  • Page 99 Step Description Refer to chapter NORTH (F3) or SOUTH (F3). Available for local geodetic or WGS 1984 geodetic coordinates when <Local Lat:> or <WGS 1984 Lat:> is highlighted. Changes between North and South latitude. EAST (F3) or WEST (F3). Available for local geodetic or WGS 1984 geodetic coordinates when <Local Long:>...
  • Page 100 Manage...\Data TPS1200 Step Description Refer to chapter • For <Thematc Codes: Without Codelist>: Codes for points can be typed in but not selected from a codelist. <Point Code:> The code to be stored with the point. A check is performed to see if a point code of this name already exists in the job.
  • Page 101 Step Description Refer to chapter Class: CTRL Sub class: Fixed (Pos & Ht) Source: User Entered Instrument source: TPS It may happen that a point with the same point ID exists in the job. If the codes and/or attribute values of the new and the existing point do not match, a screen opens where they can be corrected.

  • Page 102: Editing A Point

    Manage...\Data TPS1200 6.3.3 Editing a Point Access Refer to "6.2 Accessing Data Management" to access MANAGE Data: Job Name. Edit point step-by-step The following table explains the most common settings. Refer to the stated chapter for more information on screens. Step Description Refer to...
  • Page 103 Step Description Refer to chapter SHIFT ELL H (F2) or SHIFT ORTH (F2). Available for local coordi- nates. Change between the option to enter an ellipsoidal or an ortho- metric height. Changing the height type does not edit the point. Is <Class: MEAS>? •...
  • Page 104 Manage...\Data TPS1200 Step Description Refer to chapter The name of the real-time reference station from where the GPS point was measured, the name of antenna used to measure the point and the baseline values are shown in output/observations fields. MORE (F5) Available for TPS points. Displays the horizontal angle or the azimuth from the point to the instrument.
  • Page 105 Step Description Refer to chapter NAME (F3) or VALUE (F3) Available for attributes for which an attribute name can be typed in. To highlight <Attribute n:> or the field for the attribute value. The name of <Attribute n:> can be edited and an attribute value can be typed in.
  • Page 106 Manage...\Data TPS1200 Step Description Refer to chapter PAGE (F6) changes to the Mean page. MANAGE Edit Point: Point ID, Mean page 6.3.4 All points of <Class: MEAS> of the same point ID are listed sorted by time. The settings in the Use column can be edited. All functionality and keys are explained in a separate section.

  • Page 107: Mean Page

    6.3.4 Mean Page Description • In order to check measurements, the same point can be measured more than once. These measured points are assigned the class MEAS. The various measured coordinate triplets for one point can be recorded using the same point ID. If the averaging mode is activated, an average is calculated when more than one measured coordinate triplet is available for the same point ID.
  • Page 108 Manage...\Data TPS1200 Description of averaging modes Averaging Description mode Average When more than one measured coordinate triplet is recorded for the same point, the average for the position and the height is computed. Depending on the selected averaging method, the average will be computed weighted or arithmetic (no weighting).
  • Page 109 <Averaging Mode: Average> or <Averaging Mode: Absolute Diffs> is configured in MANAGE New Job, Avge page or in MANAGE Edit Job: Job Name, Avge page. more than one measured coordinate triplet is recorded for the same point using the same point ID.
  • Page 110 Manage...\Data TPS1200 MANAGE All measured coordinate triplets recorded using the same point ID are shown. Edit Point: Point ID, Mean page STORE (F1) To store the changes and to return to the screen from where this screen was accessed. USE (F2) To change between the options in the Use column for the highlighted coordinate triplet.
  • Page 111 DEL (F4) To delete the highlighted coordinate triplet. The average is recomputed. MORE (F5) To change between time and date of when the point was stored and the 3D coordinate quality. PAGE (F6) To change to another page on this screen. SHIFT DIFFS (F5) Available for <Averaging Mode: Absolute Diffs>...
  • Page 112 Manage...\Data TPS1200 Column Description • The coordinate triplet is never included in the averaging computation. • ----- The coordinate triplet cannot be included in the averaging computation. Automatically set by the system. USE (F2) changes between the options. Time The time the measured coordinate triplet was stored. Date The date the measured coordinate triplet was stored.
  • Page 113 Next step IF a measured THEN coordinate triplet is not to be viewed STORE (F1) stores the changes and returns to MANAGE Data: Job Name. is to be viewed highlight a measured coordinate triplet and EDIT (F3). Manage...\Data TPS1200...

  • Page 114: Line/Area Management

    Manage...\Data TPS1200 Line/Area Management 6.4.1 Overview Description A line/area consists of points and can be created/edited in MANAGE Data: Job Name. The individual points are measured within any application program. These can be all points. Points can be simultaneously assigned to one or more lines and/or areas. A line/area can have •...

  • Page 115: Creating A New Line/Area

    6.4.2 Creating a New Line/Area The functionality of all screens and fields are similar for the creation of both lines and areas. The step-by-step instructions for creating a new line can be applied for areas. Access Refer to "6.2 Accessing Data Management" to access MANAGE Data: Job Name. Press a hot key configured to access the screen MANAGE New Line/MANAGE New Area.
  • Page 116 Manage...\Data TPS1200 Step Description Refer to chapter <Pts to Store:> The type of points which are used to form the line 48.1, 48.4 during a survey. Select between all points, measured points, auto points and offset points of type 1 or 2. <Line Style:>...
  • Page 117 Step Description Refer to chapter • For <Thematc Codes: Without Codelist>: Codes for lines can be typed in but not selected from a codelist. <Line Code:> The line code to be stored with the point. A check is performed to see if a line code of this name already exists in the job.
  • Page 118 Manage...\Data TPS1200 Step Description Refer to chapter The value for <Start Time:> with which the line is stored is the time 6.4.3 when STORE (F1) was pressed. The same value is assigned to the value for <End Time:> until a point is added to the line. Any existing lines and areas which are open are closed.

  • Page 119: Editing A Line/Area

    6.4.3 Editing a Line/Area The functionality of all screens and fields are similar for the editing of both lines and areas. The step-by-step instructions for editing a new line can be applied for areas. Access Refer to "6.2 Accessing Data Management" to access MANAGE Data: Job Name. Edit line step-by-step The following table explains the most common settings.
  • Page 120 Manage...\Data TPS1200 Step Description Refer to chapter <Start Time:> and <Start Date:> The time/date when the line was created. A line cannot be renamed to an already existing line ID. MORE (F5) displays <End Time:> and <End Date:>. This is the time/date when the last point was added to the line.
  • Page 121 Step Description Refer to chapter PAGE (F6) changes to the Code page. MANAGE Edit Line: Line ID, Code page The line code can be edited. All line codes can be selected. For <Line Code: <None>>, the line style can be changed. The description of the code is shown as an output field.

  • Page 122: Working Example

    Manage...\Data TPS1200 6.4.4 Working Example Description Application: Pick up points along fence lines with a gate. The gate can also be represented as a line. Some points belong to more than one line. Setting: F7 is configured to access the MANAGE Data: Job Name screen.
  • Page 123 Step Description Refer to chapter Start Survey application program. 47.1 Press F7. MANAGE Data: Job Name, Lines (X) page The line F1 must be open, the lines F2 and G1 must be closed. To open/close a line, highlight the line and CLOSE (F4) and OPEN (F4).
  • Page 124 Manage...\Data TPS1200 Step Description Refer to chapter Measure P1. This point is automatically added to all three lines open at that time. Press F7. MANAGE Data: Job Name, Lines (X) page Highlight the line F1. CLOSE (F4) to close the line. Highlight the line F2.

  • Page 125: Data Log

    Data Log Description A list of all objects and free codes in the active job is displayed in order of time. Access step-by-step Access within data management Step Description Refer to "6.2 Accessing Data Management" to access MANAGE Data: Job Name. In MANAGE Data: Job Name on the Points page, SHIFT LOG (F4) to access MANAGE Data Log: Job Name.
  • Page 126 Manage...\Data TPS1200 Access by user defined menu Press USER. Refer to "2.2 USER Key" for information on the USER key. MANAGE In the column Data Record, all points, lines and areas as well as free codes stored within Data Log: Job Name the active job are displayed.
  • Page 127 MORE (F5) To display information about the type of data recorded, the time and the date of when it was stored or for lines and areas when they were created and the codes if stored with any object. Next step CONT (F1) returns to the screen from where MANAGE Data Log: Job Name was accessed.

  • Page 128: Point Sorting And Filters

    Manage...\Data TPS1200 Point Sorting and Filters 6.6.1 Sorting and Filters for Points, Lines and Areas Description The sort settings define the order of the objects in the active job. The filter settings define the objects to be viewed. Three types of filters are available: Point filter: An active point filter shows selected points in MANAGE Data: Job Name, Points page.
  • Page 129 Step Description In MANAGE Data: Job Name on the Points, Lines or Areas page, SHIFT FILT (F5) to access MANAGE Sorts & Filters. MANAGE Sorts & Filters This screen consists of three pages, one for each type of object. The page for an object is displayed when the equivalent page is displayed in MANAGE Data: Job Name.
  • Page 130 Manage...\Data TPS1200 Description of fields Field Option Description <Sort:> Ascend Point ID, Always available. The method points are Descend Point ID, sorted by. Forward Time or Backward Time <Filter:> Always available. The method the points are filtered by. No Filter Shows all points.
  • Page 131 Field Option Description Point Code Shows points with selected codes attached. Refer to "6.6.2 Point, Line and Area Code Filter". Radius From Pt Shows points within the defined radius from a particular point. The radius is the horizontal distance. Individual Line Shows points forming a selected line.
  • Page 132 All Triplets All classes for one coordinate triplet are shown. <Instrument:> All, TPS, GPS, Available for <Filter: Instrument>. Points LEICA Geo Office, originating from this instrument type are Level, Data Logger, shown. Third Party SW or Unknown <Type:> WGS84 Only or Available for <Filter: Coordinate Type>.
  • Page 133 Field Option Description <Point ID:> Choicelist Available for <Filter: Radius From Pt>. The point to which the radius is applied. Opening the choicelist opens MANAGE Data: Job Name. Refer to "6.2 Accessing Data Manage- ment". <Radius:> User input Available for <Filter: Radius From Pt>. The radius of the circle within which the points are shown.
  • Page 134 Manage...\Data TPS1200 MANAGE Sorts & Filters, Lines page CONT (F1) To close the screen and return to the screen from where this screen was accessed. The selected sort and filter settings are applied and the lists in MANAGE DATA: Job Name are updated.
  • Page 135 Field Option Description Code/Code Group Shows lines with selected codes attached. Refer to "6.6.2 Point, Line and Area Code Filter" since the functionality is identical to the point code filter. Next step PAGE (F6) changes to the Areas page. Refer to paragraph "MANAGE Sorts & Filters, Areas page".
  • Page 136 Manage...\Data TPS1200 Next step CONT (F1) returns to the screen from where MANAGE Sorts & Filters was accessed.

  • Page 137: Point, Line And Area Code Filter

    6.6.2 Point, Line and Area Code Filter For each object, a code filter exists. The point, line and area code filters are independent from each other. The functionality is identical. For simplicity, the point code filter is explained. Access step-by-step Step Description Refer to "6.6.1 Sorting and Filters for Points, Lines and Areas"...
  • Page 138 Manage...\Data TPS1200 USE (F5) To activate and deactivate the filter for the highlighted code. NONE (F6) or ALL (F6) To deactivate or activate all point codes. SHIFT SORT (F5) To define the order of the codes. Accesses MANAGE Sort Codes.

  • Page 139: Stakeout Filter

    6.6.3 Stakeout Filter Description The settings on this screen define a filter for the Stakeout application program, for example to show points which are already staked or points that are still to be staked. The stakeout filter acts in addition to any other filter set in MANAGE Sorts & Filters. For example, points still to be staked out with a particular code can be filtered.
  • Page 140 Manage...\Data TPS1200 Description of fields Field Option Description <View:> Shows all points. Pts to Shows points not yet staked out. Stakeout Staked Points Shows points which are already staked out.
  • Page 141 Manage...\Data TPS1200...

  • Page 142: Terminology

    Manage...\Codelists TPS1200 Manage...\Codelists Terminology Description This chapter describes technical terms related to codes and codelists. The values for code groups, codes and attributes are case sensitive. For example the code group Tree is not the same as the code group TREE. Object For coding, points, lines and areas have the same behaviour.
  • Page 143 Structure of codes Codes Thematical codes: Free codes: Object related information recorded Time related information recorded together with the actual object in the field. between objects in the field. A time stamp is recorded with each free code. It allows to export free codes and objects in a chronological order to be used for third party mapping software.
  • Page 144 Manage...\Codelists TPS1200 Code types The code type defines how and for which objects a code can be used. It is possible to create a code of the same name but of different code types both on the instrument and in LGO. Example: The code Oak can exist with code type point code and with code type line code.
  • Page 145 Structure of attributes Attributes Attribute type: Normal Mandatory Fixed Attribute value type: Text Real Integer Attribute value region: Attribute value region: None Choicelist None Choicelist Range Manage...\Codelists TPS1200...
  • Page 146 Manage...\Codelists TPS1200 Attribute types The attribute type defines the input requirements for the attribute. Normal: An input for the attribute is optional. The attribute value can be typed in in the field. New attributes with this attribute type can be created in LGO or on the instrument.
  • Page 147 Range: An input for the attribute must fall within a predefined range. New attributes with this attribute value region can be created in LGO. Choicelist: An input for the attribute is selected from a predefined list. New attributes with this attribute value region can be created in LGO. Example Code Attributes...
  • Page 148 Manage...\Codelists TPS1200 Structure of a codelist Structure Example Codelist Codelist |—— Code group 1 |—— Trees |—— Code 1.1 |—— Birch |—— Attribute 1.1.1 |—— Height |—— Attribute ... |—— Condition |—— Attribute 1.1.20 |—— Remark |—— Code 1.2 |—— Oak |——...

  • Page 149: Overview

    Overview It is recommended to create a codelist in LGO. A codelist can be transferred from LGO to the System RAM of the instrument using the CompactFlash card. Steps from creating to Codelist Tools: Transfer Instrument using a codelist Management: Create Serial Compact-...

  • Page 150: Accessing Codelist Management

    Manage...\Codelists TPS1200 Accessing Codelist Management Access Select Main Menu: Manage...\Codelists. From a choicelist in some screens, for example MANAGE New Job, Codelist page. MANAGE Listed are all codelists stored in the System RAM. Codelists CONT (F1) To return to the screen from where this screen was accessed.
  • Page 151 Next step IF a codelist THEN is to be selected highlight the desired codelist. CONT (F1) copies the codes of the codelist to the active job, closes the screen and returns to the screen from where MANAGE Codelists was accessed. is to be created NEW (F2).

  • Page 152: Creating/Editing A Codelist

    Manage...\Codelists TPS1200 Creating/Editing a Codelist Access Refer to "7.3 Accessing Codelist Management" to access MANAGE Codelists. Create/edit a codelist The following table explains the most common settings. Refer to the stated chapter for more step-by-step information on screens. Step Description Refer to chapter MANAGE Codelists...

  • Page 153: Managing Codes

    Managing Codes 7.5.1 Accessing MANAGE Codes Description Managing codes includes • creating new codes • viewing codes with their related information • editing codes. • deleting existing codes. Access step-by-step Step Description Refer to "7.3 Accessing Codelist Management" to access MANAGE Codelists. In MANAGE Codelists highlight the codelist of which codes are to be managed.
  • Page 154 Manage...\Codelists TPS1200 The indicates codes which have attributes attached. CONT (F1) To close the screen and return to the screen from where this screen was accessed. NEW (F2) To create a new code. Refer to "7.5.2 Creating a New Code". EDIT (F3) To edit the highlighted code.
  • Page 155 Next step THEN a code is to be NEW (F2). Refer to "7.5.2 Creating a New Code". created a code is to be edited highlight the code and EDIT (F3). Refer to "7.5.3 Editing a Code". code groups are to SHIFT GROUP (F4).

  • Page 156: Creating A New Code

    Manage...\Codelists TPS1200 7.5.2 Creating a New Code Create a new code step- The following table explains the most common settings. Refer to the stated chapter for more by-step information on screens. Step Description Refer to chapter Refer to "7.5.1 Accessing MANAGE Codes" to access MANAGE Codes.
  • Page 157 Step Description Refer to chapter • None: Select this option to disable the functionality. All other code settings on the instrument are not affected when this option is set. • Begin Line: When a point code is newly selected, a new line is opened and the point being stored is added to the line.
  • Page 158 Manage...\Codelists TPS1200 Step Description Refer to chapter STORE (F1) adds the new code and any associated attributes to the System RAM codelist and returns to the screen from where this screen was accessed. A new code can also be created within an application program. In this case, the new code is added to the job codelist.

  • Page 159: Editing A Code

    7.5.3 Editing a Code Access step-by-step Step Description Refer to "7.5.1 Accessing MANAGE Codes" to access MANAGE Codes. EDIT (F3) to access MANAGE Edit Code. All following steps are identical with the creation of a new code. Refer to "7.5.2 Creating a New Code". Follow the instructions in paragraph "Create a new code step-by-step"...

  • Page 160: Managing Code Groups

    Manage...\Codelists TPS1200 Managing Code Groups Access step-by-step Step Description Refer to "7.5.1 Accessing MANAGE Codes" to access MANAGE Codes. SHIFT GROUP (F4) to access MANAGE Code Groups. MANAGE The listed code groups belong to Code Groups the selected System RAM codelist when this screen was accessed through Main Menu: Manage...\Codelists.
  • Page 161 USE (F5) To activate and deactivate the highlighted code group. Codes belonging to a deactivated code group are not displayed in MANAGE Codes. NONE (F6) or ALL (F6) To deactivate or activate all code groups. Description of columns Column Description Code Group The name of the code group.

  • Page 162: Coding

    Coding TPS1200 Coding Overview Description A code is a description which can be stored with a point, line, area or alone. Coding on TPS1200 is very flexible with thematical, free and quick coding being available. Thematical and free coding is possible by selecting codes from a codelist or by directly typing in codes.
  • Page 163 Coding Characteristic Description method Recording of the Together with the objects. codes Free To store a description independent of an object at any time. A free code can be used to store a descrip- tion related to an object or to store additional descriptions such as the job name or the tempera- ture.
  • Page 164 Coding TPS1200 Coding Characteristic Description method Selection of the codes Shortcuts must be assigned to codes in the job codelist. <Quick Code: On> must be set in CONFIGURE Coding & Linework. Typing the shortcut searches for the assigned code and initiates a measurement.

  • Page 165: Thematical Coding

    Thematical Coding 8.2.1 Thematical Coding with Codelist Thematical coding of points with a codelist is explained in this chapter. Refer to "6.4 Line/Area Management" for information on coding lines/areas. Requirements • The job codelist contains thematical codes. • <Thematc Codes: With Codelist> in CONFIGURE Coding & Linework. •...
  • Page 166 Coding TPS1200 MANAGE Select Code CONT (F1) To return to the screen from where this screen was accessed. NEW (F2) To create a new code. Refer to "7.5.2 Creating a New Code". ATRIB (F3) Available unless accessed from MANAGE New Point/Line/Area or MANAGE Edit Point/Line/Area.
  • Page 167 Thematical coding with The following table explains the most common settings. Refer to the stated chapter for more codelist step-by-step information on screens. Step Description Refer to chapter Refer to paragraph "Access" to access XX Select Point Code. MANAGE Select Point Code All point codes from the job codelist which belong to the active code groups are available for selection.
  • Page 168 Coding TPS1200 Step Description Refer to chapter NAME (F3) or VALUE (F3) Available for attributes for which an attribute name can be typed in. To highlight <Attribute n:> or the field for the attribute value. Attributes of type mandatory or fixed and of value type real or integer online help must be created in LGO.

  • Page 169: Thematical Coding Without Codelist

    8.2.2 Thematical Coding without Codelist Thematical coding without codelist for points is explained in this chapter. Refer to "6.4 Line/Area Management" for information on coding lines/areas. Requirements • <Thematc Codes: Without Codelist> in CONFIGURE Coding & Linework. • A display mask with an input field for point codes must be configured. Access A thematical code is typed in the field <Code:>...
  • Page 170 Coding TPS1200 Step Description <Point ID:> The identifier for the point for which codes and attribute values are to be typed in. <Point Code:> The name for the code. <Attribute n:> The attribute values for the code. Type in a code and attribute values. Up to eight attributes can be added.

  • Page 171: Free Coding

    Free Coding 8.3.1 Free Coding Using a Codelist In this chapter, free coding using a codelist is explained for points. Refer to "6.4 Line/Area Management" for information on coding lines/areas. Requirements • The job codelist contains free codes. • A hot key is configured to access the screen FREECODE Select Free Code or the user defined menu is configured to display the option Select Free Code.
  • Page 172 Coding TPS1200 FREECODE Select Free Code STORE (F1) To store the free code and any associated attribute values and to return to the screen from where this screen was accessed. NEW (F2) To create a new code. Refer to "7.5.2 Creating a New Code".
  • Page 173 Free coding using a The following table explains the most common settings. Refer to the stated chapter for more codelist step-by-step information on screens. Step Description Refer to chapter Refer to paragraph "Access" to access FREECODE Select Free Code. FREECODE Select Free Code All free codes from the job codelist which belong to the active code groups are available for selection.
  • Page 174 Coding TPS1200 Step Description Refer to chapter NAME (F3) or VALUE (F3) Available for attributes for which an attribute name can be typed in. To highlight <Attribute n:> or the field for the attribute value. Attributes of type mandatory or fixed and of value type real or integer online help must be created in LGO.

  • Page 175: Free Coding With Direct Input

    8.3.2 Free Coding with Direct Input In this chapter, free coding with direct input is explained for points. Refer to "6.4 Line/Area Management" for information on coding lines/areas. Requirements A hot key is configured to access the screen FREECODE Enter Free Code & Attributes or the user defined menu is configured to display the option Enter Free Code.
  • Page 176 Coding TPS1200 Step Description LAST (F4) Available if a free code has been previously used in the active job. Accesses FREECODE Last Used Free Codes. To select from a list of last used free codes. The free codes are sorted by time with the most recently used code at the top of the list.

  • Page 177: Quick Coding

    Quick Coding Requirements • The job codelist contains quick codes for points, lines and/or areas. • According to the requirements of the used CAD package, set <Rec Free Code: Before Point> or <Rec Free Code: After Point> in CONFIGURE Coding & Linework. Activate quick coding The current setting for <Quick Code:>...
  • Page 178 Coding TPS1200 Quick coding for points The following table explains the most common settings. Refer to the stated chapter for more step-by-step information on screens. Step Description Refer to chapter Refer to paragraph "Activate quick coding" to activate quick coding. A screen must be active where points can be measured.
  • Page 179 Step Description Refer to chapter • fixed cannot be edited. The point code and any associated attribute values are stored with the point. If a point with the same point ID exists in the job, the codes, the attribute names and the attribute values of the new and the existing point must be identical.
  • Page 180 Coding TPS1200 Quick coding for The following table explains the most common settings. Refer to the stated chapter for more lines/areas step-by-step information on screens. Step Description Refer to chapter Refer to paragraph "Activate quick coding" to activate quick coding. Type in the one, two or three digits of the quick code.

  • Page 181: Smartcodes

    SmartCodes 8.5.1 Overview Description SmartCodes is basically a quick way for code to be selected and point to be measured. All existing coding, linework, and point measurement functionality is retained. Coding TPS1200...

  • Page 182: Configuring Smartcodes

    Coding TPS1200 8.5.2 Configuring SmartCodes Access Select Main Menu: Survey. In SURVEY Survey Begin press CONF (F2) to access SURVEY Configuration. In SURVEY Survey: Job Name press SHIFT CONF (F2) to access SURVEY Configu- ration. SURVEY The settings on this page activate the using of SmartCodes and define the method. All Configuration, settings in this panel are stored within the currently active configuration set.
  • Page 183 Description of fields Field Option Description <Use SCodes:> Activates using of SmartCodes. All other fields on the screen are active and can be edited. Deactivates using of SmartCodes and all fields on this screen. <Show Info:> Information shown in line 8 of SURVEY Survey: Job name, SCode page.
  • Page 184 Coding TPS1200 Field Option Description The current vertical angle of the measured point. Horiz Dist The current horizontal distance of the measured point. Slope Dist The current slope distance of the measured point. Ht Diff The current height difference between the station and the measured point.
  • Page 185 Field Option Description Refer to "50.1 Overview" for <Method: Zig-Zag> or <Method: Same direction>. <Direction:> The way of using the code boxes. This influences in which order the code boxes will be applied. Forward The code boxes are used in the same way as defined in SURVEY Survey: Job name, SCode page.

  • Page 186: Code Block

    Coding TPS1200 8.5.3 Code Block Requirements • <Use SCodes: Yes> in SURVEY Configuration, SCode page. SURVEY ALL (F1) Survey: Job Name, To measure and store distances and angles. SCode page CODES (F3) To select a code from MANAGE Select Code panel.
  • Page 187 Step Description Refer to chapter With the focus on <Code Block: 1> press enter to access SURVEY Manage Code Blocks panel. NEW (F2) to create a new code block. Code blocks can only be created or deleted in SURVEY Manage Code Blocks panel.
  • Page 188 Coding TPS1200 Step Description Refer to chapter Code blocks are stored in the job. Refer to paragraph "Accessing Job Management" to access MANAGE Edit Job: Job Name, Codelist page. <Codelist:> If codes had been copied from a System RAM codelist, the name of the codelist is displayed.

  • Page 189: Using Smartcodes

    8.5.4 Using SmartCodes Measuring points using The following table explains the most common settings. Refer to the stated chapter for more Code Blocks step-by- information on screens. step Step Description Refer to chapter Refer to paragraph "Creating a Code Block step-by-step" to access 8.5.4 SURVEY Survey: Job Name, SCode page.

  • Page 190: Code And Attribute Mismatch

    Coding TPS1200 Code and Attribute Mismatch 8.6.1 Code Mismatch Description When storing a point with a code, it may happen that a point with the same point ID already exists in the job. If the codes of the new and the existing point do not match, a screen opens where the code can be corrected.
  • Page 191 Match codes step-by- Step Description step XX Point Code Mismatch opens automatically if the codes of the new and the existing point do not match. Highlight the code to be stored with the new point. STORE (F1) stores the highlighted code and any associated attributes with the point being stored and continues with the application program or data manage- ment.

  • Page 192: Attribute Mismatch

    Coding TPS1200 8.6.2 Attribute Mismatch Description If a point with the same point ID exists in the job, the codes, the attribute names and the attribute values of the new and the existing point must be identical. Should they not be iden- tical, a screen opens where the attribute mismatch can be corrected.
  • Page 193 Description of fields Field Option Description <Point Code:> Output • For XX Attributes Already Stored: The code of the existing point in the job. • For XX Attributes Being Stored: The code of the new point. Attributes Output • For XX Attributes Already Stored: The attributes as stored for the existing point in the job.

  • Page 194: Linework

    Linework TPS1200 Linework Overview Description Two methods are available for the surveying of lines and areas. These two methods can be combined and are described in the following table. Linework by Description Linework • In all application programs, a display mask can be configured to show the field <Linework:>.

  • Page 195: Performing Linework

    Performing Linework The Survey application program is used here to explain Linework. Requirements • A display mask with a choicelist for Linework must be configured. • The Linework flags are defined in CONFIGURE Coding & Linework Settings, Linework Preparing Linework Step1: Placing Linework in a display mask Step2: Defining the Linework flags Linework TPS1200...
  • Page 196 Linework TPS1200 Performing Linework The most important keys are explained. ALL (F1) To measure and store distances and angles. STOP (F1) Available if <EDM Mode: Tracking> and DIST (F2) was pressed. Stops the distance measurements. (F1) changes back to ALL. DIST (F2) To measure and display distances.
  • Page 197 Field Option Description • For an individual point ID independent of the ID template SHIFT INDIV (F5). SHIFT RUN (F5) changes back to the next ID from the configured ID template. Refer to "16.1 ID Templates". <Linework:> The linework flag to be stored with the point. The options available depend on whether a line/area is currently open.
  • Page 198 Linework TPS1200 Field Option Description ReOpen Last Line Opens the last used line again. The last code used with the reopened line is automatically selected when the point is stored. End Line Closes all open lines. Cont Line/Area Indicates a line/area is open. Start Spline Stores the linework flag for beginning a spline and continues any open line/area.
  • Page 199 Field Option Description Close Area Closes all open areas. Next step Step Description Go to the point to be measured. Select the appropriate Linework flag to be stored with the next point. ALL (F1) Repeat steps 1. to 3. until all points are measured and stored. SHIFT QUIT (F6) to exit the Survey application program.

  • Page 200: Combining Linework And Coding

    Linework TPS1200 Combining Linework and Coding Description • Linework and coding can be combined. • This combination can be useful, because coding, assigning linework flags and opening/closing lines/areas can all be done with one point observation. • Combining Linework and coding can only be configured if thematical point codes or if thematical point, line and area codes are available for selection.
  • Page 201 Code Type Required Optional Appearance Output Output Output Choicelist Linework Required Optional Appearance Choicelist Choicelist Choicelist Choicelist Requirements • A display mask must be configured with: • a field for codes. • a choicelist for Linework. • The configuration of a field for code types in a display mask is required for working with point, line and area codes without choicelist.
  • Page 202 Linework TPS1200 Access step-by-step Step Description Select Main Menu: Survey to access SURVEY Survey Begin. In SURVEY Survey Begin select a job. Select a configuration set. Select a reflector. CONT (F1) to access SURVEY Survey: Job Name. Using Linework/Coding This is what a display mask configured for Linework and coding looks like. The most impor- tant keys are explained.
  • Page 203 REC (F3) To record data. If <EDM Mode: Tracking> and/or <Log Auto Pts: Yes>, records meas- ured point and continues tracking. Using Linework/Coding For <Show Codes: Only Pt Codes> for point codes Step Field Description for thematical coding step-by-step With codelist Without codelist <Code:>...
  • Page 204 Linework TPS1200 Using Linework/Coding For <Show Codes: All Codes> for all codes Step Field Description for thematical coding step-by-step With codelist Without codelist <Code:> Select a code from the Type in a code. choicelist. Point, line and area codes are available for selec- tion.
  • Page 205 Linework TPS1200...

  • Page 206: Manage

    Manage...\Coordinate Systems TPS1200 Manage...\Coordinate Systems 10.1 Overview Using coordinate Coordinate systems are used on TPS1200 instruments to combine GPS1200 data with systems on TPS TPS1200 data. Description A coordinate system • consists of up to five elements. • allows the conversion from WGS 1984 geodetic or cartesian coordinates to local carte- sian, geodetic or grid coordinates and back.
  • Page 207 Using a different coordinate system converts the coordinates displayed on the screen, but does not convert and restore the coordinate values in the database DB-X. One coordinate system can be attached to a job at one time. This coordinate system remains attached to the job unless it is changed.
  • Page 208 Manage...\Coordinate Systems TPS1200 a) WGS 1984 cartesian: X, Y, Z b) WGS 1984 ellipsoid c) WGS 1984 geodetic: Latitude, longitude, ellip- soidal height d) 7 parameter transformation: dX, dY, dZ, rx, ry, rz, scale e) Local cartesian: X, Y, Z f) Local ellipsoid g) Local geodetic: Latitude, longitude, ellipsoidal height...
  • Page 209 Default coordinate TPS1200 and GPS1200 have different default coordinate systems. They cannot be deleted. systems Additional default coordinate systems may be available for certain countries. Coordinate system <None> is the default coordinate system on a TPS1200 instrument. It is not possible to <None>...

  • Page 210: Terminology

    Manage...\Coordinate Systems TPS1200 10.2 Terminology Description This chapter describes technical terms related to coordinate system management. Transformation Refer to "37.1 Overview" for information on transformations. Geoid model Description GPS operates on the WGS 1984 ellipsoid and all heights obtained by measuring baselines are ellipsoidal heights.
  • Page 211 N value and geoid model The geoid separation (N value) is the distance between the geoid and the reference ellipsoid. It may refer to the WGS 1984 or to the local ellipsoid. It is not a constant except over maybe small flat areas such as 5 km x 5 km.
  • Page 212 Manage...\Coordinate Systems TPS1200 of CSCS models are supported by TPS1200. Their conversion process is as explained in the following table. Any suitable geoid model can be combined with a geodetic CSCS model. Refer to the online help of LGO for more information on CSCS models. Type Description Grid...

  • Page 213: Accessing Coordinate System Management

    10.3 Accessing Coordinate System Management Access Select Main Menu: Manage...\Coordinate Systems. Press a hot key configured to access the screen MANAGE Coordinate Systems. Refer to "2.1 Hot Keys" for information on hot keys. Press USER. Refer to "2.2 USER Key" for information on the USER key. From a choicelist in some screens for example in MANAGE New Job, Coord System page.
  • Page 214 Manage...\Coordinate Systems TPS1200 CONT (F1) To select the highlighted coordinate system and to return to the previous screen. With a CompactFlash card inserted, the selected coordinate system will be attached to the active job. NEW (F2) To create a coordinate system. Refer to "10.4.1 Creating a New Coordinate System".
  • Page 215 Next step IF a coordinate THEN system is to be selected highlight the desired coordinate system. CONT (F1) closes the screen and returns to the screen from where MANAGE Coordinate Systems was accessed. is to be created highlight any coordinate system and NEW (F2). Refer to "10.4.1 Creating a New Coordinate System".

  • Page 216: Coordinate Systems

    Manage...\Coordinate Systems TPS1200 10.4 Coordinate Systems 10.4.1 Creating a New Coordinate System Coordinate systems can be defined by manual creation or determined by calculation. In this chapter, the manual creation of coordinate systems is explained. Refer to "37 Deter- mine Coordinate System - General" for information on the determination by calculation. Coordinate systems with a Classic 3D transformation can be defined by manual creation.
  • Page 217 Step Description Refer to chapter <Residuals:> Available for transformations with control points. Entered transformations do not have control points. The method by which residuals are distributed throughout the transformation area. The transformation results become more realistic and any strain is dispersed in the transformation.

  • Page 218: Editing A Coordinate System

    Manage...\Coordinate Systems TPS1200 10.4.2 Editing a Coordinate System The type of transformation of the selected coordinate system determines which elements of a coordinate system can be edited. The name of the coordinate system, the method of residual distribution and the geoid model in use are always editable. Access Refer to "10.3 Accessing Coordinate System Management"...
  • Page 219 Step Description Refer to chapter Make the required changes. STORE (F1) stores the changes and returns to MANAGE Coordi- nate Systems. Manage...\Coordinate Systems TPS1200...

  • Page 220: Transformations

    Manage...\Coordinate Systems TPS1200 10.5 Transformations 10.5.1 Accessing Transformation Management Access step-by-step Step Description Refer to "10.3 Accessing Coordinate System Management" to access MANAGE Coordinate Systems. In MANAGE Coordinate Systems highlight a coordinate system to be edited. EDIT (F3) to access MANAGE Edit Coordinate System. In MANAGE Edit Coordinate System highlight <Transform:>.
  • Page 221 MANAGE Listed are all Classic 3D transformations stored in the database DB-X. Any unavailable infor- Transformations mation is shown as -----. CONT (F1) To select the highlighted transformation and to return to the previous screen. NEW (F2) To create a new transformation. Refer to "10.5.2 Creating a New Transformation".
  • Page 222 Manage...\Coordinate Systems TPS1200 Next step IF a transformation THEN is to be selected highlight the desired transformation. CONT (F1) closes the screen and returns to the screen from where MANAGE Transformations was accessed. is to be created highlight any transformation and NEW (F2). Refer to "10.5.2 Creating a New Transformation".

  • Page 223: Creating A New Transformation

    10.5.2 Creating a New Transformation Classic 3D transformations can be created. Access Refer to "10.5.1 Accessing Transformation Management" to access MANAGE Transforma- tions. Create a transformation The following table explains the most common settings. step-by-step Refer to the stated chapter for more information on screens. Step Description Refer to...
  • Page 224 Manage...\Coordinate Systems TPS1200 Step Description Refer to chapter MANAGE New Transformation, More page <Height Mode:> The type of heights to be computed. <Transf Model:> The transformation model to be used. For <Transf Model: Molodensky-Bad>, additional input fields are available. Select at least a height mode and a transformation model. CLEAR (F5) Available for <Transf Model: Molodensky-Bad>.

  • Page 225: Editing A Transformation

    10.5.3 Editing a Transformation Access step-by-step Step Description Refer to "10.5.1 Accessing Transformation Management" to access MANAGE Transformations. In MANAGE Transformations highlight a transformation to be edited. EDIT (F3) to access MANAGE Edit Transformation. All following steps are identical with the creation of a new transformation. <Height Mode:>...

  • Page 226: Ellipsoids

    Manage...\Coordinate Systems TPS1200 10.6 Ellipsoids 10.6.1 Accessing Ellipsoid Management Access step-by-step Step Description Refer to "10.3 Accessing Coordinate System Management" to access MANAGE Coordinate Systems. In MANAGE Coordinate Systems highlight a coordinate system to be edited. EDIT (F3) to access MANAGE Edit Coordinate System. In MANAGE Edit Coordinate System highlight <Ellipsoid:>.
  • Page 227 SHIFT SET-D (F4) To turn the highlighted ellipsoid into a user defined default ellipsoid stored in the instru- ment. SHIFT DEFLT (F5) To recall the deleted default ellipsoids. Next step IF an ellipsoid THEN is to be selected highlight the desired ellipsoid. CONT (F1) closes the screen and returns to the screen from where MANAGE Ellipsoids was accessed.

  • Page 228: Creating A New Ellipsoid

    Manage...\Coordinate Systems TPS1200 10.6.2 Creating a New Ellipsoid Access Refer to "10.6.1 Accessing Ellipsoid Management" to access MANAGE Ellipsoids. Create an ellipsoid The following table explains the most common settings. step-by-step Refer to the stated chapter for more information on screens. Step Description Refer to...

  • Page 229: Editing An Ellipsoid

    10.6.3 Editing an Ellipsoid Access step-by-step Step Description Refer to "10.6.1 Accessing Ellipsoid Management" to access MANAGE Ellip- soids. In MANAGE Ellipsoids highlight an ellipsoid to be edited. EDIT (F3) to access MANAGE Edit Ellipsoid. All following steps are identical with the creation of a new ellipsoid. Refer to "10.6.2 Creating a New Ellipsoid".

  • Page 230: Projections

    Manage...\Coordinate Systems TPS1200 10.7 Projections 10.7.1 Accessing Projection Management Access step-by-step Step Description Refer to "10.3 Accessing Coordinate System Management" to access MANAGE Coordinate Systems. In MANAGE Coordinate Systems highlight a coordinate system to be edited. EDIT (F3) to access MANAGE Edit Coordinate System. In MANAGE Edit Coordinate System highlight <Projection:>.
  • Page 231 MANAGE Listed are all projections stored in the database DB-X. Any unavailable information is shown Projections as -----. CONT (F1) To select the highlighted projection and to return to the previous screen. NEW (F2) To create a new projection. Refer to "10.7.2 Creating a New Projection".
  • Page 232 Manage...\Coordinate Systems TPS1200 Column Option Description Customised Customised projection. Certain hard wired projec- tions which cannot be defined by any of the following options. Trans Mercator Transverse Mercator. Conformal projection onto a cylinder with its axis lying on the equatorial plane. The cylinder is tangential to a meridian.
  • Page 233 Column Option Description Cassini-Soldn Soldner Cassini. Projection onto a cylinder. It is neither equal area nor conformal. The scale is true along the central meridian and along lines perpendic- ular to central meridian. Polar Stereo Polar Stereographic. Conformal azimuthal projection onto a plane.
  • Page 234 Manage...\Coordinate Systems TPS1200 IF a projection THEN is to be edited highlight the projection and EDIT (F3). Refer to "10.7.3 Editing a Projection".

  • Page 235: Creating A New Projection

    10.7.2 Creating a New Projection Access Refer to "10.7.1 Accessing Projection Management" to access MANAGE Projections. Create a projection The following table explains the most common settings. step-by-step Refer to the stated chapter for more information on screens. Step Description Refer to chapter In MANAGE Projections highlight a projection.

  • Page 236: Editing A Projection

    Manage...\Coordinate Systems TPS1200 10.7.3 Editing a Projection Access step-by-step Step Description Refer to "10.7.1 Accessing Projection Management" to access MANAGE Projec- tions. In MANAGE Projections highlight a projection to be edited. EDIT (F3) to access MANAGE Edit Projection. All following steps are identical with the creation of a new projection. <Type:> in MANAGE Edit Projection cannot be changed.

  • Page 237: Geoid Models

    10.8 Geoid Models 10.8.1 Overview Use in the field For use on the instrument in the field, geoid field files are created from the geoid model. Geoid field file The geoid separations in a geoid field file may be used in the field to change between ellip- soidal and orthometric heights.
  • Page 238 Manage...\Coordinate Systems TPS1200 Here the geoid field file is stored in the internal memory of the instrument. It is recommended for large geoid field files. This method is also explained in this chapter. Transfer Creation Geoid field file on the System Geoid model Main Menu:...

  • Page 239: Accessing Geoid Model Management

    10.8.2 Accessing Geoid Model Management Access step-by-step Step Description Refer to "10.3 Accessing Coordinate System Management" to access MANAGE Coordinate Systems. In MANAGE Coordinate Systems highlight a coordinate system to be edited. EDIT (F3) to access MANAGE Edit Coordinate System. In MANAGE Edit Coordinate System highlight <Geoid Model:>.
  • Page 240 Manage...\Coordinate Systems TPS1200 EDIT (F3) To view the highlighted geoid model. None of the fields can be edited. The geoid field file from which the geoid model was created must be stored in the System RAM or in the \DATA\GPS\GEOID directory on the Compact- Flash card / internal memory.

  • Page 241: Creating A New Geoid Model From The Compactflash Card / Internal Memory

    10.8.3 Creating a New Geoid Model from the CompactFlash Card / Internal Memory Refer to "24 Tools...\Transfer Objects..." for information on how to transfer geoid field files to the System RAM on the instrument. Requirement At least one geoid field file with the extension *.gem is in the \DATA\GPS\GEOID directory on the CompactFlash card .

  • Page 242: Cscs Models

    Manage...\Coordinate Systems TPS1200 10.9 CSCS Models Use in the field For use on the instrument in the field, CSCS field files are created from the CSCS model. CSCS field file CSCS field files may be used in the field to directly convert coordinates from WGS 1984 to local grid without the need of transformation parameters.
  • Page 243 Manage...\Coordinate Systems TPS1200...

  • Page 244: Manage

    Manage...\Configuration Sets TPS1200 Manage...\Configuration Sets 11.1 Overview Description The instrument has numerous user configurable parameters and functions. This allows a variety of preferences to be addressed. The configuration of the parameters and functions for an individual measuring technique are combined in a configuration set. Default configuration Default configuration sets exist on the instrument.

  • Page 245: Accessing Configuration Set Management

    11.2 Accessing Configuration Set Management Access Select Main Menu: Manage...\Configuration Sets. Press a hot key configured to access the screen MANAGE Configuration Sets. Refer to "2.1 Hot Keys" for information on hot keys. Press USER. Refer to "2.2 USER Key" for information on the USER key. From a choicelist in some screens for example the begin screen of application programs.
  • Page 246 Manage...\Configuration Sets TPS1200 MORE (F5) To display information about the description, the creator and the creation date of the config- uration set. SHIFT SET-D (F4) Available unless a default configuration set is highlighted. To turn the highlighted configura- tion sets into a user defined default configura- tion set stored in the instrument.

  • Page 247: Creating A New Configuration Set

    11.3 Creating a New Configuration Set Access Refer to "11.2 Accessing Configuration Set Management" to access MANAGE Configura- tion Sets. Configuration step-by- The following table explains the most common settings. Refer to the stated chapter for more step information on screens. Step Description Refer to...
  • Page 248 Manage...\Configuration Sets TPS1200 Step Description Refer to chapter CONFIGURE Wizard Mode 18.1 <Wizard Mode: Reduced> LIST (F6) accesses CONFIGURE Quick Access. Lists all screens within the configuration set. Allows to access these individual screens and to change settings. CONT (F1) to access CONFIGURE Coding Settings. CONFIGURE Coding Settings 16.3 CONT (F1) to access CONFIGURE TPS Correction.

  • Page 249: Editing A Configuration Set

    11.4 Editing a Configuration Set Description There are two possibilities to edit a configuration set. Using the configuration set wizard to be lead through the steps. Outside of the configuration set wizard. Each screen can be accessed separately without being guided through the steps. Access step-by-step Step Description...
  • Page 250 Manage...\Configuration Sets TPS1200 In CONFIGURE Wizard Mode, press LIST (F6). Refer to "11.3 Creating a New Configu- ration Set".
  • Page 251 Manage...\Configuration Sets TPS1200...

  • Page 252: Overview

    Overview Description • Each reflector type has an additive constant. • Leica Geosystems reflectors are predefined as default and can be selected. • Additional reflectors can be defined. Default reflectors Following default reflectors are always available on the instrument: Product Name...

  • Page 253: Manage

    12.2 Accessing Reflector Management Access Select Main Menu: Manage...\Reflectors. Press a hot key configured to access the screen MANAGE Reflectors. Refer to "2.1 Hot Keys" for information on hot keys. Press USER. Refer to "2.2 USER Key" for information on the USER key. From a choicelist in some screens for example the SURVEY Survey Begin screen.
  • Page 254 Manage...\Reflectors TPS1200 MORE (F5) To display information about the additive constant, the reflector type and the creator of the reflector. Next step IF a reflector THEN is to be selected highlight the desired reflector. CONT (F1) closes the screen and returns to the screen from where MANAGE Reflectors was accessed.

  • Page 255: Creating A New Reflector

    <Type: Undefined>. <Add. Constant:> The additive constant is always in [mm]. An additive constant of 0.0 mm has been defined for the Leica Geosystems standard reflectors GPR1, GPR111, etc. All entered or selected additive constant values are differences to this 0.0 mm based Leica Geosystems TPS prism system.
  • Page 256 TPS1200 Step Description The additive constants of non Leica Geosystems prisms are often given in the true zero prism system. Use the following formula to convert the additive constant to the Leica Geosystems TPS prism system. This Leica constant needs to be entered into the Leica instrument.

  • Page 257: Editing A Reflector

    MANAGE Edit Reflector The fields are identical with those for the creation of a new reflector. 12.3 All fields can be edited except fields of Leica default reflectors. Make the required changes. STORE (F1) stores the changes and returns to MANAGE Reflec- tors.

  • Page 258: Convert

    Convert...\Export Data from Job TPS1200 Convert...\Export Data from Job 13.1 Overview Description This screen lists all the exporters loaded. Data can be exported • to a file on the CompactFlash card. • to a file on the internal memory if fitted. •...
  • Page 259 Format Characteristic Description Specialities: Points in file outside of CSCS The default value for missing variable is model output. Points in file outside of geoid The default value for missing variable is model output, also if a geoid separation is available. Coordinate conversion All points are converted to local grid position using the coordinate system.

  • Page 260: Accessing The Data Export Functionality

    Convert...\Export Data from Job TPS1200 13.2 Accessing the Data Export Functionality Access Select Main Menu: Convert...\Export Data from Job. Press a hot key configured to access the screen EXPORT Export Data from Job. Refer to "2.1 Hot Keys" for information on hot keys. Press USER.

  • Page 261: Exporting Data From A Job To A Custom Ascii Format

    13.3 Exporting Data from a Job to a Custom ASCII Format Description The settings on this screen define the data that is converted and exported and what format is used. Data is exported from the selected job. Currently active view, filter and sort settings are applied.
  • Page 262 Convert...\Export Data from Job TPS1200 Step Description Refer to chapter <Coord System:> The coordinate system currently attached to the selected <Job:>. <Format File:> The format files currently available in the System RAM. <File Name:> The name of the file to which the data should be exported.
  • Page 263 Step Description Refer to chapter <Filter:> Defines which points are exported. PAGE (F6) changes to the Lines or Areas page. The setting for <Filter:> on these pages defines which lines or areas are exported. CONT (F1) accepts the changes and returns to EXPORT Export ASCII from Job.

  • Page 264: Exporting Data From A Job To Another Device

    Convert...\Export Data from Job TPS1200 13.4 Exporting Data from a Job to another Device General Data can be transferred to an external device via RS232. Access Refer to "13.2 Accessing the Data Export Functionality" to access EXPORT Export ASCII from Job. Export data step-by- The following table explains the most common settings.
  • Page 265 Step Description Refer to chapter CSYS (F6) accesses EXPORT Coordinate Systems. To update the 10.3 coordinate system in which the coordinates are exported. CONT (F1) exports the data. Information message: Are more data to be exported? • If yes, continue with step 7. •...

  • Page 266: Exporting Data In Dxf Format

    Convert...\Export Data from Job TPS1200 13.5 Exporting Data in DXF Format General Data can be exported to a DXF file in the \DATA directory of the CompactFlash card or the internal memory, if fitted. Access Refer to "13.2 Accessing the Data Export Functionality" to access EXPORT Export DXF from Job.
  • Page 267 Step Description <Areas:> Defines if areas are exported. <Filter:> Defines which points are exported. PAGE (F6) changes to the DXF page. <Lines & Areas:> Defines if lines and areas are exported as Line or Polyline enti- ties. <LGO Symbols:> Defines if a block is created for each point with the same icons used in LGO.
  • Page 268 Convert...\Export Data from Job TPS1200 Step Description NO (F4) returns to the TPS1200 Main Menu.
  • Page 269 Convert...\Export Data from Job TPS1200...

  • Page 270: Convert

    Convert...\Import Data to Job TPS1200 Convert...\Import Data to Job 14.1 Overview Description This screen lists all the importers loaded. The data to import must be stored on the Compact- Flash card. Data can be imported to a job • on the CompactFlash card. •...
  • Page 271 Format Characteristic Description Neither coordinates nor No import. heights in file No point ID’s in file No import. GSI8 Import variables Point ID WI 11, local coordinates WI 81, GSI16 WI 82, WI 83, thematical codes WI 71. No free codes, no attributes. Refer to "20.1 GSI Output"...
  • Page 272 Convert...\Import Data to Job TPS1200 Format Characteristic Description Units Not predefined. Heights Z value imported as orthometric. Specialities Neither coordinates nor No import heights in file Checks Points are always imported with the class CTRL and a coordinate quality of -----. Refer to "6.3.1 Terminology".
  • Page 273 Case 2: Point already exists in database with a class other than CTRL Add point to database? Point not imported. Is a code attached to the point? Point imported. Point imported. Is the attached code the same as for the point already existing in the database? Point imported, existing code from data- Should the existing code for the...
  • Page 274 Convert...\Import Data to Job TPS1200 Point imported with code.

  • Page 275: Accessing The Data Import Functionality

    14.2 Accessing the Data Import Functionality Access Select Main Menu: Convert...\Import Data to Job. Press a hot key configured to access the screen IMPORT Import Data to Job. Refer to "2.1 Hot Keys" for information on hot keys. Press USER. Refer to "2.2 USER Key" for information on the USER key. Next step IF importing data in THEN ASCII format...

  • Page 276: Importing Data In Ascii Format

    Convert...\Import Data to Job TPS1200 14.3 Importing Data in ASCII Format Requirements At least one ASCII file with any file extension is stored in the \DATA directory of the Compact- Flash card. Access Refer to "14.2 Accessing the Data Import Functionality" to access IMPORT Import ASCII/GSI Data to Job.
  • Page 277 Step Description <No. Lines/Pt:> Available for <Delimiter: Line Feed>. The number of lines used to describe each point. Select the delimiter and the positions of the particular variables. DEFLT (F5) recalls the default ASCII import settings. CONT (F1) leads back to IMPORT Import ASCII/GSI Data to Job SHIFT HTS (F2) to access IMPORT Define Ht Type &...

  • Page 278: Importing Data In Gsi Format

    Convert...\Import Data to Job TPS1200 14.4 Importing Data in GSI Format Requirements At least one ASCII file in GSI format with the file extension *.gsi is stored in the GSI directory of the CompactFlash card. Access Refer to "14.2 Accessing the Data Import Functionality" to access IMPORT Import ASCII/GSI Data to Job.
  • Page 279 Step Description CONT (F1) leads back to IMPORT Import ASCII/GSI Data to Job CONT (F1) imports the data. Points with a height > 20000 m are not imported. Information message: Are more data to be imported? • If yes, continue with step 7. •...

  • Page 280: Importing Data In Dxf Format

    Convert...\Import Data to Job TPS1200 14.5 Importing Data in DXF Format Requirements At least one file in DXF format with the file extension *.dxf has to be stored in the \DATA direc- tory of the CompactFlash card. Access Refer to "14.2 Accessing the Data Import Functionality" to access DXF IMPORT Import DXF Data to Job.
  • Page 281 Step Description <Exclude Height:> Height value inside the DXF file are considered invalid and will not be converted. CONT (F1) leads back to DXF IMPORT Import DXF Data to Job CONT (F1) imports the data. Message: Do not remove CF Card! Information message: Are more data to be imported? If yes, continue with step 5.

  • Page 282: Convert

    Convert...\Copy Points Between Jobs TPS1200 Convert...\Copy Points Between Jobs Description This chapter explains the process of copying points from one job to another. Important features: • Points are copied as defined by the point filter settings. • Points selected for copying may be viewed in a points listing. The point sort settings define the order of the points in the listing.
  • Page 283 COPY Copy Points Between Jobs CONT (F1) To copy a selection of points. FILT (F4) To define the point sort and/or point filter settings of points from the job <From Job:>. DATA (F5) To view, edit and delete points, lines and areas stored with the job.

  • Page 284: Config

    Config...\Survey Settings... TPS1200 Config...\Survey Settings... 16.1 ID Templates 16.1.1 Overview of Templates Description • ID templates are predefined templates for point, line or area numbers. ID templates save having to type in the ID for each object. They are useful when many points are collected. •...
  • Page 285 Default ID Template Description No Template Used • The last point ID during a survey will be displayed. This ID is auto- matically incremented if it contains numerical characters. If this ID is overwritten, the auto increment starts from the new ID. The automatic incrementation can be turned off when editing this ID template.
  • Page 286 Config...\Survey Settings... TPS1200 Default ID Template Availability: Survey Points Auto Points Lines Areas No Template Used Time & Date Use Code&String Selecting the • A default ID template can be selected: default ID templates • manually, by selecting it in the ID Template Library under Config \Survey Settings \ID Templates.

  • Page 287: Accessing Id Template Configuration

    16.1.2 Accessing ID Template Configuration Access Select Main Menu: Config...\Survey Settings...\ID Templates. Press a hot key configured to access the screen CONFIGURE ID Templates. Refer to "2.1 Hot Keys" for information on hot keys. Press USER. Refer to "2.2 USER Key" for information on the USER key. Within the configuration set wizard.
  • Page 288 Config...\Survey Settings... TPS1200 Description of fields Field Option Description <Survey Pts:> Choicelist Sets the ID templates for measured points. <Auto Pts:> Choicelist Sets the ID templates for auto points. These points are automatically recorded at a specific rate. <Auxil Pts:> Choicelist Sets the ID templates for auxiliary points.

  • Page 289: Creating A New Id Template

    16.1.3 Creating a New ID Template Create ID template Step Description step-by-step Refer to "16.1.2 Accessing ID Template Configuration" to access CONFIGURE ID Templates. In CONFIGURE ID Templates highlight any field. ENTER to access CONFIGURE ID Template Library. Highlight an ID template. A copy of this ID template is taken for further configura- tions.
  • Page 290 Config...\Survey Settings... TPS1200 Step Description CONT (F1) returns to the screen from where CONFIGURE ID Templates was accessed. Examples for For <Increment: Numeric only> incrementation The rightmost numeric part is incremented within the point ID. <ID:> <Increment By:> Next point ID Notes Point994 Point999...
  • Page 291 <ID:> <Increment By:> Next point ID Notes Abcdefghijklmno9 -5 Abcdefghijklmnop4 Negative incrementing fails if Point ID increment next increment requires nega- fail tive sign and will result in more than 16 characters. For <Increment: Alphanumeric> The rightmost character within the point ID is incremented regardless of whether that char- acter is numeric or alphanumeric.
  • Page 292 Config...\Survey Settings... TPS1200 Template Increment value Next point ID’s Notes ABCDEB ABCDEB Upper case alpha characters ABCDEG increment from upper to lower case until z is reached. Then a Abcdez new point ID must be entered. Point ID increment fail...

  • Page 293: Editing An Id Template

    16.1.4 Editing an ID Template Edit ID template Step Description step-by-step Refer to "16.1.2 Accessing ID Template Configuration" to access CONFIGURE ID Templates. In CONFIGURE ID Templates highlight any field. ENTER to access CONFIGURE ID Template Library. CONFIGURE ID Template Library Highlight the ID template to be edited.
  • Page 294 Config...\Survey Settings... TPS1200 Step Description CONT (F1) returns to CONFIGURE ID Templates. CONT (F1) returns to the screen from where CONFIGURE ID Templates was accessed.

  • Page 295: Deleting An Id Template

    16.1.5 Deleting an ID Template Delete ID template Step Description step-by-step Refer to "16.1.2 Accessing ID Template Configuration" to access CONFIGURE ID Templates. In CONFIGURE ID Templates highlight any field. ENTER to access CONFIGURE ID Template Library. CONFIGURE ID Template Library Highlight the ID template to be deleted.

  • Page 296: Working Example

    Config...\Survey Settings... TPS1200 16.1.6 Working Example Description Application: • Pick up points with many different point ID’s. • Most point ID’s require an incrementing number behind a text. Working technique: Application program Survey. Goal: • The first point ID’s for survey points are Bolt 001, Bolt 002, ..•...
  • Page 297 Step Description CONFIGURE ID Templates <Survey Pts: Bolt 001> CONT (F1) returns to the screen from where CONFIGURE ID Templates was accessed. Field procedure Step Description step-by-step Refer to "47.2 Surveying Points" to access SURVEY Survey: Job Name. SURVEY Survey: Job Name <Point ID: Bolt 001>...
  • Page 298 Config...\Survey Settings... TPS1200 Step Description ALL (F1). The system changes back to the point ID’s RoadXXXX.

  • Page 299: Display Settings

    16.2 Display Settings Description Display settings define the parameters shown on a page on the SURVEY screen. Four display masks are definable. Mask 1: Always shown on the SURVEY screen. Mask 2: Can be shown or hidden on the SURVEY screen. Mask 3: Can be shown or hidden on the SURVEY screen.
  • Page 300 Config...\Survey Settings... TPS1200 CONFIGURE Display Settings CONT (F1) To accept changes and return to the screen from where this screen was accessed. DMASK (F3) To configure the selected display mask. Refer to paragraph "CONFIGURE Define Display Mask n". Description of fields Field Option Description...
  • Page 301 IF a display mask THEN is to be edited highlight the display mask and DMASK (F3). Refer to paragraph "CONFIGURE Define Display Mask n". CONFIGURE Define Display Mask n CONT (F1) To accept changes and to return to CONFIGURE Display Settings. CLEAR (F4) To set all fields to <XX.
  • Page 302 Config...\Survey Settings... TPS1200 Field Option Description <2nd Line:> to For each line one of the following options can <16th Line:> be selected. Add. Constant Output field for additive constant of currently selected reflector. Angle Right Displayes the horizontal angle difference between the backsight point and the current telescope position.
  • Page 303 Field Option Description Code Desc (free) Output field for the description of free codes. Code Type Output field for the type of code, for example point code, line code or area code. EDM Mode Select EDM measurement mode. EDM Type Select EDM type.
  • Page 304 Config...\Survey Settings... TPS1200 Field Option Description Offset Cross Input field for horizontal distance offset for measured point, perpendicular to the line of sight. Offset Height Input field for height offset for measured point. Offset Length Input field for horizontal distance offset, in the direction of line of sight.
  • Page 305 Field Option Description Station North Output field for current station Northing coordi- nates. Std Dev Output field of standard deviation in millime- ters of averaged distances. Time at Point Output field for the time from when the point is occupied until point occupation is stopped. Appears in the display mask during the point occupation.

  • Page 306: Coding & Linework Settings

    Config...\Survey Settings... TPS1200 16.3 Coding & Linework Settings Description The settings on this screen define the method of coding, for both points and lines. Refer to "8 Coding" for a complete description of coding. Access Select Main Menu: Config...\Survey Settings...\Coding & Linework Settings. Press a hot key configured to access the screen CONFIGURE Coding &...
  • Page 307 Description of fields Field Option Description <Quick Code:> Never Prevents the use of quick coding completely. Allows the use of quick coding and activates it. Allows the use of quick coding, but keeps it deacti- vated. <Digits:> 1, 2 or 3 Available unless <Quick Code: Never>.
  • Page 308 Config...\Survey Settings... TPS1200 Field Option Description <Mand Attribs:> Always The screen XX Enter Mandatory Attribute will Prompt always appear when codes, having one or more attributes of attribute type mandatory, are being stored. Attributes of attribute type mandatory or fixed can only be created in LGO.
  • Page 309 Field Option Description All Codes All codes of the job codelist will be available in the choicelist for <Code:>/<Point Code:> in a display mask of an application program. Selecting a line/area code opens a new line/area. <String Attrib:> Choicelist Available for <Show Codes: All Codes>. When this field is active, surveyed points that have the same code attached are strung to one line.
  • Page 310 Config...\Survey Settings... TPS1200 CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Begin Line:> User input Opens a new line when the next point is stored. Any lines which are currently open are closed.
  • Page 311 Field Option Description <Start Spline:> User input Stores the linework flag for beginning a spline and continues any open line/area. <End Spline:> User input Stores the linework flag to stop a spline. <Cont Spline:> User input Indicates a line/area is open with spline line type. <Begin Area:>...

  • Page 312: Offsets

    Config...\Survey Settings... TPS1200 16.4 Offsets Description Offsets can be configured and entered. The offset values are applied to measured points. The Offset function allows offset points to be determined, for instance when the reflector cannot be set up directly on a point. Transverse, longitudinal and/or elevation offsets can be defined from the reflector position to the offset point.
  • Page 313 If configured in a display mask, the offset values appear also in the display mask in Survey. Access Select Main Menu: Config...\Survey Settings...\Offsets. Press a hot key configured to access the screen CONFIGURE Offsets. Refer to "2.1 Hot Keys" for information on hot keys. Press USER.
  • Page 314 Config...\Survey Settings... TPS1200 Description of fields Field Option Description <Offset Mode:> Reset after The offset values are reset to 0.000 after a point is measured with REC (F3) or ALL (F1). Permanent The offset values are applied to every measured point until reset or changed.

  • Page 315: Target Check

    16.5 Target Check Description • It is possible to configure the instrument to monitor sequentially stored measurements and to notify the user if the coordinates lie within a defined range from each other. • If configured, when a point is being stored the X,Y coordinates of the point being stored are compared to those of the last previously stored point.
  • Page 316 Config...\Survey Settings... TPS1200 Configuring the target check CONT (F1) To accept the screen entries and continue. Description of fields Field Option Description <Target Check:> Target checking is activated. Target checking is not activated. <Pos Tolerance:> User input The position tolerance. The units are defined by Config \General Settings \Units &...
  • Page 317 Config...\Survey Settings... TPS1200...

  • Page 318: Config

    Config...\Instrument Settings... TPS1200 Config...\Instrument Settings... 17.1 EDM & ATR Settings Description • The settings on this screen define the active EDM Electronic Distance Measurement and ATR Automatic Target Recognition settings. • Refer to "32 Functions" for detailed information on EDM and ATR. •...
  • Page 319 CONFIGURE Description EDM & ATR Settings • This screen has two pages - the Survey page and the Setup page. Survey page • The Survey page and Setup page contain identical fields. Setup page • The settings made in the Survey page are used by all applications and all measurements taken outside of the Setup application program.
  • Page 320 Config...\Instrument Settings... TPS1200 Description of fields Field Option Description <EDM Type:> Reflector All fields are set to the last used options. (IR) The IR EDM exists for all instrument types and allows to measure the distance to a prism or a tape. IR is the EDM that can be used with ATR and LOCK.
  • Page 321 Field Option Description Fast Available only for <EDM Type: Reflector (IR)>. Fast single distance measurement with 0.5 s meas- uring time and 5 mm + 2 ppm accuracy. When activated, FAST is displayed as an icon. Tracking Available unless <EDM Type: Long Range (LO)>. Continuous distance measurement with 0.3 s meas- uring time and 5 mm + 2 ppm accuracy.
  • Page 322 Config...\Instrument Settings... TPS1200 Field Option Description Average Available for all <EDM Type:> options. Repeats measurements in standard measuring mode. The average distance of <AVG Max #Dist:> and the standard deviation for the averaged distance are calculated. When activated, AVG is displayed as an icon. <AVG Max #Dist:>...
  • Page 323 Field Option Description • This mode is automatically deactivated when the instrument is turned off. Low Vis • Low Visability Mode is permanently turned on. Always On S-Range On • Short Range Mode is turned on. • This mode is designed for survey work at close range from the instrument (up to 60-80 m).

  • Page 324: Search Windows

    Config...\Instrument Settings... TPS1200 17.2 Search Windows Description • The settings on this screen define the size of search windows for prisms to be searched in. The prisms can be searched with ATR in the ATR window or with PowerSearch in the PS window.
  • Page 325 CONFIGURE CONT (F1) Search Windows, TPS1200 To accept changes and return to PS Window page Main Menu NEW (F2) To define new PowerSearch window. CENTR (F4) To centre the PowerSearch window to the current position of the telescope. SHOW (F5) To position the telescope to corners of Power- Search window.
  • Page 326 Config...\Instrument Settings... TPS1200 Field Option Description <Dist max:> From 25 m to Maximum distance of the search range for the PS 175 m and window to be defined. Next step PAGE (F6) changes to the ATR Window page. CONFIGURE Search Windows, ATR Window page CONT (F1) TPS1200...
  • Page 327 Field Option Description <V Search:> User input Vertical extent of window. Next step CONT (F1) returns to TPS1200 Main Menu. Config...\Instrument Settings... TPS1200...

  • Page 328: Automatic Prism Search

    Config...\Instrument Settings... TPS1200 17.3 Automatic Prism Search Description • The settings on this screen define the behaviour of automatic prism search after the target is lost in lock mode. • Refer to "32 Functions" for information on ATR, PowerSearch, lock and automation behaviour.
  • Page 329 CONFIGURE Automatic Prism Search CONT (F1) TPS1200 To accept changes and return to Main Menu DEFLT (F5) To recall the default settings. Description of fields Field Option Description <Predict for:> From 1 s to 5 s If the target is lost when <Automation: LOCK> the path of the reflector is predicted for the selected amount of seconds.
  • Page 330 Config...\Instrument Settings... TPS1200 Next step CONT (F1) closes the screen and returns to TPS1200 Main Menu.

  • Page 331: Tps Corrections

    17.4 TPS Corrections Description • The settings on this screen define the atmospheric ppm, the geometric ppm and the refraction. The geometric ppm can also be determined by a resection calculation. • For standard application programs the distance is corrected on account of atmospheric influences.
  • Page 332 Config...\Instrument Settings... TPS1200 CONFIGURE The atmospheric distance corrections are derived from the dry air temperature, air pressure TPS Corrections, or elevation above mean sea level MSL and relative air humidity or wet bulb temperature. AtmosPPM page CONT (F1) TPS1200 To accept changes and return to Main Menu P<>E (F3) To change <Atm Pressure:>...
  • Page 333 Next step PAGE (F6) changes to the GeomPPM page. CONFIGURE • The geometric distance correction (geometric ppm) is derived from the map projection TPS Corrections, distortion (map projection ppm), the height above reference datum correction (height GeomPPM page ppm) and an individual correction (individual ppm). •...
  • Page 334 Config...\Instrument Settings... TPS1200 Description of fields Field Option Description <Calc Scale:> Choicelist To manually or automatically calculate the geometric ppm value. Manually The geometric ppm value is manually calculated. Automatically The geometric ppm value is automatically calculated. <Scale at C.M.:> User input The scale at the central meridian.
  • Page 335 Field Option Description <Height ppm:> Output The height ppm value calculated from the height coordinates of the current TPS station stored in the System RAM. If this value cannot be calculated, then ----- is displayed and is also ignored in the calculation of the geometric ppm value.
  • Page 336 Config...\Instrument Settings... TPS1200 Automatic calculation of the geometric ppm value When <Calc Scale: Automatically> is set: • the ppm values for <Map Proj ppm>, <Height ppm> and <Geometric ppm> are auto- matically calculated. The coordinates of the current instrument station stored in the System RAM are used, which are based on the currently active coordinate system.
  • Page 337 CONT (F1) TPS1200 To accept changes and return to Main Menu DEFLT (F5) Sets <Correction: On> and <Ref coeff (k): 0.13>. PAGE (F6) To change to other page on screen. Description of fields Field Option Description <Correction:> On or Off Refraction correction is applied to measurements.

  • Page 338: Compensator

    Config...\Instrument Settings... TPS1200 17.5 Compensator Description The compensator and the Hz correction can be deactivated if raw data is to be displayed and recorded. Access Select Main Menu: Config...\Instrument Settings...\Compensator. Press a hot key configured to access the screen CONFIGURE Compensator. Refer to "2.1 Hot Keys"...
  • Page 339 CONFIGURE Compensator CONT (F1) TPS1200 To accept changes and return to Main Menu Description of fields Field Option Description <Compensator:> Vertical angles are relative to plumb line. The hori- zontal angle is corrected for the transversal tilt errors if <Hz-Correction: On>. Vertical angles are relative to vertical/standing axis.
  • Page 340 Config...\Instrument Settings... TPS1200 Next step CONT (F1) returns to TPS1200 Main Menu.

  • Page 341: Instrument Id

    17.6 Instrument ID Description • The settings on this screen define the instrument identification number. This number is used for the generation of the file names. • Using format files, the instrument ID can be output together with data from the instrument. By doing so, it can be identified which instrument was used for certain measurements.
  • Page 342 Config...\Instrument Settings... TPS1200 Description of fields Field Option Description <Instrument ID:> User input Sets a four digit number as instrument identification number. By default the last four numbers of the serial number are used. Next step CONT (F1) returns to TPS1200 Main Menu.
  • Page 343 Config...\Instrument Settings... TPS1200...

  • Page 344: Config

    Config...\General Settings... TPS1200 Config...\General Settings... 18.1 Wizard Mode Description The settings on this screen define the behaviour of the configuration set wizard. Access Select Main Menu: Config...\General Settings...\Wizard Mode. Within the configuration set wizard. Refer to "11.2 Accessing Configuration Set Manage- ment".
  • Page 345 Description of fields Field Option Description <Wizard Mode:> View All All configuration screens are shown in the configura- Screens tion set wizard. Application program configuration screens are not included. They can be configured within each application program. Reduced A reduced set of screens are shown in the configura- tion set wizard.

  • Page 346: Hot Keys & User Menu

    Config...\General Settings... TPS1200 18.2 Hot Keys & User Menu Description The settings on this screen assign a particular function, screen or application program to each of the first and second level of hot keys and to the USER key. Refer to "2 Configurable Keys"...
  • Page 347 CONFIGURE To configure the first level of hot keys. Hot Keys & User Menu, Hot Keys page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option...
  • Page 348 Config...\General Settings... TPS1200 CONFIGURE To configure the second level of hot keys. Hot Keys & User Menu, The functionality on this page is identical to the one on the Hot Keys page. Shift Hot Keys page Field Option Description <F7:> to <F10:> Choicelist All functions, screens or application programs which can be assigned to the particular key.
  • Page 349 Description of fields Field Option Description <1:> to <9:> Choicelist All functions, screens or application programs which can be assigned to the individual lines in the user defined menu. Next step PAGE (F6) changes to the first page on this screen. Config...\General Settings...

  • Page 350: Units & Formats

    Config...\General Settings... TPS1200 18.3 Units & Formats Description The settings on this screen define • the units for all types of measurement data displayed. • information related to some types of measurement data. • the order in which coordinates are displayed. Access Select Main Menu: Config...\General Settings...\Units &...
  • Page 351 CONFIGURE Units & Formats, Units page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Distance Unit:> The units shown for all distance and coordinate related fields.
  • Page 352 Config...\General Settings... TPS1200 Field Option Description <Distance Dec:> From The number of decimal places shown for all distance 0 Decimal to and coordinate related fields. This is for data display 4 Decimals and does not apply to data export or storage. The available options depend on the selected <Distance Unit:>.
  • Page 353 Field Option Description Elev Angle Elevation angle. <Area Unit:> , Int Acres The units shown for all area related fields. (Ai), US Acres (A), Hectares (ha), fi or ft <Temp Unit:> Celsius (°C) or The units shown for all temperature related fields. Fahrenheit (°F) <Press Unit:>...
  • Page 354 Config...\General Settings... TPS1200 CONFIGURE Units & Formats, Angle page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Direc Ref:>...
  • Page 355 Field Option Description GPS12_084 For all other options, the azimuth/bearing fields in other screens are called <Azimuth:>. <V-Display:> Zenith Angle V = 0 in zenith. Elev Angle V = 0 horizontal elevation angle. V-angles are posi- tive above the horizon and negative below it. Elev Angle % V = 0 horizontal.
  • Page 356 Config...\General Settings... TPS1200 Field Option Description Running The vertical angle is continuously updated with the telescope movement. The active reflector height is applied in the calculation of remote point elevations. The reflector height must be set to zero to display and record the elevation of the targeted remote point.
  • Page 357 CONFIGURE Units & Formats, Time page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Time Format:> 24 hour or How the time is shown in all time related fields.
  • Page 358 Config...\General Settings... TPS1200 CONFIGURE Units & Formats, Format page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Grid Format:>...

  • Page 359: Language

    18.4 Language Description The setting on this screen defines the language used on the instrument. Three languages can be stored on the instrument at one time - English and two others. English cannot be deleted. Refer to "25.2 System Languages". Access Select Main Menu: Config...\General Settings...\Language.
  • Page 360 Config...\General Settings... TPS1200 Field Option Description The selected language is used for the system soft- ware. If a language is not available for the system software, the English language is used instead. Application programs run in the language they were loaded.

  • Page 361: Lights, Display, Beeps, Text

    18.5 Lights, Display, Beeps, Text Description The settings on this screen allow the lights and screen appearance to be configured, turn the notification beeps on and off and define the behaviour of the keys. Access Select Main Menu: Config...\General Settings...\Lights, Display, Beeps, Text. Press SHIFT F11.
  • Page 362 Config...\General Settings... TPS1200 Field Option Description <EGL:> On or Off To turn the Emitting Guide Light (EGL) on and off. This field is only available if EGL is fitted <Laser Guide:> On or Off To turn the Laser Guide (GUS74) on and off. This field is only available if GUS74 is fitted <Intensity:>...
  • Page 363 CONFIGURE This page contains the screen display settings for the TPS1200 instrument. Lights, Display, Beeps, Text, Display page CONT (F1) To accept changes and return to the screen from where this screen was accessed. CALIB (F5) To calibrate the touch screen. PAGE (F6) To change to another page on this screen.
  • Page 364 Config...\General Settings... TPS1200 Field Option Description <Key Illum:> Off, Same as Controls the keyboard illumination. Screen or Always On <Contrast:> From 0 % to Adjust the contrast level for the display with the right 100 % and left arrow key when the field is highlighted. <Heating:>...
  • Page 365 Description of fields Field Option Description <Warning Beeps:> Off, Soft or Controls the beep for acoustic warning signals for the Loud TPS1200 instrument. <WarnBeeps RCS:> Off, Soft or Controls the beep for acoustic warning signals for the Loud RX1200 controller. <Key Beeps:>...
  • Page 366 Config...\General Settings... TPS1200 CONFIGURE Lights, Display, Beeps, Text, Text page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Key Rpt Delay:>...
  • Page 367 Field Option Description <Alpha Mode:> Function Alphanumeric input can either be through function or Keys or numeric keys. Numeric Keys <Deflt αNum:> Up to 6 choices Available if <Alpha Mode: Function Keys>. Sets the set of extra characters available through αNUM or on F1-F6 whenever an entry is made.

  • Page 368: Start Up & Power Down

    Config...\General Settings... TPS1200 18.6 Start Up & Power Down Description • The settings on this screen • define the instrument start up screen. • define the behaviour of the instrument and SmartAntenna when starting up and when powering down. • define a PIN code which needs to be entered when starting up the instrument. Start Up •...
  • Page 369 For instruments delivered with firmware version 2.10 or higher, the PUK code comes with the instrument. • For instruments delivered with firmware versions lower than v2.10, contact a Leica representative to obtain a PUK code. Access Select Main Menu: Config...\General Settings...\Start Up & Power Down.
  • Page 370 Config...\General Settings... TPS1200 CONFIGURE Start Up & Power Down Start Up & Power Down page CONT (F1) To accept changes and return to TPS1200 Main Menu. Description of fields Field Option Description <Start Screen:> Choicelist Determines the first screen which is shown after turning on the instrument.
  • Page 371 Field Option Description Remain On The instrument does not power down automat- ically. <After Time:> User input Available unless <Mode: Remain On> is selected. Minutes after which the instrument should turn off. <Switch Off:> Choicelist This option determines when SmartAntenna is turned off.
  • Page 372 Config...\General Settings... TPS1200 • The PIN code protection can be activated. • The PIN code must be typed in order to change settings on this page. • Then a PIN code can be typed in. • Then the PIN code protection can be deactivated.
  • Page 373 Field Option Description PIN Code User input The PIN code as previously defined on this page. The correct PIN code must be typed in within five attempts or the PUK code is required. Refer to "1 Instrument Protection with PIN". Change PIN Yes or No Activates <New PIN:>...

  • Page 374: Interfaces, Ports, Devices

    Interfaces, Ports, Devices TPS1200 Interfaces, Ports, Devices 19.1 Overall Concept Terminology Term Description Interface The procedures, codes and protocols that enable two entities to interact for an exchange of data. Each interface is given a meaningful display name which enables easy distinction between interfaces. Port A connection through which a separate device may communicate with the instrument.
  • Page 375 Concept Example Device Which device is being connected to the port and Baud Rate: 115200 what are its communication settings and indi- Parity: None vidual parameters ? Data Bits: 8 Stop Bit: 1 Link Number: 1, Set as: Base Screen This screen gives an overview of all interfaces with the currently assigned port and device.
  • Page 376 Interfaces, Ports, Devices TPS1200 Point Description To configure the parameters related to the highlighted interface (switching on/off the interface, port selection, device selection and device communication settings). • CONFIGURE Interfaces - CTRL (F4) refers to device parameters. To configure additional parameters related to the highlighted device. •...

  • Page 377: Interfaces

    19.2 Interfaces 19.2.1 Overview of Interfaces Description • The instrument has various interfaces configured to to be used with a port and a device. The configuration varies depending on the individual application. • Additional interfaces are always available when the instrument is fitted with Communica- tion side cover.

  • Page 378: Accessing Configure Interfaces

    Interfaces, Ports, Devices TPS1200 19.2.2 Accessing CONFIGURE Interfaces Access Select Main Menu: Config...\Interfaces..Press a hot key configured to access the screen CONFIGURE Interfaces. Refer to "2.1 Hot Keys" for information on hot keys. Press USER. Refer to "2.2 USER Key" for information on the USER key. CONFIGURE •...
  • Page 379 USE (F5) To turn the highlighted interface on or off. If the interface is turned on then the settings which were last used with that interface are active. If the device which was last used with that inter- face is no longer available, the RS232 is assigned to that interface.

  • Page 380: Ports

    Interfaces, Ports, Devices TPS1200 19.3 Ports Description • The instrument is always fitted with the port located at the instrument base (port 1). Addi- tional ports are available when Communication side cover is fitted (port 2 and port 3). • The list of available devices always depends on the selected port.

  • Page 381: Devices

    19.4 Devices 19.4.1 Overview of Devices Description • A device is the hardware which is connected to the chosen port. Devices are used to transmit and receive measurement data in TPS mode and GPS real-time data in GPS mode. Devices are also used by TPS1200 to communicate with the RX1200 controller. •...

  • Page 382: Devices

    Interfaces, Ports, Devices TPS1200 / CONFIGURE GPRS Internet De- 19.4.2 Accessing CONFIGURE Devices vices Description • Allows devices to be created, edited, selected and deleted. • Refer to "21 Config...\Interfaces... - Controlling The Device" for more information. Access step-by-step Step Description Main Menu: Config...\Interfaces...
  • Page 383 CONT (F1) To select the highlighted device and return to the screen from where this screen was accessed. NEW (F2) To create a new device. Refer to "19.4.3 Creating a New Device". EDIT (F3) To edit the highlighted device. Refer to "19.4.4 Editing a Device".
  • Page 384 Interfaces, Ports, Devices TPS1200 Description of columns Column Description Name Names of available devices. Type Type of device defined when creating the device. Creator The creator of the device. The creator can either be Default if the device is a default, or User if the device has been created. If a Default device is edited by using EDIT (F3) then its creator is still displayed as Default.

  • Page 385: Creating A New Device

    19.4.3 Creating a New Device Description Allows a new device to be configured. Access step-by-step Step Description Refer to "19.4.2 Accessing CONFIGURE Devices / CONFIGURE GPRS Internet Devices" to access CONFIGURE Devices / CONFIGURE GPRS Internet Devices. Highlight a device of the same type as the device to be created, from the list. NEW (F2) to access CONFIGURE New Device.
  • Page 386 Interfaces, Ports, Devices TPS1200 Description of fields Field Option Description <Name:> User input Name of new device. <Type:> Output Same device type as was highlighted when NEW (F2) was used. <Baud Rate:> From 300 to Frequency of data transfer from instrument to device 115200 in bits per second.
  • Page 387 Field Option Description <Flow Control:> None or Available for some devices. Activates hardware RTS/CTS handshake. When the receiver/device is ready for data, it asserts the Request To Send line indicating it is ready to receive data. This is read by the sender at the Clear To Send input, indicating it is clear to send the data.
  • Page 388 Interfaces, Ports, Devices TPS1200 Description of fields Field Option Description <Init 1:> User input Initilisation sequence to initilise digital cellular phone/modem. <(cont):> User input Allows the <Init X:> or the <Connect:> string to continue onto a new line. <Init 2:> User input Initilisation sequence to initilise digital cellular phone/modem.

  • Page 389: Editing A Device

    19.4.4 Editing a Device Access step-by-step Step Description Refer to "19.4.2 Accessing CONFIGURE Devices / CONFIGURE GPRS Internet Devices" to access CONFIGURE Devices / CONFIGURE GPRS Internet Device. Highlight the device to be edited from the list. EDIT (F3) to access CONFIGURE Edit Device. CONFIGURE The availability of options may change depending on the selected device.

  • Page 390: Device - Digital Cellular Phones

    Interfaces, Ports, Devices TPS1200 19.4.5 Device - Digital Cellular Phones Description Digital cellular phones comprise of the technologies CDMA and GSM with its subgroup GPRS. Typical uses • To transmit real-time data. • To receive real-time data. • To download raw observations from a remote location. •...
  • Page 391 Requirements for using Always required: • AT command language must be supported by the digital cellular digital cellular phones phone. Refer to "19.4.3 Creating a New Device". • Working area must be covered by a digital cellular phone network. • The network operator must support data transmission.
  • Page 392 Interfaces, Ports, Devices TPS1200 • Nokia 6230(i) • SonyEricsson K700i • Nokia 6310(i) • SonyEricsson K750i • Nokia 6630 • SonyEricsson K800i • Nokia 6822a • SonyEricsson P900 • Nokia N80 • SonyEricsson S700i • Siemens M75 • SonyEricssonT610 User defined digital cellular phones Other digital cellular phones than those listed above can be used.

  • Page 393: Device - Modems

    19.4.6 Device - Modems Typical uses • To transmit NMEA messages. • To transmit real-time data • To download raw observations from a remote location. Example of use Step Description The reference is equipped with a modem. The rover is equipped with a digital cellular phone. Ensure that the modem is switched on.
  • Page 394 Interfaces, Ports, Devices TPS1200 Supported modems Default modems • AirLink CDMA • U.S. Robotics 56K Modems must be connected with a cable. Refer to "Appendix E Cables" for information on cables. User defined modems Other modems than those listed above can be used. Their settings must be defined by creating a new modem configuration.

  • Page 395: Device - Radios For Gps Real-Time

    19.4.7 Device - Radios for GPS Real-Time Typical uses • To transmit real-time data. • To receive real-time data. • To download raw observations from a remote location. • To steer a receiver. Example of use Step Description Reference and rover must both be equipped with radios using the same frequency range and the same data format.
  • Page 396 Interfaces, Ports, Devices TPS1200 Default radios not fitting into a clip-on-housing These radios must be connected with a cable. Refer to "Appendix E Cables" for information on cables. • AT-RXM500, Akasaka Tech • Pacific Crest RFM96W • Satelline 2ASx • Satelline 2ASxE User defined radios Other radios than those listed above can be used.

  • Page 397: Device - Radios For Remote Control

    19.4.8 Device - Radios for Remote Control Typical uses • To remote control the TPS1200. • To transmit data between TPS1200 and computer. Supported radios • The default radios used with TPS1200 for remote control are RadioHandle and TCPS27. TPS1200 has to be set to the correct communication mode to send and receive data and commands via the radio.
  • Page 398 Interfaces, Ports, Devices TPS1200 User defined radios Other radios than the default radios can be used. Their settings must be defined by creating a new radio configuration. Refer to "19.4.3 Creating a New Device". These radios must be connected with a cable. Refer to "Appendix E Cables" for information on cables.

  • Page 399: Device - Rs232

    19.4.9 Device - RS232 Typical uses • To exchange information with a device via an RS232 interface. • RS232_GeoCOM can be used to control the instrument via GeoCOM commands from a computer. • RS232_GSI can be used to send data from the instrument to a computer. •...
  • Page 400 Interfaces, Ports, Devices TPS1200 User defined RS232 All settings can be defined.

  • Page 401: Device - Gprs / Internet Devices

    19.4.10 Device - GPRS / Internet Devices Description • GPRS is a telecommunication standard for transmitting data packages using the Internet Protocol. • When using GPRS technology charges are made based on the amount of transferred data and not as for normal digital cellular phones where charges are made for the connec- tion time.
  • Page 402 Interfaces, Ports, Devices TPS1200 Requirements for using • AT command language must be supported by the digital cellular phone. Refer to "19.4.3 GPRS / Internet devices Creating a New Device". • Access Point Name of a server from the network provider. The APN can be thought of as the home page of a provider supporting GPRS data transfer.
  • Page 403 Interfaces, Ports, Devices TPS1200...

  • Page 404: Config

    Config...\Interfaces... - Editing The Interface TPS1200 Config...\Interfaces... - Editing The Interface 20.1 GSI Output Description Data is streamed through the serial port (RS232) and is stored to the active job. GSI data is stored when <Use Interface: Yes> and either ALL (F1) or REC (F3) is pressed. The format of the data depends on the option selected in <Output Format:>.
  • Page 405 CONFIGURE GSI Output CONT (F1) To accept changes and return to the screen from where this screen was accessed. DEVCE (F5) To create, select, edit or delete a device. Description of fields Field Option Description <Use Interface:> Yes or No Activates the interface.
  • Page 406 Config...\Interfaces... - Editing The Interface TPS1200 Field Option Description RS232 GSI A handshake is required. A data block is sent out from the instrument and a receive confirmation (?) is expected. This handshake requires that GeoCom Mode be activated. None No handshake is required.
  • Page 407 Next step IF a device is THEN not to be created or CONT (F1) closes the screen and returns to the screen from where edited CONFIGURE GSI Output was accessed. to be created or DEVCE (F5) to create or edit a device. edited Output format - GSI data is transmitted in blocks.
  • Page 408 Config...\Interfaces... - Editing The Interface TPS1200 Type GSI8 Polar&Cart GSI16 Polar GSI16 Cartesian WI 31 SlopeDist SlopeDist WI 51 PPM Total/mm PPM Total/mm WI 81 East East WI 82 North North WI 83 Elev. Elev. WI 87 Refl. Ht Refl. Ht Example 1: GSI8 Each word has 16 characters of which 8 characters are used for the data block.
  • Page 409 *110003+000000000PNC0057 21.002+0000000011222360 22.002+0000000005433800 *110004+000000000PNC0058 21.002+0000000010573550 22.002+0000000005817600 *110005+000000000PNC0059 21.002+0000000009983610 22.002+0000000005171400 GSI Word information Pos. Name Description of values Applicable for Word Index (WI) No signifi- .: No information. WI 11, WI 21, WI 22, cance WI 31, WI 51, WI 81, WI 82, WI 83, WI 87 Automatic .: No information.
  • Page 410 Config...\Interfaces... - Editing The Interface TPS1200 Pos. Name Description of values Applicable for Units .: No information. WI 21, WI 22, WI 31, WI 81, WI 82, WI 83, 0: <Distance Unit: Metre (m)>, last digit 1 / 1000 m 1: <Distance Unit: Us ft (ft)>, last digit 1 / 1000 ft WI 87 2: <Angle Unit: 400 gon>...
  • Page 411 Description of fields The format settings are defined in CONFIGURE Units & Formats. Field Description Point ID Text describing the point identification Northing The northing coordinate. Easting The easting coordinate. Elevation The height coordinate. Date The measurement/origination date. Time The measurement/origination time. <CR/LF>...
  • Page 412 Config...\Interfaces... - Editing The Interface TPS1200 Format $GPGGA,Time,Northing,N,Easting,E,1,05,1.0,Elevation,M,0.0,M,0.0,0001*99 <CR/LF> Description of Fields Field Description $GPGGA Sentence identification (header including talker identification). A Talker ID appears at the beginning of the header of each NMEA message. Time UTC time of position (hhmmss.ss) Northing The northing coordinate (always output with 2 decimal places) Fixed text (N)
  • Page 413 Field Description Time since last Fixed number (0.0) DGPS update DGPS Fixed number (0.0001) reference station id Checksum Fixed number (*99) <CR/LF> Carriage Return Line Feed Example $GPGGA,171933.97,7290747.02,N,3645372.06,E,1,05,1.0,1093609.54,F,0.0,M,0.0,0001*99 $GPGGA,171934.20,7290747.02,N,3645372.06,E,1,05,1.0,1093609.54,F,0.0,M,0.0,0001*99 $GPGGA,171934.45,7290747.03,N,3645372.06,E,1,05,1.0,1093609.54,F,0.0,M,0.0,0001*99 Fields are always separated by a comma. A comma is never placed before the Checksum field.

  • Page 414: Geocom Mode

    Config...\Interfaces... - Editing The Interface TPS1200 20.2 GeoCOM Mode Description The GeoCOM Mode permits communication of the TPS1200 with a 3 party device. Access step-by-step Step Description Refer to "19.2.2 Accessing CONFIGURE Interfaces" to access CONFIGURE Interfaces CONFIGURE Interfaces Highlight GeoCOM Mode. EDIT (F3) to access CONFIGURE GeoCOM Mode.
  • Page 415 Description of fields Field Option Description <Use Interface:> Yes or No Activates the interface. <Port:> Output Available if <Use Interface: Yes>. Port to be used. <Device:> Output Available if <Use Interface: Yes>. Device to be used. <Protocol:> Output Available if <Use Interface: Yes>. Protocol to be used.

  • Page 416: Rcs Mode

    Config...\Interfaces... - Editing The Interface TPS1200 20.3 RCS Mode Description • RCS stands for Remote Control Surveying. • This enables the instrument to be remotely controlled by an RX1200 controller. Access step-by-step Step Description Refer to "19.2.2 Accessing CONFIGURE Interfaces" to access CONFIGURE Interfaces CONFIGURE Interfaces Highlight RCS Mode.
  • Page 417 Description of fields Field Option Description <Use Interface:> Yes or No Activates the interface. <Port:> Output Available if <Use Interface: Yes>. Port to be used. <Device:> Output Available if <Use Interface: Yes>. Device to be used. <Protocol:> Output Available if <Use Interface: Yes>. Protocol to be used. Next step IF a device is THEN...

  • Page 418: Export Job

    Config...\Interfaces... - Editing The Interface TPS1200 20.4 Export Job Description • The Export Job interface allows data from a job to be exported from the instrument to an external device. Refer to "13.4 Exporting Data from a Job to another Device" for informa- tion on how to export data via RS232.
  • Page 419 Description of fields Field Option Description <Use Device:> Yes or No Activates the interface. <Port:> Output Available if <Use Interface: Yes>. Port to be used. <Device:> Output The device currently assigned to the selected port within the active configuration set. The device which is selected determines the availability of the next fields.

  • Page 420: Gps Rtk

    Config...\Interfaces... - Editing The Interface TPS1200 20.5 GPS RTK Description • The settings on this screen allow real-time related parameters to be configured. This includes defining if SmartStation should work as a rover and the real-time messages to be used. •...

  • Page 421: Internet

    20.6 Internet Description • The Internet interface • allows accessing the Internet using SmartStation and normally a GPRS device. • can be used together with the Real-Time interface to receive real-time data from a NTRIPCaster via Internet communication. Refer to "33.1 Overview" for information about NTRIP.
  • Page 422 Config...\Interfaces... - Editing The Interface TPS1200 Description of fields Field Option Description <Internet:> Yes or No Activates the Internet interface. <IP Address:> In order to get access to the Internet, an IP address is required. This IP address identifies the receiver in the Internet.
  • Page 423 Field Option Description It is possible to show/hide the User ID. Refer to "28 Tools...\Licence Keys" for further details. <(cont):> User input Allows the <User ID:> string to continue onto a new line. <Password:> User input Some providers ask for a password to allow connecting to the Internet via GPRS.

  • Page 424: Config

    Config...\Interfaces... - Controlling The Device TPS1200 Config...\Interfaces... - Controlling The Device 21.1 Digital Cellular Phones 21.1.1 Overview Description For digital cellular phones, information such as • the reference stations that can be contacted • the phone numbers of the reference stations and •...
  • Page 425 Technologies CDMA Code Division Multiple Access is a high speed data transmission for very effective and flexible use of available ressources such as band width. Users of a cellular phone network occupy the same frequency band. The signal is especially coded for each user. Global System for Mobile Communications is a more efficient version of CDMA technology that uses smaller time slots but faster data transfer rates.

  • Page 426: Configuring A Gsm Connection

    <Bluetooth:> SmartStation detects automatically if the attached device is bluetooth capable. Some GSM’s ask for the identification number of the Bluetooth. The identification number of Leica’s Blue- tooth is 0000. <ID Address:> Available for <Bluetooth: Yes>. The ID address of the Bluetooth device to be used.
  • Page 427 Step Description Refer to chapter <Number:> The number of the digital cellular phone at the selected <Station:> as configured in CONFIGURE Stations to Dial. <Protocol:> The configured protocol of the digital cellular phone at the selected <Station:> as configured in CONFIGURE Stations to Dial.
  • Page 428 Config...\Interfaces... - Controlling The Device TPS1200 Step Description Refer to chapter CODES (F3) accesses CONFIGURE GSM Codes to enter the Personal Identification Number of the SIM card. If the PIN is locked for any reason, for example the wrong PIN was entered, input the Personal UnblocKing code for access to the PIN.

  • Page 429: Configuring A Cdma Connection

    21.1.3 Configuring a CDMA Connection Configure CDMA The following table explains the most common settings. Refer to the stated chapter for more connection step-by- information on screens. step Step Description Refer to chapter Refer to "19.2.2 Accessing CONFIGURE Interfaces" to access CONFIGURE Interfaces.
  • Page 430 Config...\Interfaces... - Controlling The Device TPS1200 Step Description Refer to chapter NEAR (F2) finds the nearest reference station with a digital cellular 21.9 phone of CDMA technology. Available when reference stations to dial are already created in CONFIGURE Stations to Dial. Coordinates of these stations must be known.
  • Page 431 Step Description Refer to chapter CLEAR (F5) deletes the input of the highlighted field. CONT (F1) returns to CONFIGURE Interfaces. Config...\Interfaces... - Controlling The Device TPS1200...

  • Page 432: Modems

    Config...\Interfaces... - Controlling The Device TPS1200 21.2 Modems Description For modems, information such as • the reference stations that can contacted and • the phone numbers of the reference stations can be controlled. Changing the reference station to be dialled is of interest in two cases. Case 1: Two real-time reference stations, each equipped with a digital cellular phone, are set up at two locations belonging to different network providers.
  • Page 433 Step Description Refer to chapter <Modem Type:> The type of modem highlighted when CONFIGURE Modem Connection was accessed. <Station:> The modem reference station to be dialled. Accesses 21.9 CONFIGURE Stations to Dial where new reference stations can be created and existing reference stations can be selected or edited. <Number:>...

  • Page 434: Radios For Gps Real-Time

    Config...\Interfaces... - Controlling The Device TPS1200 21.3 Radios for GPS Real-Time Description For radios the channels on which the radio broadcasts can be changed. Changing channels changes the frequency at which the radio operates. The following radios support channel changing: •...
  • Page 435 Requirements for Pacific Crest radios: • Channel changing must be activated by a Pacific Crest dealer. channel changing • A special licence might be required. Satelline radios: The radio must be in programming mode. This can be set by a Satelline dealer.
  • Page 436 Config...\Interfaces... - Controlling The Device TPS1200 Step Description Refer to chapter CONFIGURE Radio Channel <Radio Type:> The type of radio highlighted when CONFIGURE Radio Channel was accessed. <Channel:> The radio channel. The channel used must be within minimum and maximum allowed input values. The minimum and maximum allowed input values for a radio depend on the number of channels supported by the radio and the spacing between the chan- nels.

  • Page 437: Radios For Remote Control

    21.4 Radios for Remote Control Description For radios the channels on which the radio broadcasts can be changed. Changing channels changes the frequency at which the radio operates. This may be necessary to enable multiple pairs of radios to work simultaneously in the same area without interferring with each other.
  • Page 438 Config...\Interfaces... - Controlling The Device TPS1200 Step Description Refer to chapter Base sets the radio into base mode. The radio modules inside the RX1200 controller and the radio must be set to opposite settings. It is recommended to set the RX1200 controller to Remote and the radio to Base.

  • Page 439: Rs232

    <Bluetooth:> SmartStation detects automatically if the attached device is bluetooth capable. Some devices ask for the identification number of the Bluetooth. The identification number of Leica’s Blue- tooth is 0000. <ID Address:> Available for <Bluetooth: Yes>. The ID address of the Bluetooth device to be used.
  • Page 440 Config...\Interfaces... - Controlling The Device TPS1200 Step Description Refer to chapter SRCH (F4) available for <Bluetooth: Yes>, to search for all available Bluetooth devices. If more than one Bluetooth device is found a list of available devices is provided. SCAN (F5) provides information such as the station ID, latency and 21.8 the data format of incoming signals from reference stations.

  • Page 441: Gprs / Internet Devices

    21.6 GPRS / Internet Devices Description GPRS / Internet devices can be used to access the Internet from SmartStation. Configure Internet The following table explains the most common settings. Refer to the stated chapter for more connection step-by- information on screens. step Step Description...
  • Page 442 Config...\Interfaces... - Controlling The Device TPS1200 Step Description Refer to chapter <APN:> Available for some GPRS / Internet devices. The Access Point Name of a server from the network provider, which allows access to data services. Contact your provider to get the correct APN. Mandatory for using GPRS.

  • Page 443: Internet

    21.7 Internet The Internet connection is available for SmartStation. Description The Internet connection allows SmartStation to be connected to the Internet to receive real- time data. A GPRS / Internet device must be attached. Requirements For Internet • <Internet: Yes> in CONFIGURE Internet Interface. •...
  • Page 444 Config...\Interfaces... - Controlling The Device TPS1200 Step Description Refer to chapter <User:> How SmartStation will operate in the Internet. 33.1 <User: Client> must be selected when using NTRIP as Internet application. Inside the Internet NTRIPClients and NTRIPServers are considered as clients. <User: Server>...
  • Page 445 Step Description Refer to chapter For <User: Server> in CONFIGURE Set NET Port, General page, the fields are input fields. The fields <Range X From:> and <Range X To:> can be used to prevent a user with an IP address outside the defined ranges from accessing the receiver.

  • Page 446: Scanning Reference Stations

    Config...\Interfaces... - Controlling The Device TPS1200 21.8 Scanning Reference Stations Description CONFIGURE Scan Reference Station provides information about the reference stations, with specific types of devices attached, for example a radio, from which real-time corrections are being received. This can also be useful for finding out if anyone else in the area is using a particular radio channel.
  • Page 447 CONFIGURE Scan Reference Station CONT (F1) To select the highlighted reference station and to continue with the subsequent screen. CH- (F2) and CH+(F3) Available for scanning reference stations with radios attached. To switch the radio to one channel lower/higher than the current channel. The reference stations displayed change to those broadcasting on the new channel.

  • Page 448: Configuring The Stations To Dial

    Config...\Interfaces... - Controlling The Device TPS1200 21.9 Configuring the Stations to Dial 21.9.1 Overview Description CONFIGURE Stations to Dial allows new stations to be created, provides a list of reference stations that can be dialled and allows existing stations to be edited. For digital cellular phones of any technology and for modems, the phone numbers of the device at the reference station must be known.

  • Page 449: Accessing Configure Stations To Dial

    21.9.2 Accessing CONFIGURE Stations to Dial Access step-by-step Step Description Refer to chapter Refer to "19.2.2 Accessing CONFIGURE Interfaces" to access CONFIGURE Interfaces. In CONFIGURE Interfaces highlight an interface which has a digital 19.2.2 cellular phone of any technology or modem attached. CTRL (F4) to access CONFIGURE XX Connection.
  • Page 450 Config...\Interfaces... - Controlling The Device TPS1200 Description of columns Column Description Name Name of all available reference stations. Number Phone number of the station to dial.

  • Page 451: Creating A New Station To Dial

    21.9.3 Creating a New Station to Dial Create new station to Step Description dial step-by-step Refer to "21.9.2 Accessing CONFIGURE Stations to Dial" to access CONFIGURE Stations to Dial. NEW (F2) to access CONFIGURE New Station to Dial. CONFIGURE New Station to Dial <Name:>...
  • Page 452 Config...\Interfaces... - Controlling The Device TPS1200 Step Description SHIFT ELL H or SHIFT ORTH (F2) Available for local coordinates. Changes between the ellipsoidal and the orthometric height. STORE (F1) returns to the screen from where CONFIGURE New Points to Dial was accessed.

  • Page 453: Editing A Station To Dial

    21.9.4 Editing a Station to Dial Access step-by-step Step Description Refer to "21.9 Configuring the Stations to Dial" to access CONFIGURE Stations to Dial. EDIT (F3) to access CONFIGURE Edit Station to Dial. All following steps are identical with the creation of a new station to dial. Refer to "21.9.3 Creating a New Station to Dial".

  • Page 454: Configuring The Server To Connect

    Config...\Interfaces... - Controlling The Device TPS1200 21.10 Configuring the Server to Connect 21.10.1 Overview Description CONFIGURE Server to Connect allows new servers to be created, provides a list of servers that can be accessed in the Internet and allows existing servers to be edited. For servers to be accessed in the Internet, the IP address and the TCP/IP port must be known.

  • Page 455: Accessing Configure Server To Connect

    21.10.2 Accessing CONFIGURE Server to Connect Access step-by-step Step Description Refer to chapter Refer to "19.2.2 Accessing CONFIGURE Interfaces" to access CONFIGURE Interfaces. In CONFIGURE Interfaces highlight an interface which has an Internet/Ethernet interface attached. CTRL (F4) to access CONFIGURE XX Connection. Open the choicelist for <Server:>...
  • Page 456 Config...\Interfaces... - Controlling The Device TPS1200 DEL (F4) To delete the highlighted server. MORE (F5) To change between the IP Address and the TCP/IP Port of the server. Description of columns Column Description Name Name of all available servers. IP Address IP addresses of all available servers.

  • Page 457: Creating A New Server

    21.10.3 Creating a New Server Create new server to be Step Description accessed step-by-step Refer to "21.10.2 Accessing CONFIGURE Server to Connect" to access CONFIGURE Server to Connect. NEW (F2) to access CONFIGURE New Server. CONFIGURE New Server <Name:> A unique name for the new server to be accessed. The name may be up to 16 characters long and may include spaces.

  • Page 458: Editing A Server To Connect

    Config...\Interfaces... - Controlling The Device TPS1200 21.10.4 Editing a Server to Connect Access step-by-step Step Description Refer to "21.10 Configuring the Server to Connect" to access CONFIGURE Server to Connect. EDIT (F3) to access CONFIGURE Edit Server. All following steps are identical with the creation of a new server. Refer to "21.10.3 Creating a New Server".
  • Page 459 Config...\Interfaces... - Controlling The Device TPS1200...

  • Page 460: Config

    Config...\SmartStation... TPS1200 Config...\SmartStation... 22.1 Real-Time Mode 22.1.1 Configuration of Real-Time Description The settings on this screen allow GPS real-time related parameters to be configured. This includes defining whether SmartStation should operate as a rover (static, as on a tripod) and the type of GPS real-time messages to be used.
  • Page 461 Rover Activates a rover GPS real-time interface. <R-Time Data:> Leica The proprietary Leica GPS real-time data format. This is recommended when working exclusively with Leica receivers. CMR and CMR+ are compacted formats used to CMR+ receive data from third party receivers.
  • Page 462 Config...\SmartStation... TPS1200 Field Option Description RTCM v3 Message according to RTCM version 3. A new standard format for transmission of Global Navi- gation Satellite System correction information. Higher efficiency than RTCM v2.x. Supports GPS real-time services with significantly reduced band- width.
  • Page 463 Field Option Description • 1011: L1 & L2 GLONASS real-time observa- bles • 1012: Extended L1 & L2 GLONASS real-time observables • 1013: System parameters Pseudorange and phase range values for L1 and L2. Depending on the type of receiver, the data for L1-only or for L1 and L2 are sent out.
  • Page 464 Config...\SmartStation... TPS1200 Field Option Description RTCM 18,19 v2) Message according to RTCM version 2.x. Uncor- rected carrier phase and pseudorange. Message 3 is also generated. Use for GPS real-time opera- tions where the ambiguities will be resolved at the rover. Accuracy at the rover: 1 - 5 cm rms after a successful ambiguity resolution.
  • Page 465 The GPS real- time data formats Leica, RTCM v2.3, CMR and CMR+ contain this information. If the reference data is corrected by abso-...
  • Page 466 Config...\SmartStation... TPS1200 Next step IF additional rover THEN options are not to be config- CONT (F1) closes the screen and returns to the screen from where ured CONFIGURE Real-Time Mode was accessed. are to be configured ROVER (F2). Refer to paragraph "CONFIGURE Additional Rover Options, General page".
  • Page 467 GETID (F5) Available for <Accept Ref: User Defined>. To display and select the station ID of the avail- able reference stations, the latency of the message and the data format. When using radios, the radio channel can be switched and the stations received on the new frequency are displayed.
  • Page 468 <User ID 1:> and User input Available for <Send User ID: Yes>. <User ID 2:> The specific user ID’s to be sent as part of the Leica proprietary NMEA message. By default the serial number of the instrument is displayed. <RTCM Version:>...
  • Page 469 Next step PAGE (F6) changes to the NTRIP page. CONFIGURE Additional Rover Options, NTRIP page CONT (F1) To accept changes and return to the screen from where this screen was accessed. SRCE (F5) To download the NTRIP source table if <Mountpnt:>...
  • Page 470 Config...\SmartStation... TPS1200 Field Option Description <(cont):> User input Allows the <User ID:> string to continue onto a new line. <Password:> User input A password is required to receive data from the NTRIPCaster. Contact the NTRIP administrator for information. <Mountpnt:> User input The NTRIPSource from where GPS real-time data is required.

  • Page 471: Configuration Of Gga Message Sending For Ref Network Applications

    22.1.2 Configuration of GGA Message Sending for Ref Network Applications Description • Most reference networks require an approximate position of the rover. For reference network applications, a rover dials into the reference network and submits its approximate position in form of a NMEA GGA message. •...
  • Page 472 Config...\SmartStation... TPS1200 CONFIGURE Send GGA NMEA CONT (F1) To accept changes and return to the screen from where this screen was accessed. COORD (F2) Available for <GGA Position: From Job> and <GGA Position: LAST/HERE Posn>. To view other coordinate types. Local coordinates are available when a local coordinate system is active.
  • Page 473 Description of fields Field Option Description <GGA Position:> Automatic The current rover position is sent to the reference network. The position is updated and sent every five seconds. From Job A point from the active job can be selected in <Point ID:>.
  • Page 474 Config...\SmartStation... TPS1200 Step Description CONT (F1) returns to CONFIGURE Real-Time Mode. CONT (F1) returns to the screen from where CONFIGURE Real-Time Mode was accessed.

  • Page 475: Point Occupation Settings

    22.2 Point Occupation Settings Description The settings on this screen define the way in which points are occupied and recorded. Access Select Main Menu: Config...\SmartStation...\Point Occupation Settings. Press a hot key configured to access the screen CONFIGURE Point Occupation Settings. Refer to "2.1 Hot Keys" for information on hot keys. Press USER.
  • Page 476 Config...\SmartStation... TPS1200 Description of fields Field Option Description <Pt Occupation:> Normal The way in which coordinates for a point are recorded. This field is fixed to <Pt Occupation: Normal>. <Auto OCCUPY:> Starts point occupation when pressing OCUPY (F1). Starts point occupation automatically when entering SETUP New Station Point.
  • Page 477 Field Option Description Time, Available for <R-Time Mode: None>. Observa- tions or No. of Satel- lites <% Indicator:> Available for <Auto STOP: No>. This is an indicator when to stop the point occupa- tion. Parameters for the selected method are defined with PARAM (F3).
  • Page 478 Config...\SmartStation... TPS1200 Field Option Description <End Survey:> Defines the instrument behaviour once a point is stored. Manual Exits GPS SURVEY when pressing ESC. Automatically Exits GPS SURVEY automatically when pressing STORE (F1) and returns to main menu. Next step IF parameters for THEN <Auto STOP:>...
  • Page 479 CONFIGURE Real-Time Stop Criteria CONT (F1) To accept changes and to return to CONFIGURE Point Occupation Settings. Description of fields The parameters shown on this screen depend on the setting for <STOP Criteria:> in CONFIGURE Point Occupation Settings. Field Option Description <Pos Quality <:>...
  • Page 480 Config...\SmartStation... TPS1200 Field Option Description <Position Update:> User input Sets the number the positions which must be observed before SmartStation stops measuring. Counting the number of positions starts when OCUPY (F1) is pressed. Next step Step Description CONT (F1) returns to CONFIGURE Point Occupation Settings. CONT (F1) returns to TPS1200 Main Menu.

  • Page 481: Satellite Settings

    22.3 Satellite Settings Description The settings on this screen define which satellite system, satellites and satellite signals will be used by SmartStation. Access Select Main Menu: Config...\SmartStation...\Satellite Settings. Within the configuration set wizard. Refer to "11.2 Accessing Configuration Set Management". CONFIGURE Satellite Settings CONT (F1)
  • Page 482 Config...\SmartStation... TPS1200 Description of fields Field Option Description <Sat System:> Defines the satellite signals accepted by the receiver when tracking satellites. GPS Only For normal survey applications requiring high accuracy. Phase solution for real-time and post-processing. GPS & Glonass For applications requiring lower accuracy. Enables satellite tracking under noisier condi- tions like dense tree cover.
  • Page 483 Field Option Description <Suppress MPath:> Automatic or Defines if phase multipath mitigation tech- Always On niques will be used. The recommended setting is Automatic. Next step CONT (F1) returns to TPS1200 Main Menu. Config...\SmartStation... TPS1200...

  • Page 484: Local Time Zone

    Config...\SmartStation... TPS1200 22.4 Local Time Zone Description The settings on this screen help SmartStation to quickly locate and track satellites. Access Select Main Menu: Config...\SmartStation...\Local Time Zone. Within the configuration set wizard. Refer to "11.2 Accessing Configuration Set Management". CONFIGURE Local Time Zone CONT (F1) To accept changes and to return to TPS1200...
  • Page 485 Description of fields Field Option Description <Time Zone:> From The time zone for the current location and local date. -13:00 to +13:00 <Local Time:> User input Setting the local time supports a very fast satellite acquisition. <Local Date:> User input Setting the local date supports a very fast satellite acquisition.

  • Page 486: Quality Control Settings

    Config...\SmartStation... TPS1200 22.5 Quality Control Settings Description The settings on this screen define the limits for coordinate quality and DOP values accepted for point occupations. Access Select Main Menu: Config...\SmartStation...\Quality Control Settings. Press a hot key configured to access the screen CONFIGURE Quality Control Settings. Refer to "2.1 Hot Keys"...
  • Page 487 Description of fields Field Option Description <CQ Control:> None, Pos The type of coordinate quality to be checked before Only, Height storing a point. If activated, the limit defined in Only or Pos & <Maximum CQ:> is checked before storing a point. Height A warning signal is given when the limit is exceeded.

  • Page 488: Logging Of Raw Obs

    Config...\SmartStation... TPS1200 22.6 Logging of Raw Obs Description • When using SmartStation, it is possible to add the ability to log raw GPS data. • The settings on this screen define the logging of raw observations. • This is a protected option and is only activated by the entry of a license key. Access This menu option is licence protected and is only activated by the entry of a licence key.
  • Page 489 CONFIGURE Logging of Raw Obs CONT (F1) To accept changes and return to the screen from where this screen was accessed. Description of fields Field Option Description <Log Raw Obs:> Never Available unless <R-Time Mode: Reference>. No raw observation logging during either static or moving intervals.
  • Page 490 Config...\SmartStation... TPS1200 Field Option Description <Switch Off:> Choicelist This option determines when SmartAntenna is turned off. The selected time is activated whenever SmartStation leaves GPS mode. This option is directly linked to <Switch Off:> in CONFIGURE Start Up & Power Down. Refer to "18.6 Start Up &...
  • Page 491 Config...\SmartStation... TPS1200...

  • Page 492: Tools

    Tools...\Format Memory Device TPS1200 Tools...\Format Memory Device Description Allows the CompactFlash card, the internal memory, if fitted, and the System RAM to be formatted. All data will be erased. Refer to "Appendix B Memory Types" for more information on the types of memory devices available. Access Select Main Menu: Tools...\Format Memory Device.
  • Page 493 Field Option Description CF Card or For instruments with CompactFlash card and internal Internal memory. Memory <Format Method:> Format Quick After formatting, data is not visible anymore but still exists on the memory device and is overwritten as and when required. Format Data is fully deleted.

  • Page 494: Tools

    Tools...\Transfer Objects... TPS1200 Tools...\Transfer Objects... Description This chapter describes the basic procedure for transferring objects between the Compact- Flash card, the System RAM and the internal memory, if fitted. Refer to "Appendix C Direc- tory Structure of the Memory Device" for information about file types and locations of files on the CompactFlash card.
  • Page 495 Description of fields Field Option Description <From:> Memory device to transfer object from. CF card Transfer from CompactFlash card. System RAM Transfer from System RAM. Available unless object to transfer is a job. Internal Transfer from internal memory, if fitted. Available if Memory the object to transfer is a job.
  • Page 496 Tools...\Transfer Objects... TPS1200 Field Option Description <Antenna:> Choicelist To select the antenna records to be transferred. Next step IF all XX THEN are to be transferred ALL (F3) transfers all objects in list. are not to be trans- CONT (F1) transfers selected object. ferred...
  • Page 497 Tools...\Transfer Objects... TPS1200...

  • Page 498: Tools

    Tools...\Upload System Files... TPS1200 Tools...\Upload System Files... 25.1 Application Programs Description Application program uploads are possible from the CompactFlash card to the application programs memory. These files are stored in the \SYSTEM directory of the memory device and use the extension *.a*. Access Select Main Menu: Tools...\Upload System Files...\Application Programs.
  • Page 499 Description of fields Field Option Description <From:> Output Upload from CompactFlash card. <To:> Output Upload to application program memory. <Program:> Choicelist List of program files stored on the CompactFlash card. <Version:> Output Version of the program file chosen. Next step CONT (F1) uploads the selected application program.

  • Page 500: System Languages

    Tools...\Upload System Files... TPS1200 25.2 System Languages Description System language uploads are possible from the CompactFlash card to the instrument. These files are stored in the \SYSTEM directory of the active memory device and use an extension that is individual to each language. Access Select Main Menu: Tools...\Upload System Files...\System Languages.
  • Page 501 Field Option Description <Language:> Choicelist List of language files stored on the CompactFlash card. <Version:> Output Version of the language file. Next step CONT (F1) uploads the selected language. It is not possible to have more than three language files stored on the instrument. English is always available as the default language and cannot be deleted.

  • Page 502: Instrument Firmware

    Tools...\Upload System Files... TPS1200 25.3 Instrument Firmware Description Firmware uploads are possible from the CompactFlash card to the instrument, Smart- Antenna or RX1200. These files are stored in the \SYSTEM directory of the active memory device and use the extension *.fw. Firmware can be uploaded from LGO on a PC directly through a serial interface to the CompactFlash card in the instrument and from there to the instrument or the RX1200.
  • Page 503 Description of fields Field Option Description <From:> Output Upload from CompactFlash card. <To:> Output Upload to the instrument, SmartAntenna or the RX1200. <Firmware:> Choicelist List of firmware files stored on the CompactFlash card. Firmware for SmartAntenna is a separate file independant from the instrument firmware.

  • Page 504: Overview

    Tools...\Calculator TPS1200 Tools...\Calculator 26.1 Overview Description The calculator can be used to perform the following arithmetic operations such as • addition, subtraction, multiplication and division • statistics • trigonometry, hyperbolic trigonometry and calculations with Pi • polar, rectangular and angle conversions •...

  • Page 505: Accessing The Calculator

    26.2 Accessing the Calculator Access Select Main Menu: Tools...\Calculator. Press a hot key configured to access the screen TOOLS XX Calculator. Refer to "2.1 Hot Keys" for information on hot keys. Press USER. Refer to "2.2 USER Key" for information on the USER key. Press CALC in any screen when editing an input field for numeric characters, such as <Azimuth:>...

  • Page 506: Configuring The Calculator

    Tools...\Calculator TPS1200 26.3 Configuring the Calculator Access step-by-step Step Description Refer to "26.2 Accessing the Calculator" to access TOOLS XX Calculator. SHIFT CONF (F2) to access TOOLS Calculator Configuration. TOOLS Calculator Configura- tion CONT (F1) To accept changes and return to the screen from where this screen was accessed.
  • Page 507 Field Option Description Standard The principle of conventional pocket calculators. Refer to "26.1 Overview" for more information. Refer to "26.4.2 Standard Mode" for a working example. <Angle Unit:> The unit used for trigonometric functions in the calcu- lator. The selection here is independent from the angle setting in CONFIGURE Units &...

  • Page 508: Using The Calculator

    Tools...\Calculator TPS1200 26.4 Using the Calculator 26.4.1 RPN Mode Requirements <Operatng Mode: RPN> in TOOLS Calculator Configuration. Access Refer to "26.2 Accessing the Calculator" to access TOOLS RPN Calculator. TOOLS Refer to paragraph "Working example" for information about the operating principle. RPN Calculator The function keys F1-F6 are allocated seven times.
  • Page 509 Description of fields Field Option Description First field on the Output The unit used for trigonometric functions in the calcu- screen lator as configured in TOOLS Calculator Configura- tion. Degrees Radians GRAD <ΣY:> Output The result of the sum or difference of values in <Y:> using Σ+ (F1) and Σ- (F2).
  • Page 510 Tools...\Calculator TPS1200 Working example Task: Calculate (3 + 5) / (7 + 6). Step Description Type in 3. ENTER Type in 5. ENTER <Y: 3>, <X: 5> + (F1) <X: 8> Type in 7. ENTER <Y: 8>, <X: 7> Type in 6. ENTER <Z: 8>, <Y: 7>, <X: 6>...

  • Page 511: Standard Mode

    26.4.2 Standard Mode Requirements <Operatng Mode: Standard> in TOOLS Calculator Configuration. Access Refer to "26.2 Accessing the Calculator" to access TOOLS Standard Calculator. TOOLS Refer to paragraph "Working example" for information about the operating principle. Standard Calculator The function keys F1-F6 are allocated seven times.
  • Page 512 Tools...\Calculator TPS1200 Field Option Description Radians GRAD <Σ:> Output The result of the sum or difference of values in the last field on the screen using Σ+ (F1) and Σ- (F2). Third to sixth field on Output Previously entered value the screen Latest operation including result # indicates that the value is cut after the third...
  • Page 513 Step Description Last field on the screen displays 8.00000. such that STO (F1) is visible. STO (F1) such that + (F1) is visible. Type in 7. ENTER + (F1) Type in 6. ENTER Last field on the screen displays 13.00000. Remember 13.00000.

  • Page 514: Description Of Softkeys

    Tools...\Calculator TPS1200 26.4.3 Description of Softkeys Overview of softkeys The softkeys shown and described are those of <Operatng Mode: RPN>. Most of the softkeys are identical and their functionality is similar to that for <Operatng Mode: Standard>. The function keys F1-F6 are allocated seven times with softkeys. Using the various allocations can be accessed.
  • Page 515 Description of softkeys First level + (F1) To add <X:> and <Y:>. - (F2) To subtract <X:> from <Y:>. * (F3) To multiply <X:> by <Y:>. / (F4) To divide <Y:> by <X:>. +/- (F5) To change between positive and negative algebraic sign for <X:>.
  • Page 516 Tools...\Calculator TPS1200 to access the Third level SIN (F1) To calculate sine of <X:>. COS(F2) To calculate cosine of <X:>. TAN (F3) To calculate tangent of <X:>. ASIN (F4) To calculate arcsine of <X:>. ACOS (F5) To calculate arccosine of <X:>. ATAN (F6) To calculate arctangent of <X:>.
  • Page 517 to access the Fifth level POLAR (F1) Conversion of rectangular coordinates into polar coordinates. The y coordinate must be visible in <Y:> and the x coordinate in <X:> when pressing this key. The angle is displayed in <Y:> and the distance in <X:>. RECT(F2) Conversion of polar coordinates into rectan- gular coordinates.
  • Page 518 Tools...\Calculator TPS1200 e^X (F4) <X:> To calculate e Y^X (F6) <X:> To calculate <Y:> to access the Seventh level STO (F1) To store <X:> to the memory. Up to ten values can be stored. RCL (F2) To recall a value for <X:> from the memory. Up to ten values can be recalled.

  • Page 519: Calling And Closing The Calculator From An Input Field For Numeric Characters

    26.4.4 Calling and Closing the Calculator from an Input Field for Numeric Characters COGO traverse calculation is used as example. Call and close calcu- Step Description Refer to lator step-by-step chapter Select Main Menu: Programs...\COGO to access the screen COGO COGO Begin.
  • Page 520 Tools...\Calculator TPS1200 Step Description Refer to chapter Perform the calculations. 26.4.1, 26.4.2 SHIFT DONE (F4) to return to COGO Traverse Input. The calculated value is taken over for <Azimuth:>.
  • Page 521 Tools...\Calculator TPS1200...

  • Page 522: Tools...\File Viewer

    Tools...\File Viewer TPS1200 Tools...\File Viewer Description Allows ASCII files on the memory device to be viewed. The ASCII file can have up to 500 KB. Refer to "Appendix C Directory Structure of the Memory Device" for more information on the contents of folders on the memory device.
  • Page 523 DEL (F4) Available for a file being highlighted. To delete the highlighted file. MORE (F5) To display information about the size of a directory or file. CFCRD (F6) or INTL (F6) Available for instruments with internal memory. To change between viewing jobs stored on the CompactFlash card or internal memory.
  • Page 524 Tools...\File Viewer TPS1200 Next step THEN the screen is to be ESC to return to TPS1200 Main Menu. quit a directory is to highlight the directory and DIR (F2). accessed a file is to be viewed highlight the file and VIEW (F3). Refer to "TOOLS View File: File Name".
  • Page 525 Keys Keys Function Moves up. Moves down. Moves right. Moves left. Next step CONT (F1) returns to the screen from where TOOLS View File: File Name was accessed. Tools...\File Viewer TPS1200...

  • Page 526: Tools

    Tools...\Licence Keys TPS1200 Tools...\Licence Keys Description • A licence key can be used to activate application programs and protected options and can be used to define the expiry date of the software maintenance. Refer to "30.4 STATUS: System Information" to find out how to check the expiry date of the software maintenance. •...
  • Page 527 TOOLS Enter Licence Key CONT (F1) To accept changes and return to TPS1200 Main Menu or continue with application program. SHIFT DEL (F4) To delete all licence keys on the instrument. Description of fields Field Option Description <Method:> The method used to input the licence key to activate the application program or the protected options or the software maintenance.
  • Page 528 Tools...\Licence Keys TPS1200 Field Option Description <Key:> User input Available for <Method: Manual Entry of Key>. The licence key required to activate an application program. Entry is not case sensitive. Next step CONT (F1) returns to TPS1200 Main Menu or continues with selected application program. Showing/Hiding Showing The User ID the User ID for the...
  • Page 529 Hiding the User ID 1) Type "hide user id" (not case sensitive) and 2) The user Id will then always be hidden. press CONT (F1) to continue. Tools...\Licence Keys TPS1200...

  • Page 530: Tools

    29.1 Overview Description Leica instruments are manufactured, assembled and adjusted to the best possible quality. Quick temperature changes, shock or stress can cause deviations and influence the instru- ment accuracy. It is therefore recommended to check and adjust the instrument from time to time. This can be done in the field by running through specific measurement procedures.
  • Page 531 Precise measurements To get precise measurements in the daily work, it is important: • To check and adjust the instrument from time to time. • To take high precision measurements during the check and adjust procedures. • To measure targets in two faces. Some of the instrument errors are eliminated by aver- aging the angles from both faces.
  • Page 532 Tools...\Check & Adjust TPS1200 The instrument should be protected from direct sunlight in order to avoid thermal warming in general and especially on one side of the instrument housing. It is also recommended to avoid strong heat shimmer and air turbulences.The best conditions can be found usually early in the morning and with overcast sky.

  • Page 533: Details On Instrument Errors

    29.2 Details on Instrument Errors General Instrument errors occur, if the standing axis, the tilting axis and the line of sight are not precisely perpendicular to each other. Hz collimation error (c) a) Tilting axis b) Line perpendicular to tilting axis c) Hz collimation error (c), also called line of sight error d) Line of sight...
  • Page 534 Tools...\Check & Adjust TPS1200 Tilting axis error (a) a) Axis perpendicular to the vertical axis b) Mechanical vertical axis of the instrument, also called standing axis c) Tilting axis error d) Tilting axis TPS12_027 The tilting axis error (a) is caused by the deviation between the mechanical tilting axis and the line perpendicular to the vertical axis.
  • Page 535 Vertical index error (i) a) Mechanical vertical axis of the instrument, also called standing axis b) Axis perpendicular to the vertical axis c) V = 90° reading in a specific face d) Vertical index error TPS12_023 A vertical index error (i) exists, if the 0° mark of the vertical circle reading doesn’t coincide with the mechanical vertical axis of the instrument, also called standing axis.
  • Page 536 Tools...\Check & Adjust TPS1200 Compensator index errors (l, t) a) Mechanical vertical axis of the instrument, also called standing axis b) Plumb line c) Longitudinal component (l) of the compensator index error d) Transversal component (t) of the compensator index error TPS12_022 The compensator index errors (l, t) occur, if the vertical axis of the instrument and the plumb- line are parallel but the zero points of the compensator and the circular level do not coincide.
  • Page 537 ATR collimation errors a) Centre of prism b) Crosshairs c) V component of ATR collimation error TPS12_028 d) Hz component of ATR collimation error The ATR collimation error is the angular divergence between the line of sight, which means the direction in which the crosshairs points, and the ATR CCD camera axis, which detects the centre of the prism.
  • Page 538 Tools...\Check & Adjust TPS1200 Summary of errors to be Instrument error Effects Hz Effects V Elimination Automatically adjusted electronically with two face corrected with measurement proper adjust- ment c - Hz collimation error a - Tilting axis error l - Compensator index error t - Compensator index error i - V-Index error ATR Collimation error...

  • Page 539: Accessing Check & Adjust Menu

    29.3 Accessing Check & Adjust Menu Access Select Main Menu: Tools...\Check & Adjust... Press a hot key configured to access the screen TOOLS Check & Adjust Menu. Refer to "2.1 Hot Keys" for information on hot keys. Press USER. Refer to "2.2 USER Key" for information on the USER key. TOOLS Check &...
  • Page 540 Tools...\Check & Adjust TPS1200 Description of the Check & Adjust functions Function Description Refer to chapter Combined (l,t,i,c,ATR) To determine the l, t, i, c and ATR instrument errors. 29.5 Tilting Axis (a) To determine the tilting axis (a) error. 29.6 Compensator (l,t) To determine the compensator (l, t) errors.

  • Page 541: Configure Check & Adjust

    29.4 Configure Check & Adjust Access step-by-step Step Description Refer to "29.3 Accessing Check & Adjust Menu" to access TOOLS Check & Adjust Menu. CONF (F2) to access TOOLS Configuration. TOOLS Configuration, Parameters page CONT (F1) To accept the settings and to return to the screen TOOLS Check &...
  • Page 542 Tools...\Check & Adjust TPS1200 Description of fields Field Option Description <Adjust 2 weeks, A reminder message is displayed each time the Reminder:> 1 month, instrument is turned on if one or more adjustment 3 months, values were determined longer ago than the time 6 months, specified with this parameter.
  • Page 543 Field Option Description Opening the choicelist accesses XX Logfiles where a name for a new logfile can be created and an existing logfile can be selected or deleted. <Format File:> Choicelist Available for <Write Logfile: Yes>. A format file defines which and how data is written to a logfile.

  • Page 544: Combined Adjustment (L, T, I, C And Atr)

    Tools...\Check & Adjust TPS1200 29.5 Combined Adjustment (l, t, i, c and ATR) Access step-by-step Step Description Refer to "29.3 Accessing Check & Adjust Menu" to access TOOLS Check & Adjust Menu. In TOOLS Check & Adjust Menu highlight Combined (l,t,i,c,ATR). CONT (F1) to access TOOLS Combined I.
  • Page 545 <ATR Adjust: On> Includes the determination of the ATR, Hz and V adjustment values if an ATR is available. It is recommended to use a clean Leica circular prism as target, for example a GPR1. Do not use a 360° prism.
  • Page 546 Tools...\Check & Adjust TPS1200 Step Description Refer to chapter Aim the telescope accurately at a target at a distance of about 100 m. The target must be positioned within ± 9°/± 10 gon of the hori- zontal plane The procedure can be started in any telescope face.
  • Page 547 Step Description Refer to chapter MEAS (F1) to measure and to continue to the next screen. Motorised instruments change automatically to the other face. 180° 180° TPS12_025 Non-motorised instruments guide to the other face using the TOOLS Telescope Positioning screen. TOOLS Combined II MEAS (F1) to measure the same target in the other face and to calcu- late the instrument errors.
  • Page 548 Tools...\Check & Adjust TPS1200 Step Description Refer to chapter <No. of Meas:> Shows the number of runs executed. One run consists of a measurement in face I and face II. All other fields display the standard deviations of the determined adjustment errors.
  • Page 549 MORE (F5) To view additional information about the current used old instrument errors. REDO (F2) To reject all results and to repeat the complete check and adjust procedure. Refer to step 2. of paragraph "Combined procedure step-by- step". Description of columns and fields Column Option Description...
  • Page 550 Tools...\Check & Adjust TPS1200 IF the results are THEN to be determined REDO (F2) rejects all new determined adjustment values and repeats again the whole procedure. Refer to step 2. of paragraph "Combined proce- dure step-by-step".

  • Page 551: Tilting Axis Adjustment (A)

    29.6 Tilting Axis Adjustment (a) Access step-by-step Step Description Refer to "29.3 Accessing Check & Adjust Menu" to access TOOLS Check & Adjust Menu. In TOOLS Check & Adjust Menu highlight Tilting Axis (a). CONT (F1) to access TOOLS Tilting-Axis Adjustment I. Description This procedure determines the following instrument error: Tilting axis error...
  • Page 552 Tools...\Check & Adjust TPS1200 Step Description Refer to chapter TOOLS Tilting-Axis Adjustment I Aim the telescope accurately at a target at a distance of about 100 m. For distances less than 100 m make sure to precisely point to the target. The target must be positioned within at least 27°/30 gon above or beneath the hori-...
  • Page 553 Step Description Refer to chapter MEAS (F1) to measure and to continue to the next screen. Motorised instruments change automatically to the other face. 180° 180° TPS12_025 Non-motorised instruments guide to the other face using the TOOLS Telescope Positioning screen. TOOLS Tilting Axis Adjustment II MEAS (F1) to measure the same target in the other face and to calcu- late the tilting axis error.
  • Page 554 Tools...\Check & Adjust TPS1200 Step Description Refer to chapter <No. of Meas:> Shows the number of runs executed. One run consists of a measurement in face I and face II. <σ a T-axis:> shows the standard deviation of the determined tilting axis error.
  • Page 555 Description of columns and fields Column Option Description New [g] ----- Shows the new determined and averaged tilting axis error. The unit is displayed in []. Old [g] ----- Shows the old instrument error, which is currently valid on the instrument. The unit is displayed in []. Next step IF the result is THEN...

  • Page 556: Compensator Adjustment (L, T)

    Tools...\Check & Adjust TPS1200 29.7 Compensator Adjustment (l, t) Access step-by-step Step Description Refer to "29.3 Accessing Check & Adjust Menu" to access TOOLS Check & Adjust Menu. In TOOLS Check & Adjust Menu highlight Compensator (l,t). CONT (F1) to access TOOLS Compensator Adjustment. Description The compensator adjustment procedure determines the following instrument errors: Compensator longitudinal index error...
  • Page 557 Step Description Refer to chapter Select the option: Compensator (l, t) TOOLS Compensator Adjustment MEAS (F1) to measure the first face. No target has to be aimed at. Motorised instruments change to the other face and 180° release a measurement automatically. Non-motorised instruments guide to the other face using the TOOLS Telescope Positioning screen.
  • Page 558 Tools...\Check & Adjust TPS1200 Step Description Refer to chapter MEAS (F5) if more runs have to be added. Continue with step 2. CONT (F1) to accept the measurements and to access TOOLS Comp Adjustment Results. No more runs can be added later. TOOLS Comp Adjustment Results...
  • Page 559 Column Option Description Old [g] ----- Shows the old instrument errors, which are currently valid on the instrument. The unit is displayed in []. Next step IF the results are THEN to be stored CONT (F1) overwrites the old instrument errors with the new ones. to be determined REDO (F2) rejects the new determined instrument errors and repeats again...

  • Page 560: Current Instrument Errors

    Tools...\Check & Adjust TPS1200 29.8 Current Instrument Errors Access Step Description Refer to "29.3 Accessing Check & Adjust Menu" to access TOOLS Check & Adjust Menu. In TOOLS Check & Adjust Menu highlight Current Values. CONT (F1) to access TOOLS Current Values. TOOLS Current Values CONT (F1)
  • Page 561 Note that the temperature of the environment around the instrument may differ from the temperature shown on the screen as it is the internal temperature of the instrument. Tools...\Check & Adjust TPS1200...

  • Page 562: Adjusting The Circular Level Of The Instrument And Tribrach

    Tools...\Check & Adjust TPS1200 29.9 Adjusting the Circular Level of the Instrument and Tribrach Adjusting the circular level step-by-step SHIFT TPS12_030 Step Description Place and secure the instrument into the tribrach and onto a tripod. Using the tribrach footscrews, level the instrument with the electronic level. SHIFT F12 to access STATUS Level &...
  • Page 563 Step Description Tribrach: If it extends beyond the circle, use the supplied allen key to centre it with the adjustment screws. After the adjustments, all adjusting screws should have the same tightening tension and no adjusting screw shall be loose. Tools...\Check &...

  • Page 564: Adjustment Of The Reflectorless Edm

    29.10 Adjustment of the Reflectorless EDM Chapter validity Refer to the Leica TPS1200 User Manual for details. General The red laser beam used for measuring without reflector is arranged coaxially with the line of sight of the telescope, and emerges from the objective port. If the instrument is well adjusted, the red measuring beam coincides with the visual line of sight.
  • Page 565 Inspecting the direction of the beam step-by- step TPS12_36 The following table explains the most common settings. Refer to the stated chapter for more information on screens. Step Description Refer to chapter Set up the provided target plate between 5 m and 20 m with the grey reflective side facing the instrument.
  • Page 566 Tools...\Check & Adjust TPS1200 Step Description Refer to chapter Align the instrument crosshairs to the centre of the target plate and then inspect the position of the red laser dot on the target plate. The red dot cannot be seen through the telescope. Look at the target plate from just above the telescope or from just to the side of it.
  • Page 567 The following table explains the most common settings. Refer to the stated chapter for more information on screens. Step Description Refer to chapter Carefully pull the two plugs out from the adjustment ports on top side of the telescope housing in face II. Make sure not to break the strings of the two plugs.

  • Page 568: Adjusting The Circular Level Of The Prism Pole

    Tools...\Check & Adjust TPS1200 29.11 Adjusting the Circular Level of the Prism Pole Adjusting the circular level step-by-step TPS12_232 Step Description Suspend a plumb line. Using a pole bipod, align the prism pole parallel to the plumb line. Check the position of the circular level on the prism pole. a) If the circular level is centered, no adjustment is necessary.

  • Page 569: Inspecting The Laser Plummet Of The Instrument

    The laser plummet is located in the vertical axis of the instrument. Under normal conditions of use, the laser plummet does not need adjusting. If an adjustment is necessary due to external influences, the instrument has to be returned to any Leica Geosystems authorized service workshop.
  • Page 570 If the centre of the laser dot describes a perceptible circular movement or moves more than 3 mm away from the point which was first marked, an adjustment may be required. Inform your nearest Leica Geosystems authorized service workshop. Depending on brightness and surface, the diameter of the laser dot can vary. At...

  • Page 571: Servicing The Tripod

    29.13 Servicing the Tripod Servicing the tripod step-by-step TPS12_029 The following table explains the most common settings. Step Description The connections between metal and timber components must always be firm and tight. Tighten the leg cap screws moderately, with the supplied allen key. Tighten the articulated joints on the tripod head just enough to keep the tripod legs open when lifting the tripod off the ground.

  • Page 572: Status

    STATUS TPS1200 STATUS 30.1 STATUS Functions Description The STATUS functions help using the instrument by showing the state of many instrument functions. All fields are output fields. Unavailable information is indicated by -----. Access Press USER and then STAT (F3). Refer to "2.2 USER Key" for information on the USER key. STATUS Status Menu CONT (F1)
  • Page 573 Description of the STATUS function Description Refer to STATUS functions chapter Station Information Information related to the current station set on the 30.2 instrument. Battery & Memory Information related to use and status of battery and 30.3 memory. System Information Information related to the instrument hardware and 30.4 firmware.

  • Page 574: Status: Station Information

    STATUS TPS1200 30.2 STATUS: Station Information Access Select STATUS: Station Information. Refer to "30.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS Station Information. Refer to "2.1 Hot Keys" for information on hot keys. STATUS Station Information CONT (F1)
  • Page 575 Field Description <Easting:> Easting value of the instrument position. <Northing:> Northing value of the instrument position. <Height:>, If no coordinate system is selected the orthometric height <Height:> of the instrument position is displayed. For a selected coordinate <Local Ell Ht:> or system, orthometric or ellipsoidal height can be displayed.

  • Page 576: Status: Battery & Memory

    STATUS TPS1200 30.3 STATUS: Battery & Memory Access Select STATUS: Battery & Memory. Refer to "30.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS Battery & Memory. Refer to "2.1 Hot Keys" for information on hot keys. Press USER.
  • Page 577 STATUS Battery & Memory, Battery page CONT (F1) To exit STATUS Battery & Memory. PAGE (F6) To change to another page on this screen. Description of fields Field Description Any field The percentage of remaining power capacity for all batteries are displayed numerically.
  • Page 578 STATUS TPS1200 STATUS If no information for a field is available, for example no CompactFlash card is inserted, then Battery & Memory, ----- is displayed. Memory page CONT (F1) To exit STATUS Battery & Memory. PAGE (F6) To change to another page on this screen. Description of fields Field Description...
  • Page 579 Field Description <Mem System:> The total/free system memory. The system memory stores • instrument related files such as system settings. • survey related files such as codelists and configuration sets. Next step CONT (F1) to exit STATUS Battery & Memory. STATUS TPS1200...

  • Page 580: Status: System Information

    STATUS TPS1200 30.4 STATUS: System Information Access Select STATUS: System Information. Refer to "30.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS System Information. Refer to "2.1 Hot Keys" for information on hot keys. Press USER.
  • Page 581 Field Description <GUS74:> Instrument equipped with GUS74 or not. <Extd GeoCOM:> Instrument equipped with extended GeoCOM or not. <L2C tracking:> SmartStation option. The ability to track the L2C signal. <MMT:> SmartStation option. The availability of multipath mitigation. <GLONASS ready:> SmartStation option. The availability of GLONASS each Wed. <GLONASS perm:>...
  • Page 582 STATUS TPS1200 Field Description <Boot:> Firmware version of the boot software. <API:> Firmware version for the application program interface. <EF Interface:> Firmware version for the electric front interface. <Keyboard/Display:> Firmware version for the graphical user interface. Next step PAGE (F6) changes to the Application page. STATUS Shows the versions of all uploaded application programs.

  • Page 583: Status: Interfaces

    30.5 STATUS: Interfaces... Description STATUS Interfaces gives an overview of all interfaces with the port and the devices currently assigned. Access Select STATUS: Interfaces..Refer to "30.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS Interfaces. Refer to "2.1 Hot Keys"...
  • Page 584 STATUS TPS1200 DEVCE (F5) Available for GPS RTK or Internet being high- lighted. To view the status of the attached device. Refer to "30.8.2 Real-Time Status" paragraph "STATUS Real-Time Input, Device page". Next step CONT (F1) exits STATUS Interfaces.

  • Page 585: Status: Bluetooth

    30.6 STATUS: Bluetooth Description This screen shows • Bluetooth ports available and configured. • the device attached and connected to each Bluetooth port. • the ID address of each device. Access Select STATUS: Bluetooth. Refer to "30.1 STATUS Functions" on how to access the STATUS menu. Tap the Bluetooth icon.

  • Page 586: Status: Level & Laser Plummet

    STATUS TPS1200 30.7 STATUS: Level & Laser Plummet Description The electronic level is shown and can be centred. Access Select STATUS: Level & Laser Plummet. Refer to "30.1 STATUS Functions" on how to access the STATUS menu. Press SHIFT F12. Press a hot key configured to access the screen STATUS Level &...
  • Page 587 STATUS Level & Laser Plummet, Level page CONT (F1) To exit STATUS Level & Laser Plummet. PAGE (F6) To change to another page on this screen. Description of fields Field Description <Tilt L:> Longitudinal tilt of the vertical axis. <Tilt T:> Transversal tilt of the vertical axis.
  • Page 588 STATUS TPS1200 STATUS Description of fields Level & Laser Plummet, Field Option Description Laser Plummet page <Laser Plummet:> On or Off To turn the laser plummet on or off. Is always set on when accessing this screen. Changing this setting turns the laser plummet on or off immediately.

  • Page 589: Status: Smartstation

    30.8 STATUS: SmartStation 30.8.1 Satellite Status Description This screen shows information related to the satellites ordered by the elevation angle. Access Select STATUS: SmartStation...\Satellite Status. Refer to "30.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS Satellites. Refer to "2.1 Hot Keys"...
  • Page 590 STATUS TPS1200 CONT (F1) To exit STATUS Satellites. GPS X (F2) To hide or view the GPS satellites (shown by the prefix G). Only available for SmartStation with the ATX1230 GG antenna, where the configured Sat System is GPS&GLONASS. GLO X (F3) To hide or view the GLONASS satellites (shown by the prefix R).
  • Page 591 Description of columns Column Description The Pseudo Random Noise number (GPS) or the slot number (GLONASS) of the satellites. Elev The elevation angle in degrees. The arrows indicate if the satellite is rising or falling. Azmth The azimuth of the satellite. S/N 1 and S/N 2 The signal to noise ratio on L1 and L2.
  • Page 592 STATUS TPS1200 CONT (F1) To exit STATUS Satellites. GPS X (F2) To hide or view the GPS satellites (shown by the prefix G). Only available for SmartStation with the ATX1230 GG antenna, where the configured Sat System is GPS&GLONASS. GLO X (F3) To hide or view the GLONASS satellites (shown by the prefix R).
  • Page 593 Description of symbols Symbol Description Satellites above the <Cut Off Angle:> configured in CONFIGURE Satel- lite Settings. Satellites below the <Cut Off Angle:> configured in CONFIGURE Satel- lite Settings. Next step THEN the receiver is a real- PAGE (F6) changes to the Reference page. Refer to paragraph time rover "STATUS Satellites, Reference page".

  • Page 594: Real-Time Status

    STATUS TPS1200 30.8.2 Real-Time Status Description This screen shows information related to real-time data, for example the data link and the device used to receive real-time data. Access This screen is accessible for <R-Time Mode: Rover> in CONFIGURE Real-Time Mode. Select STATUS: SmartStation...\Real-Time Status.
  • Page 595 STATUS Real-Time Input, General page CONT (F1) To exit STATUS Real-Time Input. DATA (F4) To view the data being received. Depending on <R-Time Data:>, the shown data differ. Refer to paragraph "STATUS Real-Time Input Data". PAGE (F6) To change to another page on this screen. Description of fields Field Description...
  • Page 596 STATUS TPS1200 Field Description <Ref Network:> The type of reference network in use. Next step PAGE (F6) changes to the Device page. Refer to paragraph "STATUS Real-Time Input, Device page". STATUS The content of this page differs for each type of device in use. Real-Time Input, Device page CONT (F1)
  • Page 597 For all devices available Description of fields Field Description <Name:> The name of the device. For RS232 Description of fields Field Description <Type:> The type of device. <Port:> The port to which the device is connected. <Bluetooth:> Available if device is connected via bluetooth. Indicates the state of the connection.
  • Page 598 STATUS TPS1200 Field Description <Status:> The actual mode of the digital cellular phone. The options are Unknown, Detection and Registered. <Bluetooth:> Available if device is connected via bluetooth. Indicates the state of the connection. <Signal:> Indication of received signal strength of the digital cellular phone network.
  • Page 599 It is different from the point ID of the reference station. <Antenna Ht:> • For <R-Time Data: Leica>, <R-Time Data: RTCM v3.0> or <R- Time Data: RTCM X v2> with <RTCM Version: 2.3>: The antenna height at the reference from the marker to the MRP.
  • Page 600 STATUS TPS1200 Field Description • For real-time messages which do not include antenna Information: Phase Centre of L1. Next step THEN other coordinate COORD (F2). Local coordinates are available when a local coordi- types are to be nate system is active. viewed this screen is to be CONT (F1) exits STATUS Real-Time Input.
  • Page 601 Access DATA (F4) on STATUS Real-Time Input, General page. CONT (F1) To return to STATUS Real-Time Input. SAT- (F2) To display information about the satellite with the next smaller PRN. SAT+ (F3) To display information about the satellite with the next larger PRN. Description of fields The data being received from the satellites and the layout of the screen depend on the active real-time data format.
  • Page 602 STATUS TPS1200 Field Description <Msg 18 L1:>, <Msg 18 L2:> The uncorrected carrier phases for L1 and L2. <Msg 20 L1:>, <Msg 20 L2:> The carrier phase corrections for L1 and L2. <Code L1:>, <Code L2:> The pseudorange between the antenna to the satellite for L1 and L2.

  • Page 603: Current Position

    30.8.3 Current Position Description This screen shows information related to the current SmartStation position. For real-time rover configurations the baseline vector is also shown. MapView shows the current position in a graphical format. Access Select STATUS: SmartStation...\Current Position. Refer to "30.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS Position.
  • Page 604 STATUS TPS1200 STATUS Position, CONT (F1) Position page To exit STATUS Position. COORD (F2) To see other coordinate types. Local coordi- nates are available when a local coordinate system is active. PAGE (F6) To change to another page on this screen. SHIFT ELL H (F2) and SHIFT ORTH (F2) Available for local coordinates.
  • Page 605 Next step THEN the receiver is a real- PAGE (F6) changes to the Baseline page. Refer to paragraph time rover "STATUS Position, Baseline page". the receiver is not CONT (F1) exits STATUS Position. configured for real- time STATUS Information on the baseline vector is displayed. Position, Baseline page Next step...

  • Page 606: Logging Status

    STATUS TPS1200 30.9 Logging Status Description This screen shows information related to logging of raw observations. Access Select STATUS: Survey...\Logging Status. Refer to "30.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS Logging. Refer to "2.1 Hot Keys"...
  • Page 607 Description of fields Field Description <Logging Raw Obs:> YES or NO. <All Static Obs:> The number of static epochs recorded in the current job. <Recorded DB-X Pts:> The number of manually occupied points and auto points stored in the job. Next step PAGE (F6) changes to the Reference page.
  • Page 608 STATUS TPS1200 Description of fields Field Description <Log Static Obs:> The logging rate at the reference. This information is shown if the real-time message format supports this information and raw observa- tions are being logged at the reference. Next step CONT (F1) exits STATUS Logging.

  • Page 609: Smartantenna System Info

    30.9.1 SmartAntenna System Info Access Select STATUS: SmartAntenna System Info. Refer to "30.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS SmartAntenna Information. Refer to "2.1 Hot Keys" for information on hot keys. Press USER.

  • Page 610: Telescope Positioning

    Telescope Positioning TPS1200 Telescope Positioning Description Motorised instruments turn to a target point or change face automatically. On non motorised instruments the XX Telescope Positioning screen assists in manual aiming. This screen helps reducing the possibility for errors in target point identification. The horizontal and vertical angle differences between the current telescope position and the target position are displayed.
  • Page 611 Telescope Positioning OK (F4) To confirm angles and return to the screen this screen was accessed from. ABORT (F6) To abort the telescope positioning. Description of fields Field Option Description <∆Hz:> Output The difference between the horizontal angle of the current telescope position and of the telescope posi- tion to aim at is displayed.

  • Page 612: Functions

    Functions TPS1200 Functions 32.1 Description Electronic Distance Measurement EDM is the sensor used for distance measurements with infrared laser or visible red laser. There are three different <EDM Type:> and four different <EDM Mode:> the instrument can work in. These terms are described below. Refer to "17.1 EDM &...
  • Page 613 EDM Type Description Available for instruments equipped with reflectorless EDM. <EDM Type: Long Range (LO)> allows to measure very long distances to prisms. The last used option for <EDM Mode:> and <Reflector:> are applied, <Automation: None> is set. EDM modes EDM Mode Description Standard...

  • Page 614: Prism Search Methods

    Functions TPS1200 32.2 Prism Search Methods 32.2.1 Description Automatic Target Recognition ATR is the sensor which recognises and measures the posi- tion of a prism by means of a CCD array. A laser beam is transmitted and the reflected beam is received by the built in CCD array.
  • Page 615 Next step IF the reflector is THEN in the field of view Refer to paragraph "ATR measurement" for more information. not in the field of view Refer to paragraph "ATR search" for more information. ATR measurement If the reflector is in the field of view and <Automation: ATR> the crosshairs are automatically positioned to the reflector when, for example ALL (F1) or DIST (F2) is pressed.
  • Page 616 Functions TPS1200 ATR search If the reflector is not in the field of view when ALL (F1) or DIST (F2) is pressed, an ATR search is started. For the ATR search the ATR window is scanned line by line starting at the current telescope position.
  • Page 617 Automation Description <Automation: ATR> is set. The ATR sensor is used for measure- ments to static reflectors. If needed an ATR measurement or ATR search is performed after pressing ALL (F1) or DIST (F2). The accu- racy of ATR measurements depends on the set <EDM Mode:>. LOCK <Automation: LOCK>...

  • Page 618: Powersearch

    Functions TPS1200 32.2.2 PowerSearch Description The PowerSearch module allows an automatic prism detection within a short period of time. In the QUICK SET Change Settings to: screen the PowerSearch function can be started by pressing PS (F6). Functionality The PowerSearch sensor consists of a trans- mitter (a) and a receiver (b).
  • Page 619 360° search For <PS Window: Off> and PS (F6) the prism is searched for with PowerSearch in the 360° window. The default search with PowerSearch consists of a short swing in anti-clockwise direction followed by a complete 360° turn in clockwise direction. If a prism is detected the movement is stopped and an ATR search is performed.

  • Page 620: Follow Moving Prisms - Lock

    Functions TPS1200 32.3 Follow Moving Prisms - LOCK Description LOCK enables instruments equipped with ATR to follow a moving prism. The ATR sensor is active. When <Automation: LOCK> and a distance measurement is initiated with DIST (F2) or L.GO (F5) is pressed, an ATR search is executed. The instrument locks onto the prism and follows its movements.
  • Page 621 Loss of lock When the instrument is locked onto a reflector, lock may be lost if the movement of the reflector is too fast for the instrument to follow or the reflector is hidden behind an object. After lock is lost, the prediction is used to find the prism again. Refer to paragraph "Predic- tion"...
  • Page 622 Functions TPS1200 • <Search with: PowerSearch> and <PS Window: On>: prism is searched for in the PS window with PowerSearch. • <Search with: PowerSearch> and <PS Window: Off>: prism is searched for in the dynamic PowerSearch window. Relock Independent of <Search with:> the instrument can relock onto the prism. Refer to paragraph "Enable lock"...

  • Page 623: Rcs

    32.4 Description When <Use Interface: Yes> in CONFIGURE RCS Mode the instrument can be controlled by RX1200 via radio. The ATR sensor does not necessarily have to be active when working in RCS mode. The RX1200 is used to remote control the instrument. No data can be stored on the RX1200.

  • Page 624: Egl

    Functions TPS1200 32.5 Description The Emitting Guide Light, EGL, consists of two differently coloured flashing lights in the tele- scope housing of the TPS1200. The EGL is used for guidance into the line of sight. If the left light is seen, the prism should be moved right and vice versa. If both flashing lights can be seen, the prism is in the line of sight of the instrument.
  • Page 625 Functionality The EGL can be used • to help guiding the reflector into the tele- scope line of sight when the instrument is remotely controlled and <Automation: LOCK>. • to stake out points The instrument emits two differently colored flashing cones of light. At a target distance of 100 m the cones have a width of 6 m.
  • Page 626 Functions TPS1200 Step Description Refer to chapter Set <Automation: LOCK> and press COMPS (F1) or Hz/V (F2) or JSTCK (F3) on the QUICK SET Change Settings to: screen Set <EGL: On> on the CONFIGURE Lights, Display, Beeps, 18.5 Text, Lights page. Align instrument line of sight and prism, where both flashing EGL lights can be seen simultaneously.

  • Page 627: Illumination

    32.6 Illumination Description There are several different illumination types built into the instrument that all fulfill different functions. Some are to support measurements, for example the visible red laser pointer. Others, such as the screen illumination, are for more convenient work with the instrument. These different types of illumination are described below.
  • Page 628 Functions TPS1200 Screen/key illumination The screen and key illumination allows a more convenient working with the instrument when the lighting conditions are not ideal. They can be turned on in the CONFIGURE Lights, Displays, Beeps, Text, Lights page. To access this screen press SHIFT F11 in any appli- cation program.
  • Page 629 Functions TPS1200...

  • Page 630: Ntrip Via Internet

    NTRIP via Internet TPS1200 NTRIP via Internet 33.1 Overview Description Networked Transport of RTCM via Internet Protocol • is a protocol streaming real-time corrections over the Internet. • is a generic protocol based on the Hypertext Transfer Protocol HTTP/1.1. • is used to send differential correction data or other kinds of streaming data to stationary or mobile users over the Internet, allowing simultaneous PC, laptop, PDA, or receiver connections to a broadcasting host.
  • Page 631 System components NTRIP consists of three system components: • NTRIPClients • NTRIPServers • NTRIPCaster NTRIPClient 1 NTRIPClient x HTTP Streams NTRIPCaster HTTP Streams NTRIPServer 1 NTRIPServer x NTRIPSource 1 NTRIPSource x NTRIP via Internet TPS1200...
  • Page 632 NTRIP via Internet TPS1200 NTRIPClient The NTRIPClient receives data streams. This could be, for example a real-time rover receiving real-time corrections. In order to receive real-time corrections, the NTRIPClient must first send • a user ID • a password • an identification name, the so-called MountPoint, from which real-time corrections are to be received to the NTRIPCaster.
  • Page 633 NTRIPCaster The NTRIPCaster • is an Internet server handling various data streams to and from the NTRIPServers and NTRIPClients. • checks the requests from NTRIPClients and NTRIPServers to see if they are registered to receive or provide real-time corrections. • decides whether there is streaming data to be sent or to be received.

  • Page 634: Configuring Smartstation For Using Ntrip Service

    NTRIP via Internet TPS1200 33.2 Configuring SmartStation for Using NTRIP Service 33.2.1 Configuring an Access to the Internet Requirements • SmartStation must be used. • Firmware v2 or higher must be loaded on the TPS1200 instrument. • Firmware v1.42 or higher must be loaded on the RX1200. To access to the Internet with SmartStation, General Packed Radio System devices will normally be used.
  • Page 635 Step Description Refer to chapter <User ID:> Some providers ask for a user ID to allow connecting to the Internet via GPRS. Contact your provider if a user ID needs to be used. <Password:> Some providers ask for a password to allow connecting to the Internet via GPRS.
  • Page 636 NTRIP via Internet TPS1200 Step Description Refer to chapter The instrument is now online to the Internet. The Internet online status icon is displayed. But because GPRS is being used, no charges are yet made since no data transfer from the Internet has yet taken place.

  • Page 637: Configuring To Connect To A Server

    33.2.2 Configuring to Connect to a Server Requirements The configurations from the previous chapter must have been completed. Refer to "33.2.1 Configuring an Access to the Internet". Configure connect to a The following table explains the most common settings. Refer to the stated chapter for more server step-by-step information on screens.
  • Page 638 NTRIP via Internet TPS1200 Step Description Refer to chapter <Server:> The server to be accessed in the Internet. Opening the 21.10 choicelist accesses CONFIGURE Server to Connect where new servers can be created and existing servers can be selected or edited.
  • Page 639 Step Description Refer to chapter Highlight GPS RTK. DEVCE (F5) to access STATUS Device: Ethernet. STATUS Device: Ethernet Check the Internet online status. CONT (F1) to return to STATUS Interfaces. CONT (F1) to return to TPS1200 Main Menu. NTRIP via Internet TPS1200...

  • Page 640: Using The Ntrip Service With Smartstation

    NTRIP via Internet TPS1200 33.2.3 Using the NTRIP Service with SmartStation Requirements The configurations from the previous chapter must have been completed. Refer to "33.2.2 Configuring to Connect to a Server". Use NTRIP service step- Step Description by-step Select Main Menu: Config...\Interfaces..In CONFIGURE Interfaces highlight GPS RTK.
  • Page 641 Step Description • First column MountPoint: The abbreviations for the MountPoints. • Second column Identifier: The city where the MountPoint is located. Highlight a MountPoint about which more information is required. This information helps to configure the receiver to use the selected MountPoint as a reference. INFO (F3) to access CONFIGURE MountPoint: XX.
  • Page 642 NTRIP via Internet TPS1200 Step Description Detailed information about the location of the MountPoint is displayed. PAGE (F6) to access CONFIGURE MountPoint: XX, Miscell page. CONFIGURE MountPoint: XX, Miscell page <Generator:> The hard- or software generating the data stream. <Compress:> The name of the compression / encryption algorithm. <Info:>...
  • Page 643 NTRIP via Internet TPS1200...

  • Page 644: Mapview Interactive Display Feature

    MapView Interactive Display Feature TPS1200 MapView Interactive Display Feature 34.1 Overview Description MapView is an interactive display feature embedded in the firmware but used by all applica- tion programs as well as data management. MapView provides a graphical display of the survey elements which allows for a better overall understanding of how the data being used and measured relates to each other.
  • Page 645 • Can be used to select lines and areas. • Same as Map mode but also shows the positions of the instrument and the reflector. • Provides special functionality when staking out points. • Available as the Map page in Survey and some application programs.

  • Page 646: Accessing Mapview

    MapView Interactive Display Feature TPS1200 34.2 Accessing MapView Description The MapView interactive display feature is provided as a page within all application programs and data management. It is accessed through the application program itself. Depending on the application program and from where in the application program MapView is accessed, different MapView modes are available.
  • Page 647 Step Description Press a hot key configured to access the screen COGO COGO Begin. Refer to "2.1 Hot Keys" for information on hot keys. Press USER. Refer to "2.2 USER Key" for information on the USER key. CONT (F1) to access COGO COGO Menu. COGO COGO Menu Highlight Intersections.
  • Page 648 MapView Interactive Display Feature TPS1200 Step Description Press USER. Refer to "2.2 USER Key" for information on the USER key. Press PROG. Highlight Survey. CONT (F1). Refer to "35.2 Accessing the Programs Menu" for information on the PROG key. CONT (F1) to access SURVEY Survey: Job Name. PAGE (F6) until SURVEY Survey: Job Name, Map page is active.

  • Page 649: Configuring Mapview

    34.3 Configuring MapView Description Allows options to be set which are used as default options within MapView. These settings are stored within the configuration set and apply to all Map and Plot pages, regardless of how MapView is accessed. Any changes made in XX MapView Configuration affect the appearance of MapView in all application programs, not just the active application program.
  • Page 650 MapView Interactive Display Feature TPS1200 Description of fields Field Option Description <Show Points:> Yes or No Determines if points are displayed in MapView. <Point ID:> Yes or No Available for <Show Points: Yes>. Determines if the ID of a point is displayed. <Point Code:>...
  • Page 651 Description of fields MapView Configuration, Field Option Description Lines&Areas page <Show Lines:> Yes or No Determines if lines are displayed in MapView. <Show Line ID:> Yes or No Available for <Show Lines: Yes>. Determines if the ID of a line is displayed. <Show Line Code:>...
  • Page 652 MapView Interactive Display Feature TPS1200 Next step PAGE (F6) changes to the Display page. Refer to paragraph "XX MapView Configuration, Display page". Description of fields MapView Configuration, Field Option Description Display page <Show Pt Info:> When <200 Determines if point information is shown or not. For Pts or As <Show Pt Info: When <200 Pts>...
  • Page 653 Field Option Description <None> No information is displayed in the map. Point ID Point ID of the current position. Code Code of the current position. Attrib 01 User defined attribute. Attrib 02 User defined attribute. Attrib 03 User defined attribute. Attrib 04 User defined attribute.
  • Page 654 MapView Interactive Display Feature TPS1200 Next step CONT (F1) confirms the selections and returns to where XX MapView Configuration was accessed.

  • Page 655: Mapview Components

    34.4 MapView Components 34.4.1 Softkeys Description Standard functionality is provided by a number of softkeys within MapView. These softkeys are available regardless of the mode in which MapView was accessed and always perform the same functions. Standard softkeys The softkeys described below are standard on all MapView screens. For descriptions of mode specific softkeys see appropriate chapters.
  • Page 656 MapView Interactive Display Feature TPS1200 Softkey Touch equivalent PAGE (F6) Tap on a page tab. SHIFT FIT (F3) Tap on fit touch icon. Refer to "34.4.3 Toolbar".

  • Page 657: Screen Area

    34.4.2 Screen Area Description The MapView screen area is very similar in all cases. The positions of the scale bar, the North arrow and the toolbar, if visible, do not change. Standard screen a) Toolbar b) North arrow c) Scale bar GPS12_142 Reflector Reflectors are displayed on the Map page.
  • Page 658 MapView Interactive Display Feature TPS1200 Scale bar Symbol Description Scale of the current screen. The minimum is 0.5 m. There is no maximum for the zoom but the scale cannot display values greater than 99000 m. In this case the value displayed will be >99000 m. North arrow Symbol Description...

  • Page 659: Toolbar

    34.4.3 Toolbar Description Touch icons are available in a toolbar, if <Toolbar: On> in XX MapView Configuration, Display page. The toolbar is always located on the left hand side of the screen. Some of the functions performed by the touch icons can also be replicated using a softkey in the same mode as when the touch icon appears.

  • Page 660: Point Symbols

    MapView Interactive Display Feature TPS1200 34.4.4 Point Symbols Points When <Show Points: Yes> in XX MapView Configuration, points are displayed, in all modes, according to their class. Symbol Description 3D control point is a point of class CTRL with horizontal and vertical coordinate components.
  • Page 661 A list of the point types available, and their description, is available by pressing SYMBL (F3) in XX MapView Configuration, Points page. Refer to "34.3 Configuring MapView". MapView Interactive Display Feature TPS1200...

  • Page 662: Map Mode

    MapView Interactive Display Feature TPS1200 34.5 Map Mode 34.5.1 MapView in Map Mode Description The map mode of MapView is available as the Map page in data management and some application programs. It can be used to display, select and edit points, lines and areas. Access Refer to "34.2 Accessing MapView"...
  • Page 663 FOCUS (F2) or DONE (F2) To activate the focus tool and select a point without using the touch screen. Refer to "34.5.2 Selecting Points, Lines and Areas". EDIT (F3) To edit the highlighted point’s parameters. Accesses MANAGE Edit Point: Point ID. SHIFT CENTR (F4) To centre the screen around the point with the current focus, or the focus tool if DONE (F2) is...

  • Page 664: Selecting Points, Lines And Areas

    MapView Interactive Display Feature TPS1200 34.5.2 Selecting Points, Lines and Areas Description Selecting a point, line or area in the map mode of MapView is possible using both the softkeys and the touch screen. The functionality of all screens and field are similar for the selecting of a point, line or area.
  • Page 665 Step Description Display When there are multiple points within the same area and the precise selection is unclear, pressing ENTER will access XX Select Point. Press ENTER to select the point. The point parameter text, as defined in XX Map View Configuration, Points page, is highlighted.
  • Page 666 MapView Interactive Display Feature TPS1200 Step Description Display DONE (F2) exits the focus tool. Selecting a point using Step Description Display the touch screen step- Refer to "34.5.1 MapView in Map Mode" to access by-step MANAGE Data: Job Name, Map page. If no point field is highlighted on the previous page when the Map page is accessed, then any point that is selected will be assigned to the first point field on the previous page,...
  • Page 667 Step Description Display Have multiple points been selected? • If yes, continue with step 4. • If no, continue with step 6. XX Select Point Point ID The ID of the points within range of the point selection. Point Code The code of the points within range of the point selection.

  • Page 668: Plot Mode - Mapview Screen Area

    MapView Interactive Display Feature TPS1200 34.6 Plot Mode - MapView Screen Area Description The plot mode of MapView is available as the Plot page in an application program and can be used to view the results of the application program. Results are shown in black, all other information, that is displayable, is shown in grey.
  • Page 669 Touch screen functions Touch Equivalent SHIFT FIT R (F4) Tap on fit results touch icon. Refer to "34.4.3 Toolbar". Example of results Application Display Description displayed in MapView COGO Intersec- Intersecting lines on Plot page tion, Bearing - with known bear- Bearing ings from known points.
  • Page 670 MapView Interactive Display Feature TPS1200 Application Display Description COGO Shift, Original points in Rotate & Scale grey, calculated COGO points in black Reference Line, Reference line or Edit Reference Line Reference A dashed rectangle Plane, Edit indicates the face Reference view of the plane.
  • Page 671 Application Display Description Sets of Angles, Directions from Calculating station to sets of Angles angle points Setup Directions to resec- tion points. MapView Interactive Display Feature TPS1200...

  • Page 672: Survey Mode

    MapView Interactive Display Feature TPS1200 34.7 Survey Mode 34.7.1 MapView in Survey Mode Description The survey mode of MapView is available as the Map page in Survey and is used to display the position of the instrument station during a survey. It can also be used to select lines and areas.
  • Page 673 SURVEY The softkeys described below are specific to MapView in survey mode. Refer to "34.4.1 Survey: Job Name, Softkeys" for descriptions of the standard softkeys. Map page SHIFT FACE (F1) and SHIFT PLAN (F1) Available in REFPLANE Measure Point on Plane, Map page.

  • Page 674: Mapview In Staking Out Survey Mode

    MapView Interactive Display Feature TPS1200 34.7.2 MapView in Staking Out Survey Mode Description When staking out a point in Stakeout or Reference Line application programs, the Map page is available. The MapView survey mode is provided for this operation, with some differences. •...
  • Page 675 Access step-by-step Example access for MapView in survey mode, Stakeout Step Description Select Main Menu: Programs...\Stakeout. Press PROG. Highlight Stakeout. CONT (F1). Press a hot key configured to access the screen STAKEOUT Stakeout Begin. Refer to "2.1 Hot Keys" for information on hot keys. Press USER.
  • Page 676 MapView Interactive Display Feature TPS1200 STAKEOUT The softkeys described below are specific to MapView in survey mode, staking out. Refer to XX Stakeout, "34.4.1 Softkeys" for descriptions of the standard softkeys. Map page SHIFT CENTR (F4) To centre the screen around the reflector. Description of fields Field Option...

  • Page 677: Selecting Lines And Areas

    34.7.3 Selecting Lines and Areas Description Selecting a line or area in the survey mode of MapView is possible using the touch screen. The functionality of all screens and field are similar for the selecting of a line or area. The step-by-step instructions for selecting a line using the touchscreen can be applied for areas.
  • Page 678 MapView Interactive Display Feature TPS1200 Step Description • If yes, continue with step 5. • If no, continue with step 7. XX Select Line Point ID The ID of the lines within range of the line selection. Point Code The code of the lines within range of the point selection. Select the desired line.
  • Page 679 MapView Interactive Display Feature TPS1200...

  • Page 680: Application Programs - General

    Application Programs - General TPS1200 Application Programs - General 35.1 Overview Description Application programs are software packages supporting specific tasks. Available are: • Survey (integrated into the instrument firmware and cannot be deleted) • Setup (integrated into the instrument firmware and cannot be deleted) •...
  • Page 681 • Sets of Angles - this program could contain the following: • Sets of Angles • Monitoring • Stakeout • Survey Cross Section • Traverse • Volume Calculations For an explanation of the application programs refer to the relevant chapters. Loadable and non-load- Loadable application programs: •...
  • Page 682 Customised application programs can be developed locally using the GeoC++ development programs environment. Information on the GeoC++ development environment is available on request from the Leica Geosystems representative. Customised application programs always run in the language they were developed in.

  • Page 683: Accessing The Programs Menu

    35.2 Accessing the Programs Menu Description The application programs menu contains all loaded application programs including Survey and Setup. They are listed in the order in which they were loaded. Selecting an option in the menu starts the application program assigned to the option. Configurations and measure- ments that can be performed depend on the application program.
  • Page 684 Application Programs - General TPS1200 Next step Select an option in the menu to open the application. Refer to the chapter on the individual application programs. Four application programs can be open at one time. XX Begin is shown for the application program opened first, but not for the following application programs.
  • Page 685 Application Programs - General TPS1200...

  • Page 686: Cogo

    COGO TPS1200 COGO 36.1 Overview Description COGO is an application program to perform coordinate geometry calculations such as • coordinates of points. • bearings between points. • distances between points. The calculations can be made from • existing point data in the job, known distances or known azimuths. •...
  • Page 687 Distances and azimuths Type of distances: The choices are • Ground • Grid • Ellipsoidal Type of azimuths: The azimuths are grid azimuths relative to the local grid. Coding of COGO points • Thematical coding is available in COGO XX Results after the COGO calculation. Thematical coding of COGO points is identical to coding measured points.

  • Page 688: Accessing Cogo

    COGO TPS1200 36.2 Accessing COGO Access Select Main Menu: Programs...\COGO. Press PROG. Highlight COGO. CONT (F1). Refer to "35.2 Accessing the Programs Menu" for information on the PROG key. Press a hot key configured to access the screen COGO COGO Begin. Refer to "2.1 Hot Keys"...
  • Page 689 COGO COGO Begin CONT (F1) To accept changes and access the subsequent screen. The chosen settings become active. CONF (F2) To configure the COGO application program. Accesses COGO Configuration. Refer to "36.3 Configuring COGO". SETUP (F3) To set up station. Accesses SETUP Station Setup.
  • Page 690 COGO TPS1200 Field Option Description Output Codes have already been stored in the selected <Job:>. If codes had been copied from a System RAM codelist, then the name of the codelist is displayed. If codes have not been copied from a System RAM codelist but typed in, then the name of the active job is displayed.
  • Page 691 CONT (F1) To select the highlighted option and to continue with the subsequent screen. SHIFT CONF (F2) To configure the COGO application program. Accesses COGO Configuration. Refer to "36.3 Configuring COGO". Description of the COGO menu options COGO menu options Description Refer to chapter...
  • Page 692 COGO TPS1200 COGO menu options Description Refer to chapter • the azimuth/bearing and the distance from a known point. Offset optional. • the angle and the distance from a known point. Offset optional. Points with full coordinate triplets and position only points can be used.
  • Page 693 COGO menu options Description Refer to chapter • two known points that define the line, a distance along the line and an offset. • a distance along a bearing from a known point and and offset. To calculate new points on a line using •...
  • Page 694 COGO TPS1200 COGO menu options Description Refer to chapter • the length of an arc and two tangents, each of it defined by a point and the intersection point of the tangents. • the length of a chord and two tangents, each of it defined by a point and the intersection point of the tangents.
  • Page 695 COGO menu options Description Refer to chapter Shift, Rotate & Scale To calculate the coordinates of new points using the 36.10 (Match Pts) shifts, rotation and scale computed from selected points. Points with full coordinate triplets, position only points and height only points can be used. Area Division To divide an area by a 36.11...

  • Page 696: Configuring Cogo

    COGO TPS1200 36.3 Configuring COGO Access Select Main Menu: Programs...\COGO. In COGO COGO Begin press CONF (F2) to access COGO Configuration. Press PROG. Highlight COGO. CONT (F1). In COGO COGO Begin press CONF (F2) to access COGO Configuration. Press SHIFT CONF (F2) in COGO COGO Menu. Refer to "36.2 Accessing COGO". Press SHIFT CONF (F2) in COGO XX.
  • Page 697 Description of fields Field Option Description <Distance Type:> The type of distances and offsets to be accepted as input, shown as output and used in the calculation. Grid Distances are calculated as the trigonometric distance between the position of two points. The distance field is <HDist-Grid:>.
  • Page 698 COGO TPS1200 Field Option Description Ellipsoid Known P1 First known point P2 Second known point Unknown Ground distance Ellipsoid distance Grid distance TPS12_170 <Two Faces:> Defines if the instrument measures the second face automatically after storing the first. After storing a measurement with ALL (F1) or REC (F3) motorised instruments change face automati- cally, non-motorised instruments access COGO Telescope Positioning.
  • Page 699 Field Option Description Points stored with point class MEAS can be stored with the same point ID. The averaging functionality (configured under job management) can then be used to calculate an average for these points. Points stored with point class CTRL can only be stored with a unique point ID.
  • Page 700 COGO TPS1200 Next step PAGE (F6) changes to the Residuals page. Refer to paragraph "COGO Configuration, Residuals page". COGO This page applies to COGO Shift, Rotate & Scale (Match Pts). Configuration, Description of fields Residuals page Field Option Description <Easting:> User input The limit above which Easting residuals will be flagged as possible outliers.
  • Page 701 Next step PAGE (F6) changes to the Logfile page. Refer to paragraph "COGO Configuration, Logfile page". COGO Description of fields Configuration, Field Option Description Logfile page <Write Logfile:> Yes or No To generate a logfile when the application program is exited.
  • Page 702 COGO TPS1200 Field Option Description Opening the choicelist accesses XX Format Files where an existing format file can be selected or deleted. Next step PAGE (F6) changes to the first page on this screen. <Azimuth:> is used throughout this chapter. This should always be considered to also mean <Bearing:>.

  • Page 703: Cogo Calculation - Inverse Method

    36.4 COGO Calculation - Inverse Method 36.4.1 Overview Description It is possible to compute an inverse result between point, line and arc elements: Option 1: inverse between point - point To compute an inverse between two known points. Known elements: P1 First known point (From) P2 Second known point (To) Unknown elements:...
  • Page 704 COGO TPS1200 Option 3: inverse between point - arc To compute an inverse between a known point and a given arc (the inverse is computed as the perpendicular between the known point and the given arc). Known elements: P0 Instrument station P1 Starting point P2 End point P3 Offset point...

  • Page 705: Inverse Between Two Known Points (Pt - Pt)

    36.4.2 Inverse Between Two Known Points (Pt - Pt) Starting step-by-step Step Description Calculating STORE (F1) To store the result. SURVY (F5) To measure a known point for the calculation. SHIFT CONF (F2) To configure the program. PAGE (F6) To change to another page on the screen. COGO TPS1200...
  • Page 706 Press STORE (F1) to store the inverse result to the active job. There are no points stored to the database, only the inverse result. Inverse results can be exported from the job using a format file. The format file is created with Format Manager in LEICA Geo Office.

  • Page 707: Inverse Between A Known Point And A Line (Pt - Line)

    36.4.3 Inverse Between a Known Point and a Line (Pt - Line) Starting step-by-step Step Description Calculating CALC (F1) To calculate the result. INV (F2) To calculate the inverse between two points. LAST (F4) To select the values for distance and offset from previous COGO inverse calculations.
  • Page 708 Press STORE (F1) to store the inverse result to the active job. There are no points stored to the database, only the inverse result. Inverse results can be exported from the job using a format file. The format file is created with Format Manager in LEICA Geo Office.

  • Page 709: Inverse Between A Known Point And An Arc (Pt - Arc)

    36.4.4 Inverse Between a Known Point and an Arc (Pt - Arc) Starting step-by-step Step Description Calculating CALC (F1) To calculate the result. INV (F2) To calculate the inverse between two points. LAST (F4) To select the values for distance and offset from previous COGO Inverse calculations.
  • Page 710 COGO TPS1200 SHIFT MODIF (F4) To modify the original azimuth, distance or offset value. PAGE (F6) To change to another page on the screen. Description of fields Field Option Description <Method:> 3 Points or 2 Points/Radius or 2 Tgnts/Radius or 2 Tgnts/Arc Lngt or 2 Tgnts/Chrd Lngt.
  • Page 711 Press STORE (F1) to store the inverse result to the active job. There are no points stored to the database, only the inverse result. Inverse results can be exported from the job using a format file. The format file is created with Format Manager in LEICA Geo Office. COGO TPS1200...

  • Page 712: Cogo Calculation - Traverse Method

    COGO TPS1200 36.5 COGO Calculation - Traverse Method 36.5.1 Overview Description Elements that must be known are • the coordinates of one point. • the direction from the known point to the COGO point. • the distance from the known point to the COGO point. •...
  • Page 713 Diagram COGO traverse calculation with offset for a single point Known P1 Known point α Direction from P1 to P2 Distance between P1 and P2 Positive offset to the right Negative offset to the left Unknown P2 COGO point without offset P3 COGO point with positive offset P4 COGO point with negative offset TPS12_147...
  • Page 714 COGO TPS1200 COGO traverse calculation without offset for multiple points Known P1 Known point α 1 Direction from P1 to P2 α 2 Direction from P2 to P3 α 3 Direction from P3 to P4 α 4 Direction from P3 to P5 Distance between P1 and P2 Distance between P2 and P3 Distance between P3 and P4...

  • Page 715: Traverse With Azimuth/Bearing

    36.5.2 Traverse with Azimuth/Bearing COGO traverse calcula- The following table explains the most common settings. Refer to the stated chapter for more tion with information on screens. azimuth/bearing step- Step Description Refer to by-step chapter Refer to "36.2 Accessing COGO" to access COGO Traverse Input. COGO Traverse Input, Input page 36.3 SHIFT CONF (F2) to configure the COGO application program.
  • Page 716 COGO TPS1200 Step Description Refer to chapter <Offset:> Available for <Use Offsets: Yes> in COGO Configura- tion, Parameters page. The offset of the COGO point from the line of direction. A positive offset is to the right, a negative offset is to the left.
  • Page 717 Step Description Refer to chapter The values for the azimuth, the distance and the offset can be math- 36.13 ematically modified. SHIFT MODIF (F4) when <Azimuth:>, <HDist-XX:> or <Offset:> is highlighted. To add, subtract, multiply and divide values. Is the COGO point a foresight? •...
  • Page 718 COGO TPS1200 Step Description Refer to chapter <Ortho Ht:> or <Local Ell Ht:> are input fields. They display ----- when entering the Result page. A height value to be stored with the calculated point can be typed in. The calculated coordinates are displayed. Type in a point ID.
  • Page 719 Step Description Refer to chapter PAGE (F6) changes to the Plot page. COGO Traverse Results, Plot page 34.6 An arrow points from the known point to the calculated COGO point. SHIFT QUIT (F6) does not store the COGO point and exits COGO calculations.

  • Page 720: Traverse With Angle Right

    COGO TPS1200 36.5.3 Traverse with Angle Right Access Refer to "36.2 Accessing COGO" to access COGO Traverse Input. COGO CALC (F1) Traverse Input, To calculate the COGO point. Input page INV (F2) To calculate the values for the distance and the offset from two existing points.
  • Page 721 Description of fields Field Option Description <Method:> Angle Right The direction from the known point to the COGO point is an angle. <From:> Choicelist The point ID of the known point for the COGO calcu- lation. <Backsight:> Choicelist The point ID of a point used as backsight. <Angle Right:>...

  • Page 722: Cogo Calculation - Intersections Method

    COGO TPS1200 36.6 COGO Calculation - Intersections Method 36.6.1 Intersection with Bearing - Bearing Description The COGO intersection calculation bearing - bearing calculates the intersection point of two lines. A line is defined by a point and a direction. Elements that must be known are •...
  • Page 723 Diagram Known P1 First known point P2 Second known point α 1 Direction from P1 to P3 α 2 Direction from P2 to P3 Unknown P3 COGO point TPS12_148 COGO intersection The following table explains the most common settings. Refer to the stated chapter for more calculation with bearing information on screens.
  • Page 724 COGO TPS1200 Step Description Refer to chapter Select the point stored in the job. SURVY (F5) when <1st Point:> is highlighted. To measure a point 47.2 for the COGO calculation. For all point fields, the MapView interactive display on the Map page 34.5 can be used to select the desired point.
  • Page 725 Step Description Refer to chapter For <Write Logfile: Yes> in COGO Configuration, Logfile page the result of the COGO inverse calculation is written to the logfile. The values for the azimuth and the offset can be selected from 36.12 previous COGO inverse calculations. LAST (F4) when <Azimuth:>...
  • Page 726 COGO TPS1200 Step Description Refer to chapter <Point ID:> The identifier for the COGO point depending on the point 16.1 ID template configured for <Survey Pts:> in CONFIGURE ID Templates. The point ID can be changed. <Ortho Ht:> or <Local Ell Ht:> are input fields. They display ----- when entering the Result page.
  • Page 727 Step Description Refer to chapter <Code:>/<Point Code:> The thematical code. All codes of the job can be selected. Type in a code if required. PAGE (F6) changes to the Plot page. COGO Brng - Brng Results, Plot page 34.6 Arrows point from the known points to the calculated COGO point. SHIFT QUIT (F6) does not store the COGO point and exits COGO calculation.

  • Page 728: Intersection With Bearing - Distance

    COGO TPS1200 36.6.2 Intersection with Bearing - Distance Description The COGO intersection calculation bearing - distance calculates the intersection point of a line and a circle. The line is defined by a point and a direction. The circle is defined by the centre point and the radius.
  • Page 729 Diagram Known P1 First known point P2 Second known point α Direction from P1 to P3 and P4 Radius, as defined by the distance from P2 to P4 and P3 Unknown P3 First COGO point TPS12_149 P4 Second COGO point COGO intersection The following table explains the most common settings.
  • Page 730 COGO TPS1200 Step Description Refer to chapter CALC (F1) to calculate the COGO points. Two results are calculated. COGO Brng - Dist Results, Result1 page <Point ID:> The identifier for the first result of the COGO point 16.1 depending on the point ID template configured for <Survey Pts:> in CONFIGURE ID Templates.
  • Page 731 Step Description Refer to chapter SHIFT INDIV (F5) for an individual point ID independent of the ID 16.1 template. SHIFT RUN (F5) changes back to the next ID from the configured ID template. PAGE (F6) changes to the Code page where a code and attributes can be selected.
  • Page 732 COGO TPS1200 Step Description Refer to chapter • If yes, STORE (F1) to store the result and return to COGO Inter- section Input, Input page. For <Write Logfile: Yes> in COGO Configuration, Logfile page the result is written to the logfile. •...

  • Page 733: Intersection With Distance - Distance

    36.6.3 Intersection with Distance - Distance Description The COGO intersection calculation distance - distance calculates the intersection point of two circles. The circles are defined by the known point as the centre point and the distance from the known point to the COGO point as the radius. Elements that must be known are •...
  • Page 734 COGO TPS1200 Diagram Known P1 First known point P2 Second known point Radius, as defined by the distance from P1 to P3 or P4 Radius, as defined by the distance from P2 to P3 or P4 Unknown P3 First COGO point P4 Second COGO point TPS12_150 COGO intersection...
  • Page 735 Step Description Refer to chapter The remaining procedure is identical to a COGO intersection calcula- tion with bearing - distance. The screen is called COGO Dist - Dist Results. Follow the steps 2. to 8. in paragraph "COGO intersection calculation 36.6.2 with bearing - distance step-by-step".

  • Page 736: Intersection With By Points

    COGO TPS1200 36.6.4 Intersection with By Points Description The COGO intersection calculation by points calculates the intersection point of two lines. A line is defined by two points. Elements that must be known are • the coordinates of four points. •...
  • Page 737 Diagram Known P1 First known point P2 Second known point P3 Third known point P4 Fourth known point Line from P1 to P2 Line from P3 to P4 Unknown P5 COGO point TPS12_151 COGO intersection The following table explains the most common settings. Refer to the stated chapter for more calculation with by information on screens.
  • Page 738 COGO TPS1200 Step Description Refer to chapter <2nd Point:> The point ID of the known end point of the first line for the COGO calculation. Select the points stored in the job. SURVY (F5) when <1st Point:> or <2nd Point:> is highlighted. To 47.2 measure a known point for the COGO calculation.
  • Page 739 Step Description Refer to chapter For <Write Logfile: Yes> in COGO Configuration, Logfile page the result of the COGO inverse calculation is written to the logfile. The value for the offset can be selected from previous COGO inverse 36.12 calculations. LAST (F4) when <Offset:>...

  • Page 740: Intersection With Tps Observation - Tps Observation

    COGO TPS1200 36.6.5 Intersection with TPS Observation - TPS Observation Description The COGO intersection calculation TPS observation - TPS observation calculates the inter- section point of two lines. A line is defined by a TPS station and a TPS measurement from this station.
  • Page 741 Diagram Known P0 First known point (TPS station) P1 Second known point (TPS station) á1 Direction from P0 to P2 á2 Direction from P1 to P2 Unknown P2 COGO point GPS12_170 COGO intersection The following table explains the most common settings. Refer to the stated chapter calculation with TPS for more information on screens.
  • Page 742 COGO TPS1200 Step Description Refer to chapter <TPS Measmnt:> The point ID of the TPS measurement which is the known end point of the first line for the COGO calculation. <Azimuth:> The azimuth related to the known end point of the first line for the COGO calculation.
  • Page 743 Step Description Refer to chapter The value for the azimuth can be selected from previous COGO 36.12 inverse calculations. LAST (F4) when <Azimuth:> is highlighted. To recall previous results from COGO inverse calculations. Upon pressing CONT (F1) in COGO Last Inverse Calculations, the selected result is copied to the field.

  • Page 744: Cogo Calculation - Line Calculations Method

    COGO TPS1200 36.7 COGO Calculation - Line Calculations Method 36.7.1 Line Calculation - Base Point Description The COGO line calculation base point calculates the base point, station and offset of a point in relation to a line. Elements that must be known are •...
  • Page 745 Diagram P0 Instrument station P1 <Start Point:> P2 <End Point:> P3 <Offset Point:> P4 Base point <Offset-XX:> <∆Line-XX:> TPS12_184 Line management is not available for COGO line calculations. Access Refer to "36.2 Accessing COGO" to access COGO Line Calculations Input. COGO Line Calculations Input, Input page...
  • Page 746 COGO TPS1200 SURVY (F5) To measure a point for the COGO calculation. Available if <Start Point:> or <End Point:> is highlighted. SHIFT CONF (F2) To configure the COGO application program. SHIFT MODIF (F4) To mathematically modify the values. Available if <Azimuth:>, <∆Line-XX:> or <HDist-XX:> is highlighted.
  • Page 747 Field Option Description <End Point:> Choicelist Available for <Method: 2 Points>. The end point of the line. All points from COGO Data: Job Name can be selected. <Azimuth:> User input Available for <Method: Pt/Brg/Dist>. The azimuth of the line. <HDist-XX:> User input Available for <Method: Pt/Brg/Dist>.
  • Page 748 COGO TPS1200 Next step THEN <Task: Calc Base Point> CALC (F1) accesses COGO Base Point Results. Refer to paragraph "COGO XX Point Results, Result page". <Task: Calc Offset Point> CALC (F1) accesses COGO Offset Point Results. Refer to paragrahp "COGO XX Point Results, Result page". <Task: Segmentation>...
  • Page 749 SHIFT ELL H (F2) and SHIFT ORTH (F2) To change between the ellipsoidal and the orthometric height. Available unless <Coord System: None>. SHIFT INDIV (F5) and SHIFT RUN (F5) To change between entering an individual point ID different to the defined ID template and the running point ID according to the ID template.
  • Page 750 COGO TPS1200 Field Option Description <Line Brng:> Output Bearing of line from start point to end point. <Offs Pt Brng:> Output Bearing of offset point from base point to offset point. Next step PAGE (F6) changes to the Code page. COGO The functionality of the Code page is similar to COGO Traverse Result, Code page.

  • Page 751: Line Calculation - Offset Point

    36.7.2 Line Calculation - Offset Point Description The COGO line calculation offset point calculates the coordinates of a new point after input of station and offset values in relation to a line. Elements that must be known are • coordinates of two points. •...
  • Page 752 COGO TPS1200 Step Description Refer to chapter COGO Line Calculations Input, Input page. SHIFT CONF (F2) to configure the COGO application program. 36.3 COGO Line Calculations Input, Input page. 36.7.1 <Task: Calc Offset Point> CALC (F1) calculates the results. COGO Offset Point Results, Result page 36.7.1 STORE (F1) stores the results.

  • Page 753: Line Calculation - Segmentation

    36.7.3 Line Calculation - Segmentation Description The COGO line calculation segmentation calculates the coordinates of new points on a line. Elements that must be known are • coordinates of the start and the end point of the line • a bearing and distance from a known point that define the line AND EITHER •...
  • Page 754 COGO TPS1200 Line divided by <Method: Segment Length> P0 <Start Point:> P1 <End Point:> GPS12_145 <Seg Length:> Remaining segment COGO line calculation The following table explains the most common settings. Refer to the stated chapter for more segmentation step-by- information on screens. step Step Description...
  • Page 755 Step Description Refer to chapter <No. of Segs:> For <Method: No. of Segments> type in the number of segments for the line. For <Method: Segment Length> type in the segment length for the line. A remaining segment may result from this method.
  • Page 756 COGO TPS1200 Step Description Refer to chapter <Last Segment Lgth:> Available for <Method: Segment Length>. The length of the remaining segment. STAKE (F5) to access the Stakeout application program and stake out the calculated COGO point. SHIFT QUIT (F6) or ESC return to COGO Segmentation Results, Result page.

  • Page 757: Cogo Calculation - Arc Calculations Method

    36.8 COGO Calculation - Arc Calculations Method 36.8.1 Arc Calculation - Arc Center Description The COGO arc calculation arc center calculates the coordinates of the centre of the arc. Elements that must be known are • coordinates of three points •...
  • Page 758 COGO TPS1200 Arc management is not available for COGO arc calculations. Access Refer to "36.2 Accessing COGO" to access COGO Arc Calculations Input. COGO The softkeys are similar to line calculation. Refer to "36.7.1 Line Calculation - Base Point" for Arc Calculations Input information on softkeys.
  • Page 759 Field Option Description 2 Tgnts/Chrd Defines the arc using two tangents and the chord of Lngt the arc. <Start Point:> Choicelist The start point of the arc. All points from COGO Data: Job Name can be selected. Available for <Method: 3 Points> and <Method: 2 Points/Radius>.
  • Page 760 COGO TPS1200 Field Option Description <Arc Length:> User input The length of the arc. Available for <Method: 2 Tgnts/Arc Lngt>. <Chord Length:> User input The length of the chord. Available for <Method: 2 Tgnts/Chrd Lngt>. <∆ArcDist-XX:> User input Horizontal distance along the arc from start point to base point.
  • Page 761 COGO Refer to paragraph "36.7.1 Line Calculation - Base Point" for information on softkeys. XX Results, Result page Description of fields Field Option Description <Point ID:> User input The identifier for the COGO point depending on the point ID template configured for <Survey Pts:> in CONFIGURE ID Templates.
  • Page 762 COGO TPS1200 Next step PAGE (F6) changes to the Code page. COGO The functionality of the Code page is similar to COGO Traverse Results, Code page. XX Results, Code page Next step PAGE (F6) changes to the Plot page. COGO The functionality of the Plot page is similar to COGO Traverse Results, Plot page.

  • Page 763: Arc Calculation - Base Point

    36.8.2 Arc Calculation - Base Point Description The COGO arc calculation base point calculates the coordinates of the base point, station and offset of a point in relation to an arc. Elements that must be known are • coordinates of three points •...
  • Page 764 COGO TPS1200 Diagram P0 Instrument station P1 <Start Point:> P2 <End Point:> P3 <Offset Point:> P4 Base point <∆Offset-XX:> <∆ArcDist-XX:> TPS12_186 Arc management is not available for COGO arc calculations. COGO arc calculation The following table explains the most common settings. Refer to the stated chapter for more base point step-by-step information on screens.
  • Page 765 Step Description Refer to chapter CALC (F1) calculates the results. COGO Base Point Results, Result page 36.8.1 STORE (F1) stores the results. COGO TPS1200...

  • Page 766: Arc Calculation - Offset Point

    COGO TPS1200 36.8.3 Arc Calculation - Offset Point Description The COGO arc calculation offset point calculates the coordinates of a new point after input of arc and offset values in relation to an arc. Elements that must be known are •...
  • Page 767 Step Description Refer to chapter COGO Arc Calculations Input, Input page. SHIFT CONF (F2) to configure the COGO application program. 36.3 COGO Arc Calculations Input, Input page. 36.8.1 <Task: Calc Offset Point> CALC (F1) calculates the results. COGO Offset Point Results, Result page 36.8.1 STORE (F1) stores the results.

  • Page 768: Arc Calculation - Segmentation

    COGO TPS1200 36.8.4 Arc Calculation - Segmentation The COGO arc calculation segmentation and the functionality of all screens and fields are similar to those for COGO line calculation segmentation. Refer to "36.7.3 Line Calculation - Segmentation". Exceptions to line New field and option in COGO Define Segmentation calculation segmenta- Field Option...

  • Page 769: Cogo Calculation - Shift, Rotate & Scale (Manual) Method

    36.9 COGO Calculation - Shift, Rotate & Scale (Manual) Method Description The COGO calculation shift, rotate & scale (manual) applies shifts and/or rotation and/or scale to one or several known points. The values for shifts and/or rotation and/or scale are typed in manually.
  • Page 770 COGO TPS1200 Diagram P1’ P2’ Shift Height Easting P1 Known point P1’ Shifted point P2 Known point P2’ Shifted point GPS12_155 Rotation Height Easting P0 <Rotation Pt:> P1’ P1 Known point P2’ P1’ Rotated point P2 Known point P2’ Rotated point GPS12_156...
  • Page 771 Scale Height Easting P1 <Rotation Pt:>, can be held fixed, all other points are then scaled from here P4’ P5’ P2 Known point P2’ Scaled point P3 Known point P3’ Scaled point P4 Known point P4’ Scaled point P2’ P3’ P5 Known point P5’...
  • Page 772 COGO TPS1200 COGO Listed are points which have been selected for shifting, rotating and/or scaling. Shift, Rotate & Scale, Points page CALC (F1) To perform the shift, rotation and scale calcula- tion and to continue with the subsequent screen. Calculated COGO points are not yet stored.
  • Page 773 PAGE (F6) To change to another page on this screen. SHIFT REM A (F4) To remove all points from the list. The points itself are not deleted. SHIFT RANGE (F5) To define a range of points from the active job to be added to the list.
  • Page 774 COGO TPS1200 COGO Select Points by Range CONT (F1) To add the points within the selected range to the list in COGO Shift, Rotate & Scale, Points page and to return to the screen from where this screen was accessed. NEXT (F3) To add the points within the selected range to the list in COGO Shift, Rotate &...
  • Page 775 Field Option Description • Alphanumeric point ID’s in both fields: The left most character of both entries is used as the basis for the range. The standard ASCII numerical range is used. Points with alphanu- meric point ID’s falling within the range are selected.
  • Page 776 COGO TPS1200 COGO Shift, Rotate & Scale, Shift page CALC (F1) To perform the shift, rotation and scale calcula- tion and to continue with the subsequent screen. Calculated COGO points are not yet stored. INV (F2) To calculate the amout of shift in Easting, Northing and height from two existing points.
  • Page 777 SHIFT MODIF (F4) To mathematically modify the values. Available if <∆ Easting:>, <∆ Northing:> or <∆ Height:> is highlighted. Description of fields Field Option Description <Method:> The method by which the shift in ∆ Easting, ∆ Northing and ∆ Height will be determined. Enter Defines the shift using coordinate differences.
  • Page 778 COGO TPS1200 Field Option Description <∆ Easting:> User input or The amount of shift in East direction. output <∆ Northing:> User input or The amount of shift in North direction. output <∆ Height:> User input or The amount of shift in height. output Next step PAGE (F6) accesses COGO Shift, Rotate &...
  • Page 779 Field Option Description <Existing Az:> User input Available for <Method: Computed>. A known direc- tion before rotating. <New Azimuth:> User input Available for <Method: Computed>. A known direc- tion after rotating. <Rotation:> User input or The amount by which the points will be rotated. output Next step PAGE (F6) accesses COGO Shift, Rotate &...
  • Page 780 COGO TPS1200 Field Option Description <Existing Dist:> User input Available for <Method: Computed>. A known distance before scaling. This value is used for calcu- lating the scale factor. <New Dist:> User input Available for <Method: Computed>. A known distance after scaling. This value is used for calcu- lating the scale factor.
  • Page 781 COGO Shift, Rotate & Scale Store, General page STORE (F1) To to store the results and continue with the next subsequent screen. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Pts Selected:> Output The number of selected points having been shifted, rotated and/or scaled.
  • Page 782 COGO TPS1200 Field Option Description <Identifier:> User input The identifier with up to four characters is added in front of or at the end of the ID of the calculated COGO points. <Prefix/Suffix:> Prefix Adds the setting for <Identifier:> in front of the orig- inal point ID’s.
  • Page 783 COGO Description of fields Shift, Rotate & Scale Field Option Description Results <No. of New Pts:> Output Number of new points created. Result page <No. of Skipped Pts> Output Number of points which were skipped either due to not being able to convert coordinates or points with identical point ID’s already existed in <Store Job:>.

  • Page 784: Cogo Calculation - Shift, Rotate & Scale (Match Pts) Method

    COGO TPS1200 36.10 COGO Calculation - Shift, Rotate & Scale (Match Pts) Method Description The COGO calculation shift, rotate & scale (match pts) applies shifts and/or rotation and/or scale to one or several known points. The shifts and/or rotation and/or scale are calculated from selected points using a 2D Helmert tranformation.
  • Page 785 Number of Shift East Shift North Shift Height Rotation Scale pairs of points matched > 1 Access Refer to "36.2 Accessing COGO" to access COGO Match Common Points (n). COGO This screen provides a list of points chosen from the active job. The points are used for the Match Common Points determination of the 2D Helmert transformation.
  • Page 786 COGO TPS1200 DEL (F4) To delete the highlighted pair of matched points from the list. MATCH (F5) To change the type of match for a highlighted pair of matched points. Refer to "Description of columns". RESID (F6) To display a list of the matched points used in the transformation calculation and their associ- ated residuals.
  • Page 787 Column Description None removes matched common points from the transformation calculation but does not delete them from the list. This can be used to help improve residuals. Next step THEN the transformation is CALC (F1). The calculated shift, rotation and scale values are to be computed displayed in COGO Shift, Rotate &...
  • Page 788 COGO TPS1200 Step Description COGO Choose Matching Points or COGO Edit Matching Points <Source Pt:> A point of origin for the calculation of the shifts and/or rotation and/or scale. <Target Pt:> A target point for the calculation of the shifts and/or rotation and/or scale.
  • Page 789 Description of fields Field Option Description <∆ Easting:> User input Shift in Easting direction. <∆ Northing:> User input Shift in Northing direction. <∆ Height:> User input Shift in Height direction. <Rotation:> User input Rotation around the X axis. <Scale:> User input Scale factor.

  • Page 790: Area Division

    COGO TPS1200 36.11 Area Division 36.11.1 Overview Description The COGO calculation area division divides an area by a defined line, by percentage or by the size of a subarea. The area division methods are listed in the table below. Elements that must be known for the calculation depend on the area division method.
  • Page 791 Divide by Using Elements required Swing line Rotation point • Size of new area in percentage • Rotation point of the swing line Area Parallel line • Size of new area • Two points defining the line Perpendicular line • Size of new area •...
  • Page 792 COGO TPS1200 Diagram The diagrams show the area division methods. Some diagrams apply to several area division methods. Area division method <Divide:> <Using:> <Shift:> By Defined Line Parallel Line By Distance By Percentage Parallel Line By Area Parallel Line P0 <Point A:> of defined line P1 <Point B:>...
  • Page 793 Area division method <Divide:> <Using:> <Shift:> By Defined Line Perpendic Line By Distance By Percentage Perpendic Line By Area Perpendic Line P0 <Point A:> of defined line P1 <Point B:> of defined line P2 First new COGO point P3 Second new COGO point <HDist-XX:>...
  • Page 794 COGO TPS1200 Area division method <Divide:> <Using:> <Shift:> By Defined Line Parallel Line Through Point P0 <Point A:> of defined line P1 <Point B:> of defined line P2 <Through Point:>; in this case it is a known point of the existing border P3 New COGO point <HDist-XX:>...
  • Page 795 Area division method <Divide:> <Using:> <Shift:> By Defined Line Perpendic Line Through Point P0 <Point A:> of defined line P1 <Point B:> of defined line P2 <Through Point:>; in this case it is a known point of the existing border P3 New COGO point <HDist-XX:>...
  • Page 796 COGO TPS1200 Area division method <Divide:> <Using:> <Shift:> By Percentage Swing Line By Area Swing Line α P0 First new COGO point P1 Second new COGO point P3 <Rotation Pnt:> α <Azimuth:> TPS12_222...

  • Page 797: Choosing An Area To Be Divided

    36.11.2 Choosing an Area to be Divided Access Refer to "36.2 Accessing COGO" to access COGO Choose Area to be Divided. COGO Choose Area to be Divided CONT (F1) To accept the changes and access the subse- quent screen. Description of fields Field Option Description...
  • Page 798 COGO TPS1200 Field Option Description Survey New To survey points that do not exist in the job yet. The Area points will be added to a new area. <Area ID:> Choicelist For <Area to Use: Select Existing>. To select the area to be divided.
  • Page 799 COGO Points to be added to the new area can be surveyed. Survey: Job Name, Survey page ALL (F1) To measure and store distances and angles. DIST (F2) To measure and display distances. Available unless <EDM Mode: Tracking> and/or <Log Auto Pts: Yes>, after the tracking or logging is started.
  • Page 800 COGO TPS1200 Description of fields Field Option Description <Point ID:> User input The identifier for manually occupied points. The configured point ID template is used. The ID can be changed in the following ways: • To start a new sequence of point ID’s type over the point ID.
  • Page 801 Next step IF the task is to THEN change to another page on this PAGE (F6). screen stop surveying the area and to DONE (F4) and then STORE (F1). COGO Define How store the area to Divide Area is accessed. Refer to "36.11.3 Dividing an Area".

  • Page 802: Dividing An Area

    COGO TPS1200 36.11.3 Dividing an Area Access Refer to "36.11.2 Choosing an Area to be Divided" to access COGO Define How to Divide Area. COGO After each change of parameters in this screen, the values in the output fields are recalcu- Define How to Divide lated and updated.
  • Page 803 PAGE (F6) To change to another page on this screen. SHIFT CONF (F2) To configure the COGO application program. SHIFT MODIF (F4) To mathematically modify the values for the distance or angle. Available if <HDist-XX:> or <Azimuth:> is highlighted. Description of fields Field Option Description...
  • Page 804 COGO TPS1200 Field Option Description <Sub-Area-XX:> User input For <Divide By: Percentage> and <Divide By: Area>. The size of the sub area must be typed either in % or in m When dividing the area using a parallel or perpendic- ular line, a reference line is defined by <Point A:>...
  • Page 805 Field Option Description By Distance The new border will run in a certain distance from the line defined by <Point A:> and <Point B:>. Through The new border will run through a point defined in Point <Through Point:>. <Through Point:> Choicelist Available for <Shift: Through Point>.
  • Page 806 COGO TPS1200 COGO The Map page provides an interactive display of the data. Refer to "34 MapView Interactive Define How to Divide Display Feature" for information on the functionality and softkeys available. Area, Map page Next step CALC (F1) performs the area division and accesses COGO Results of Area Division. Refer to "36.11.4 Results of the Area Division".

  • Page 807: Results Of The Area Division

    36.11.4 Results of the Area Division Access CALC (F1) in COGO Define How to Divide Area. COGO Results of Area Divi- sion, Result page CONT (F1) To accept the calculation and to continue with the subsequent screen. Calculated COGO points are not yet stored. PAGE (F6) To change to another page on this screen.
  • Page 808 COGO TPS1200 COGO The points defining the area and the calculated COGO points are shown in black. Results of Area Divi- sion, Next step Map page CONT (F1) access COGO Area Division Results. COGO The coordinates of the intersection points of the new border with the original area are Area Division Results, displayed.
  • Page 809 Description of fields Field Option Description <Point ID:> User input The identifier for the COGO point depending on the point ID template configured for <Survey Pts:> in CONFIGURE ID Templates. <Height:> User input A height value to be stored with the calculated point can be typed in.

  • Page 810: Working Example

    COGO TPS1200 36.11.5 Working Example Description Application: Divide an area by a defined, parallel line. The new border has to run through a known point with the point ID 100. Working technique: Real-time kinematic. Goal: The points forming the original area are to be picked. The area division is to be calculated.
  • Page 811 Field procedure step- Step Description by-step Main Menu: Programs...\COGO COGO COGO Begin Select a job and a configuration set with the settings mentioned above. CONF (F2) to configure the COGO application program. CONT (F1) to access COGO COGO Menu. Highlight Area Division. CONT (F1) to access COGO Choose Area to be Divided.
  • Page 812 COGO TPS1200 Step Description <Divide By: Defined Line> <Using: Parallel Line> <Point A:> and <Point B:> Select the first and the second point of the line which is used as the reference for the new border. The new border will run parallel to this line.
  • Page 813 Step Description STAKE (F5) to access the Stakeout application program and stake out the calcu- lated COGO point. SHIFT ELL H (F2) and SHIFT ORTH (F2). Available for local coordinates. Changes between the ellipsoidal and the orthometric height. SHIFT INDIV (F5) for an individual point ID independent of the ID template. SHIFT RUN (F5) changes back to the next ID from the configured ID template.

  • Page 814: Selecting A Result From Previous Cogo Inverse Calculations

    COGO TPS1200 36.12 Selecting a Result from Previous COGO Inverse Calculations Description Azimuths, distances and offsets required within the COGO traverse and intersection calcu- lations can be selected from previously calculated inverse results. Select a result from Step Description previous COGO inverse Refer to "36.2 Accessing COGO"...
  • Page 815 Step Description HDist-XX: The horizontal distance between the two known points. Date and Time when the COGO inverse calculation was stored. VIEW (F3) to view all calculated values for the highlighted COGO inverse calcula- tion. This includes the height difference, the slope distance, the grade and the coordinate differences between the two known points.

  • Page 816: Modifying Values For Azimuths, Distances And Offsets

    COGO TPS1200 36.13 Modifying Values for Azimuths, Distances and Offsets Description The values for the azimuth, the distance and the offset required within the COGO traverse and intersection calculation can be mathematically modified. Access step-by-step Step Description Refer to "36.2 Accessing COGO" to access COGO Traverse Input or COGO Intersection Input.
  • Page 817 CONT (F1) To accept the modified value and to return to the screen from where this screen was accessed. The modified value is copied into the field which was initially highlighted in COGO XX Input, Input page. Description of fields Field Option Description...
  • Page 818 COGO TPS1200 Field Option Description • Maximum: 3000 • ----- performs a division by 1. <Add:> User input The number to be added. • For azimuths Minimum: 0 Maximum: Full circle • For distances and offsets Minimum: 0 m Maximum: 30000000 m •...
  • Page 819 Next step CONT (F1) accepts the modified value and returns to the screen from where this screen was accessed. Example: Calculations Step User input Value as calculated Value as displayed for an azimuth <Azimuth: 250.0000> g <Multiply: 2> <Azimuth: 100.0000> g <Divide: 3>...

  • Page 820: Determine Coordinate System - General

    Determine Coordinate System - General TPS1200 Determine Coordinate System - General 37.1 Overview Description GPS measured points are always stored based on the global geocentric datum known as WGS 1984. Using GPS measured points with the TPS1200 requires coordinates in a local grid system, for example, based on a country’s official mapping datum or an arbitrary grid system used in a particular area such as a construction site.
  • Page 821 Transformation parameters A transformation consists of a number of shifts, rotations and scale factors, depending on the type of transformation used. Not all of these parameters are always required. These param- eters may already be known, or may need to be computed. Description of transformations Three different transformations are provided: •...
  • Page 822 Determine Coordinate System - General TPS1200 Transformation Characteristic Description Requirements • The positions and heights are known in WGS 1984 and in the local system for at least three points. Four points or more are recom- mended in order to obtain higher redundancy. •...
  • Page 823 Transformation Characteristic Description Onestep Principle Transforms coordinates directly from WGS 1984 to local grid and vice versa without knowledge about the local ellipsoid or the map projection. Procedure: 1. The WGS 1984 coordinates are projected onto a temporary Transverse Mercator projection. The central meridian of this projection passes through the centre of gravity of the common control points.
  • Page 824 Determine Coordinate System - General TPS1200 Transformation Characteristic Description When measurements are to be forced to tie in with local existing control. For example: A site where the coordinates of the control points are based on a purely local grid. The coordinate values within this grid are totally arbitrary and are in no way connected with any ellipsoid or map projection.
  • Page 825 Transformation Characteristic Description Points and trans- The transformation parameters determined depend formation parame- on the number of available points with position infor- ters mation. • One point: Classic 2D with shift in X and Y. • Two points: Classic 2D with shift in X and Y, rota- tion about Z and scale.
  • Page 826 Determine Coordinate System - General TPS1200 Transformation Characteristic Description Advantage • Errors in height do not propagate into errors in position since the height and position transforma- tions are separated. • If local heights have low accuracy or do not exist, a transformation of position can still be calculated and vice versa.
  • Page 827 Transformation Characteristic Description Twostep Principle Combines the advantages of the Onestep and the Classic 3D transformation. It allows treating position and height separately, but is not restricted to smaller areas. Procedure: 1. The WGS 1984 coordinates of the common control points are shifted closely to the local datum using a given Classic 3D pretransforma- tion.
  • Page 828 Determine Coordinate System - General TPS1200 Transformation Characteristic Description • Parameters of a pretransformation. Area Virtually any area as long as the local coordinates are accurate. Points and trans- Identical with the Onestep transformation. formation parame- ters Points and height Identical with the Onestep transformation.
  • Page 829 Transformation Characteristic Description • Fits much better over larger areas than a Onestep transformation. Reason: The first step of a Twostep transformation avoids any distortions due to the fact that the preliminary grid coordinates are built on a different ellipsoid than the local points.
  • Page 830 Determine Coordinate System - General TPS1200 Requirements to deter- To determine a transformation it is necessary to have common control points whose posi- mine a transformation tions are known in both WGS 1984 coordinates and local coordinates. The more points that are common between datums the more accurately the transformation parameters can be calculated.
  • Page 831 Coordinate system deter- Characteristic Description mination method Transformation to use • Onestep or Twostep when information about the necessary rotations and scale factor is known. • Classic 3D when the rota- tions are to be set to zero and the scale factor to one.

  • Page 832: Accessing Determine Coordinate System

    Determine Coordinate System - General TPS1200 37.2 Accessing Determine Coordinate System Access Select Main Menu: Programs...\Determine Coordinate System. Press PROG. Highlight Determine Coordinate System. CONT (F1). Refer to "35.2 Accessing the Programs Menu" for information on the PROG key. Press a hot key configured to access the screen DET C SYS Determine Coord System Begin.
  • Page 833 Description of fields Field Option Description <Name:> User input A unique name for the coordinate system. The name may be up to 16 characters in length and may include spaces. Input is mandatory. Entering the name of a coordinate system will allow that existing system to be updated.
  • Page 834 Determine Coordinate System - General TPS1200 THEN <Method: the application CONF (F2) to access DET C SYS Configuration. program needs Refer to "37.3.2 Configuring Determine Coordinate One Pt Localistn> configuring System - One Point Localisation". <Method: Normal> the application CONT (F1) to access DET C SYS Step 1: Choose program does Transform Type.

  • Page 835: Configuring Determine Coordinate System

    37.3 Configuring Determine Coordinate System 37.3.1 Configuring Determine Coordinate System - Normal Description The configuration of DET C SYS, normal method, allows options to be set which are used as the default options within the Determine Coordinate System application program when using the normal method.
  • Page 836 Determine Coordinate System - General TPS1200 CONT (F1) To accept changes and return to the screen from where this screen was accessed. FIX (F4) or ADJST (F4) Available for Classic 3D page unless <Transf Model:> is highlighted. To define which parameters are computed or fixed in the Classic 3D transformation.
  • Page 837 Field Option Description <Default Height Orthometric The default height type to be used when determining Mode:> or Ellipsoidal the coordinate system. <Default Match:> Pos & Height, Options available depend on the choice made for Pos Only, <Default Transformation:>. Point parameters to be Height Only or matched between points in both datums.
  • Page 838 Determine Coordinate System - General TPS1200 Field Option Description None No distribution is made. Residuals remain with their associated points. 1/Distance Distributes the residuals according to the distance between each control point and the newly trans- formed point. Multiquad- Distributes the residuals using a multiquadratic inter- ratic polation approach.
  • Page 839 Description of fields Field Option Description <Transf Model:> Bursa Wolf or The transformation model to be used. Refer to Molodensky- standard surveying literature for details on the models. <Shift dX:> User input Shift in X direction. <Shift dY:> User input Shift in Y direction.
  • Page 840 Determine Coordinate System - General TPS1200 THEN all parameters are CONT (F1) to return to DET C SYS Determine configured Coord System Begin.

  • Page 841: Configuring Determine Coordinate System - One Point Localisation

    37.3.2 Configuring Determine Coordinate System - One Point Localisation Description The configuration of DET C SYS, one point localisation method, allows options to be set which are used as the default options within the Determine Coordinate System application program when using the one point localisation method. These settings are stored within the active configuration set.
  • Page 842 Determine Coordinate System - General TPS1200 CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Default Method:> Normal or One Method used to determine the coordinate system.
  • Page 843 Field Option Description <Default Height Orthometric The default height mode to be used when deter- Mode:> or Ellipsoidal mining the coordinate system. Next step PAGE (F6) changes to the Onestep page. Refer to paragraph "DET C SYS Configuration, Onestep page". DET C SYS Description of fields Configuration,...
  • Page 844 Determine Coordinate System - General TPS1200 Field Option Description <Default Height The default method for determining the height scale SF:> factor to be used in the transformation process. User Entered Height scale factor can be manually typed in. Known Height scale factor defined by a known point on the WGS84 Pt WGS 1984 datum.
  • Page 845 Field Option Description Two WGS84 Rotation defined by two points on the WGS 1984 Points datum. Refer to "39.2 Determine Coordinate System - Onestep Transformation" paragraph "DET C SYS Step 4: Determine Rotation" for a diagram. <Default Scale:> The default method for determining the scale factor to be used in the transformation process.
  • Page 846 Determine Coordinate System - General TPS1200 DET C SYS Description of fields Configuration, Field Option Description Classic 3D page <Default Local Use WGS84 Source of height information to use. Height:> Pt Ht or Use Local Pt Ht Next step CONT (F1) returns to DET C SYS Determine Coord System Begin.
  • Page 847 Determine Coordinate System - General TPS1200...

  • Page 848: Determine Coordinate System - Normal

    Determine Coordinate System - Normal TPS1200 Determine Coordinate System - Normal 38.1 Overview Description The Determine Coordinate System application program allows a new coordinate system to be determined or a coordinate system to be updated. The coordinate system is defined by the transformation used to convert coordinates from one geodetic datum to another.

  • Page 849: Determining A New Coordinate System

    38.2 Determining a New Coordinate System Access step-by-step Step Description Refer to "37.2 Accessing Determine Coordinate System" to access DET C SYS Determine Coord System Begin. Select <Method: Normal>. CONT (F1) to access DET C SYS Step 1: Choose Transform Type. DET C SYS Step 1: Choose Trans- form Type...
  • Page 850 Determine Coordinate System - Normal TPS1200 Description of fields Field Option Description <Transfrm Name:> User input A unique name for the transformation. The name may be up to 16 characters in length and may include spaces. If a coordinate system is being updated then its name is displayed.
  • Page 851 If a coordinate system was chosen to be edited in DET C SYS Determine Coord System Begin, pressing CONT (F1) DET C SYS Step 3: Match Points (n). Pressing ESC accesses does not re-access DET C SYS Determine Coord System Begin but accesses DET C SYS Step 2: Choose Parameters and DET C SYS Step 1: Choose Transform Type.
  • Page 852 Determine Coordinate System - Normal TPS1200 For <Transfrm Type: Twostep> Description of fields Field Option Description <Pre Transform:> Choicelist The pre-transformation to use for the preliminary 3D transformation. All 3D transformations from MANAGE Transformations can be selected. <Ellipsoid:> Choicelist The ellipsoid to use in the transformation. All ellip- soids from MANAGE Ellipsoids can be selected.
  • Page 853 Field Option Description Output The ellipsoid being used by a hard wired projection when selected in <Projection:>. <Projection:> Choicelist The projection to use in the transformation. All projections from MANAGE Projections can be selected. <Geoid Model:> Choicelist The geoid model to use in the transformation. Geoid models from MANAGE Geoid Models can be selected.
  • Page 854 Determine Coordinate System - Normal TPS1200 CALC (F1) To confirm the selections, compute the trans- formation and continue with the subsequent screen. NEW (F2) To match a new pair of points. This pair is added to the list. A new point can be meas- ured.
  • Page 855 SHIFT PARAM (F5) Available for <Transfrm Type: Classic 3D> in DET C SYS Step 1: Choose Transform Type. To configure Classic 3D transformation parameters. Refer to "37.3.1 Configuring Determine Coordinate System - Normal" para- graph "DET C SYS Configuration, Classic 3D page".
  • Page 856 Determine Coordinate System - Normal TPS1200 Next step CALC (F1) computes the transformation and continues to DET C SYS Step 4: Check Resid- uals. Refer to paragraph "DET C SYS Step 4: Check Residuals". If a coordinate system to be updated contains a point that was deleted from the active job and a new point was created in that job with the same point ID but different coordinates, the coordinates of the old point will still be used for the calculation.
  • Page 857 Description of columns Column Description WGS84 Pts The point ID of the points chosen from <WGS84 Pts Job:>. East The Easting residual. If positions were not used in the transformation calculation then ----- will be displayed. North The Northing residual. If positions were not used in the transformation calculation then ----- will be displayed.
  • Page 858 Determine Coordinate System - Normal TPS1200 DET C SYS This screen consists of the Summary page and the Coord System page. The Coord Step 5: Store Coord System page contains different fields, depending on what transformation type was chosen System, in DET C SYS Step 1: Choose Transform Type.
  • Page 859 Field Option Description <Matched Pts:> Output Number of matched points, as defined in DET C SYS Step 3: Match Points (n). <Easting:> Output Largest Easting residual from the transformation calculation. <Northing:> Output Largest Northing residual from the transformation calculation. <Height:> Output Largest Height residual from the transformation calculation.
  • Page 860 Determine Coordinate System - Normal TPS1200 For <Transfrm Type: Twostep> Description of fields Field Option Description <Residuals:> None, The method by which the residuals of the control 1/Distance points will be distributed throughout the transforma- or Multiquad- tion area. Refer to "37.3.1 Configuring Determine ratic Coordinate System - Normal"...
  • Page 861 For <Transfrm Type: Classic 3D> Description of fields Field Option Description <Residuals:> None, The method by which the residuals of the control 1/Distance points will be distributed throughout the transforma- or Multiquad- tion area. Refer to "37.3.1 Configuring Determine ratic Coordinate System - Normal"...

  • Page 862: Updating A Coordinate System

    Determine Coordinate System - Normal TPS1200 38.3 Updating a Coordinate System Access step-by-step Step Description Refer to "37.2 Accessing Determine Coordinate System" to access DET C SYS Determine Coord System Begin. Select <Method: Normal>. Enter the name of a coordinate system in <Name:> CSYS (F6) to select a coordinate system.

  • Page 863: Matching Points

    38.4 Matching Points 38.4.1 Overview Description Before calculating a transformation, it must be defined which points in <WGS84 Pts Job:> and <Local Pts Job:> are to be matched. Pairs of matched points are displayed in one line in DET C SYS Step 3: Match Points (n). New pairs of matched points can be created, existing pairs of matched points can be edited and pairs of matched points can be deleted.

  • Page 864: Selecting A New Pair Of Matching Points

    Determine Coordinate System - Normal TPS1200 38.4.2 Selecting a New Pair of Matching Points Match points step-by- Step Description step Refer to "38.2 Determining a New Coordinate System" to access DET C SYS Step 3: Match Points (n). NEW (F2) to access DET C SYS Choose Matching Points. DET C SYS Choose Matching Points <WGS84 Point:>...

  • Page 865: Editing A Pair Of Matching Points

    38.4.3 Editing a Pair of Matching Points Edit matching points Step Description step-by-step Refer to "38.2 Determining a New Coordinate System" to access DET C SYS Step 3: Match Points (n). DET C SYS Step 3: Match Points (n) Highlight the pair of matching points to be edited. EDIT (F3) to access DET C SYS Edit Matching Points.

  • Page 866: Transformation Results

    Determine Coordinate System - Normal TPS1200 38.5 Transformation Results 38.5.1 Accessing Transformation Results Access step-by-step Step Description The results of a transformation can be displayed during the process of determining or updating a coordinate system. Refer to "38.2 Determining a New Coordinate System". Follow the instructions to access DET C SYS Step 4: Check Residuals.

  • Page 867: Results For Onestep And Twostep Transformations

    38.5.2 Results for Onestep and Twostep Transformations DET C SYS Results of the transformation between the WGS 1984 datum and the local datum are shown Transformation for each of the transformation parameters. This screen consists of the Position page and Results, the Height page.
  • Page 868 Determine Coordinate System - Normal TPS1200 Description of fields Field Option Description <Shift dX:> Output Shift in X direction. <Shift dY:> Output Shift in Y direction. <Rotation:> Output Rotation of transformation. <Scale:> Output Scale factor used in transformation. Either true scale or ppm.
  • Page 869 Next step CONT (F1) returns to DET C SYS Step 4: Check Residuals. Determine Coordinate System - Normal TPS1200...

  • Page 870: Results For Classic 3D Transformation

    Determine Coordinate System - Normal TPS1200 38.5.3 Results for Classic 3D Transformation DET C SYS Results of the transformation between the WGS 1984 datum and the local datum are shown Transformation for each of the transformation parameters. This screen consists of the Parameters page and Results, the Rotn Origin page.
  • Page 871 Field Option Description <Rotation Y:> Output Rotation around the Y axis. <Rotation Z:> Output Rotation around the Z axis. <Scale:> Output Scale factor used in transformation. Either true scale or ppm. Next step PAGE (F6) changes to the Rotn Origin page. Refer to paragraph "DET C SYS Transforma- tion Results, Rotn Origin page".
  • Page 872 Determine Coordinate System - Normal TPS1200 Next step CONT (F1) returns to DET C SYS Step 4: Check Residuals.
  • Page 873 Determine Coordinate System - Normal TPS1200...

  • Page 874: Determine Coordinate System - One Point Localisation

    Determine Coordinate System - One Point Localisa- tion TPS1200 Determine Coordinate System - One Point Localisation 39.1 Accessing Determine Coordinate System - One Point Localisation Access step-by-step Step Description Refer to "37.2 Accessing Determine Coordinate System" to access DET C SYS Determine Coord System Begin.
  • Page 875 Description of fields Field Option Description <Transfrm Name:> User input A unique name for the coordinate system. The name may be up to 16 characters in length and may include spaces. <Transfrm Type:> Onestep, The type of transformation to be used when deter- Twostep or mining a coordinate system.
  • Page 876 Determine Coordinate System - One Point Localisa- tion TPS1200 <Azimuth:> is used throughout this chapter. This should always be considered to also mean <Bearing:>.

  • Page 877: Determine Coordinate System - Onestep Transformation

    39.2 Determine Coordinate System - Onestep Transformation Access step-by-step Step Description Refer to "39.1 Accessing Determine Coordinate System - One Point Localisation" to access DET C SYS Step 1: Choose Transform Type. DET C SYS Step 1: Choose Transform Type <Transfrm Type: Onestep>...
  • Page 878 Determine Coordinate System - One Point Localisa- tion TPS1200 Description of fields Field Option Description <Geoid Model:> Choicelist The geoid model to be used in the transformation. Geoid models from MANAGE Geoid Models can be selected. Next step CONT (F1) continues to DET C SYS Step 3: Choose Common Point. DET C SYS Step 3: Choose Common Point...
  • Page 879 Description of fields Field Option Description <Match Type:> How the horizontal and vertical shifts of the transfor- mation should be computed. Pos & Height Position and height are taken from the same pair of matching points. Pos Only Position is taken from one pair of matching points. The height can be taken from another pair of matching points.
  • Page 880 Determine Coordinate System - One Point Localisa- tion TPS1200 DET C SYS This screen contains different fields, depending on the <Method:> selected. The explana- Step 4: Determine Rota- tions for the softkeys given below are valid as indicated. tion CONT (F1) To confirm the selections and to continue with the subsequent screen.
  • Page 881 For <Method: Use WGS84 North> Description of fields Field Option Description <Rotation:> Output Transformation will be rotated to North as defined by the WGS 1984 datum. North is 0.00000 For <Method: User Entered> Description of fields Field Option Description <Rotation:> User input Allows the orientation of the transformation to be manually typed in or calculated in DET C SYS...
  • Page 882 Determine Coordinate System - One Point Localisa- tion TPS1200 For <Method: Convergnce Angle> α WGS 1984 coordinate system Local coordinate system, <Coord System:> Geodetic North Grid North Point on WGS 1984 datum, <WGS84 Point:> Meridian α Convergence angle, <Rotation:> GPS12_109 Description of fields Field Option...
  • Page 883 Field Option Description <Rotation:> Output The rotation of the transformation calculated as 0.00000 minus the computed convergence angle. The field is updated as <Coord System:> and <WGS84 Point:> are changed. For <Method: Two WGS84 Points> β α WGS 1984 coordinate system Local coordinate system Line between two WGS 1984 points.
  • Page 884 Determine Coordinate System - One Point Localisa- tion TPS1200 Description of fields Field Option Description <Point 1:> Choicelist First point to use for computation of <Azimuth:>. All points from <WGS84 Pts Job:> chosen in DET C SYS Determine Coord System Begin can be selected.
  • Page 885 formula (r + h)/r where r is the distance from the centre of the ellipsoid to the WGS 1984 point selected in DET C SYS Step 3: Choose Common Point and h is the height of this point above the WGS 1984 ellipsoid. CONT (F1) To confirm the selections and to continue with the subsequent screen.
  • Page 886 Determine Coordinate System - One Point Localisa- tion TPS1200 For <Method: User Entered> Description of fields Field Option Description <Scale:> User input Allows the scale factor to be typed in manually. For <Method: Known WGS84 Pt> Description of fields Field Option Description <WGS84 Point:>...
  • Page 887 Next step CONT (F1) continues to DET C SYS Step 6: Store Coord System. DET C SYS Step 6: Store Coord System STORE (F1) To store the coordinate system to the DB-X, attach the system to <WGS84 Pts Job:> that was selected in DET C SYS Determine Coord System Begin and return to TPS1200 Main Menu.
  • Page 888 Determine Coordinate System - One Point Localisa- tion TPS1200 Field Option Description <Scale:> Output Scale factor of transformation. <Rot Orig X:> Output Position in the X direction of the origin of rotation. <Rot Orig Y:> Output Position in the Y direction of the origin of rotation. Next step STORE (F1) stores the coordinate system and returns to TPS1200 Main Menu.

  • Page 889: Determine Coordinate System - Twostep Transformation

    39.3 Determine Coordinate System - Twostep Transformation 39.3.1 Twostep Transformation Access step-by-step Step Description Refer to "39.1 Accessing Determine Coordinate System - One Point Localisation" to access DET C SYS Step 1: Choose Transform Type. DET C SYS Step 1: Choose Transform Type <Transfrm Type: Twostep>...
  • Page 890 Determine Coordinate System - One Point Localisa- tion TPS1200 Description of fields Field Option Description <Pre Transform:> Choicelist The pretransformation to be used for the preliminary 3D transformation. All 3D transformations from MANAGE Transformations can be selected. <Ellipsoid:> Choicelist The ellipsoid to be used in the transformation. All ellipsoids from MANAGE Ellipsoids can be selected.
  • Page 891 DET C SYS Step 3: Choose Common Point CONT (F1) To confirm the selections and to continue with the subsequent screen. SURVY (F5) Available for <Known Point:> being high- lighted. To measured a point and store it in <Local Pts Job:>. Description of fields Field Option...
  • Page 892 Determine Coordinate System - One Point Localisa- tion TPS1200 Field Option Description <WGS84 Point:> Choicelist The point ID of the horizontal and/or vertical control point chosen from <WGS84 Pts Job:>. All WGS 1984 points from MANAGE Data: Job Name can be selected. <Known Point:>...
  • Page 893 DET C SYS This screen contains different fields, depending on the <Method:> selected. The explana- Step 4: Determine Rota- tions for the softkeys given below are valid as indicated. tion CONT (F1) To confirm the selections and to continue with the subsequent screen.
  • Page 894 Determine Coordinate System - One Point Localisa- tion TPS1200 For <Method: Use WGS84 North> Description of fields Field Option Description <Rotation:> Output Transformation will be rotated to North as defined by the WGS 1984 datum. North is 0.00000 For <Method: User Entered> Description of fields Field Option...
  • Page 895 For <Method: Convergnce Angle> α WGS 1984 coordinate system Local coordinate system, <Coord System:> Geodetic North Grid North Point on WGS 1984 datum, <WGS84 Point:> Meridian α Convergence angle, <Rotation:> GPS12_109 Description of fields Field Option Description <Coord System:> Choicelist Coordinate system to provide the direction of grid North in the area where the control point used for determining the local coordinate system, is located.
  • Page 896 Determine Coordinate System - One Point Localisa- tion TPS1200 Field Option Description <Rotation:> Output The rotation of the transformation calculated as 0.00000 minus the computed convergence angle. The field is updated as <Coord System:> and <WGS84 Point:> are changed. For <Method: Two WGS84 Points> β...
  • Page 897 Description of fields Field Option Description <Point 1:> Choicelist First point to use for computation of <Azimuth:>. All points from <WGS84 Pts Job:> chosen in DET C SYS Determine Coord System Begin can be selected. <Point 2:> Choicelist Second point to use for computation of <Azimuth:>. All points from <WGS84 Pts Job:>...
  • Page 898 Determine Coordinate System - One Point Localisa- tion TPS1200 DET C SYS This screen contains different fields, depending on the <Method:> selected. The explana- Step 5: Determine Scale tions for the softkeys given below are valid as indicated. The scale is calculated using the formula (r + h)/r where r is the radius of the ellipsoid at the position of the WGS 1984 point selected in DET C SYS Step 3: Choose Common Point and h is the height of this point above the local ellipsoid.
  • Page 899 Field Option Description <Grid SF:> Output Available for <Method: Compute CSF>. The grid scale factor as computed in DET C SYS Compute Grid Scale Factor. <Height SF:> Output Available for <Method: Compute CSF>. The height scale factor as computed in DET C SYS Compute Height Scale Factor.
  • Page 900 Determine Coordinate System - One Point Localisa- tion TPS1200 DET C SYS Step 6: Store Coord System STORE (F1) To store the coordinate system to the DB-X, attach the system to <WGS84 Pts Job:> that was selected in DET C SYS Determine Coord System Begin and return to TPS1200 Main Menu.
  • Page 901 Next step STORE (F1) stores the coordinate system and returns to TPS1200 Main Menu. Determine Coordinate System - One Point Localisa- TPS1200 tion...

  • Page 902: Computing The Grid Scale Factor

    Determine Coordinate System - One Point Localisa- tion TPS1200 39.3.2 Computing the Grid Scale Factor Description Calculates the grid scale factor. The grid scale factor is the scale factor of the point chosen relative to the projection being used. Access step-by-step Step Description Refer to "39.1 Accessing Determine Coordinate System - One Point Localisation"...
  • Page 903 Description of fields Field Option Description <Method:> Method by which the grid scale factor is to be calcu- lated. User Entered Grid scale factor can be manually typed in. Known Local Grid scale factor is computed using the position of a known local point.

  • Page 904: Computing The Height Scale Factor

    Determine Coordinate System - One Point Localisa- tion TPS1200 39.3.3 Computing the Height Scale Factor Description Calculates the height scale factor of the point chosen. Access step-by-step Step Description Refer to "39.1 Accessing Determine Coordinate System - One Point Localisation" to access DET C SYS Step 1: Choose Transform Type.
  • Page 905 Description of fields Field Option Description <Method:> Method by which the height scale factor is to be calculated. User Entered Height scale factor can be manually typed in. Known Local Height scale factor is computed using the height of a known local point.
  • Page 906 Determine Coordinate System - One Point Localisa- tion TPS1200 Next step CONT (F1) returns to DET C SYS Step 5: Determine Scale.

  • Page 907: Determine Coordinate System - Classic 3D Transformation

    39.4 Determine Coordinate System - Classic 3D Transformation Access step-by-step Step Description Refer to "39.1 Accessing Determine Coordinate System - One Point Localisation" to access DET C SYS Step 1: Choose Transform Type. DET C SYS Step 1: Choose Transform Type <Transfrm Type: Classic 3D>...
  • Page 908 Determine Coordinate System - One Point Localisa- tion TPS1200 Description of fields Field Option Description <Ellipsoid:> Choicelist The ellipsoid to be used in the transformation. All ellipsoids from MANAGE Ellipsoids can be selected. Output The ellipsoid being used by a hard wired projection when selected in <Projection:>.
  • Page 909 DET C SYS Step 3: Choose Common Point CONT (F1) To confirm the selections and to continue with the subsequent screen. SURVY (F5) To measure a point and store it in <Local Pts Job:>. Description of fields Field Option Description <WGS84 Point:>...
  • Page 910 Determine Coordinate System - One Point Localisa- tion TPS1200 Next step CONT (F1) continues to DET C SYS Step 4: Store Coord System. DET C SYS Step 4: Store Coord System STORE (F1) To store the coordinate system to the DB-X, attach the system to <WGS84 Pts Job:>...

  • Page 911: Computing Required Azimuth

    39.5 Computing Required Azimuth Description Available for <Method: Two WGS84 Points> and <Method: User Entered> in DET C SYS Step 4: Determine Rotation. Allows two local points to be chosen from <Local Pts Job:> selected in DET C SYS Deter- mine Coord System Begin between which the required azimuth will be computed.
  • Page 912 Determine Coordinate System - One Point Localisa- tion TPS1200 Step Description CONT (F1) to calculate the required azimuth and return to DET C SYS Step 4: Determine Rotation.
  • Page 913 Determine Coordinate System - One Point Localisa- TPS1200 tion...

  • Page 914: Gps Survey

    GPS Survey TPS1200 GPS Survey 40.1 Application Program Description GPS Survey is an application program which is used with SmartStation. The main purpose of this application program is to enable measurement of points in GPS mode without having to run through the Setup application program. Access Select Main Menu: Programs...\GPS Survey.
  • Page 915 Type Property Property Instrument source GPS SURVEY GPS Survey Begin CONT (F1) To accept changes and access the subse- quent screen. The chosen settings become active. CSYS (F6) To select a different coordinate system. Description of fields Field Option Description <Job:>...
  • Page 916 GPS Survey TPS1200 Field Option Description <Codelist:> Choicelist No codes are stored in the selected <Job:>. All codelists from Main Menu: Manage...\Codelists can be selected. Output Codes have already been stored in the selected <Job:>. If codes had been copied from a System RAM codelist, then the name of the codelist is displayed.
  • Page 917 • SmartAntenna is automatically turned on upon entry to the screen. SmartAntenna can be turned on beforehand by pressing the ON button located on the side. • Some of the screen icons change from TPS specific to GPS specific. • The GPS real-time radio link is automatically activated, if configured. •...
  • Page 918 GPS Survey TPS1200 STORE (F1) To store the measured point. When <Auto STORE: Yes> in CONFIGURE Point Occu- pation Settings, the measured point is stored automatically. (F1) changes to OCUPY. It may happen that a point with the same point ID exists in the job.
  • Page 919 SHIFT CONEC (F3) and SHIFT DISCO (F3) To dial the number of the reference station configured in the active configuration set and to hang up immediately after the survey is completed. Available for real-time devices of type digital cellular phone or modem.
  • Page 920 GPS Survey TPS1200 Field Option Description • For an individual point ID independent of the ID template SHIFT INDIV (F5). SHIFT RUN (F5) changes back to the next ID from the configured ID template. Refer to "16.1 ID Templates". <Instrument Ht:> User input Current instrument height.
  • Page 921 GPS SURVEY The Map page provides an interactive display of the data. Refer to "34 MapView Interactive GPS Survey, Display Feature" for information on the functionality and softkeys available. Map page Next step PAGE (F6) changes to the first page on this screen. GPS Survey TPS1200...

  • Page 922: Management Of Antennas Overview

    40.2 Management of Antennas 40.2.1 Overview Description • Leica Geosystems antennas are predefined as default and can be selected from a list. • Additional antennas can be defined. • Default antennas contain an elevation dependent correction model. • New antenna correction models can be set up and transferred to the receiver using LGO.

  • Page 923: Accessing Antenna Management

    40.2.2 Accessing Antenna Management Access Select Main Menu: Programs...\GPS Survey. From GPS SURVEY GPS Survey Begin highlight the choicelist for <Antenna:>. Open the choicelist to access MANAGE Antennas. The default antenna is SmartAntenna. Select Main Menu: Programs...\Setup. From SETUP Station Setup Begin press CONF (F2). Open the choicelist to access MANAGE Antennas.
  • Page 924 GPS Survey TPS1200 SHIFT DEFLT (F5) To recall previously deleted default antennas and to reset default antennas to the default settings. User defined antennas are not affected. Next step IF an antenna THEN is to be selected highlight the desired antenna. CONT (F1) closes the screen and returns to the screen from where MANAGE Antennas was accessed.

  • Page 925: Creating A New Antenna

    40.2.3 Creating a New Antenna Access Refer to "40.2.2 Accessing Antenna Management" to access MANAGE Antennas. Create new antenna The following table explains the most common settings. step-by-step Step Description In MANAGE Antennas press NEW (F2). MANAGE New Antenna, General page <Name:>...
  • Page 926 GPS Survey TPS1200 Step Description The combination of values typed in here provides a unique standardised ID for the antenna being used. STORE (F1) stores the new antenna and returns to MANAGE Antennas.

  • Page 927: Editing An Antenna

    MANAGE Edit Antenna All the following steps are identical with the creation of a new antenna. All fields can be edited except those of Leica default antennas. Refer to "40.2.3 Creating a New Antenna". Follow the instructions from step 2.

  • Page 928: Antenna Heights

    GPS Survey TPS1200 40.2.5 Antenna Heights Mechnical Description Reference Plane The Mechanical Reference Plane • is where the antenna heights are measured to. • is where the phase centre variations refer to. • varies for different antennas. Diagram a) The mechanical reference plane is the under- side of the threaded metal insert.
  • Page 929 GPS Survey TPS1200...

  • Page 930: Hidden Point

    Hidden Point TPS1200 Hidden Point 41.1 Overview Description Hidden points cannot be measured directly by TPS. This is because they are not directly visible. • A hidden point can be calculated from measurements to prisms mounted on a hidden point rod with a known spacing and a known length of the hidden point rod. The hidden point rod may be held at any angle, as long as it is stationary for all measurements.
  • Page 931 Reflector 1 Reflector 2 Reflector 3 Rod length Distance from reflector 1 to reflector 2 Distance from reflector 1 to reflector 3 TPS12_130 Properties of hidden The properties stored with the hidden point and auxiliary points are: points Type Reflector n - auxiliary point Hidden point Class MEAS MEAS...
  • Page 932 Hidden Point TPS1200 • Determination of recesses in building corners for detailed surveys, without estimating right angle offsets, with or without taping of the dimensions; • Measurements behind overhangs, buttresses and columns for quantity determinations in underground construction or mining, without estimating right angle offsets, with or without taping of the dimensions;...

  • Page 933: Accessing Hidden Point

    41.2 Accessing Hidden Point Access Select Main Menu: Programs...\Hidden Point. Press PROG. Highlight Hidden Point. CONT (F1). Refer to "35.2 Accessing the Programs Menu" for information on the PROG key. Press a hot key configured to access the screen HIDDEN PT Hidden Point Begin. Refer to "2.1 Hot Keys"...
  • Page 934 Hidden Point TPS1200 Description of fields Field Option Description <Job:> Choicelist The active job. All jobs from Main Menu: Manage...\Jobs can be selected. <Coord System:> Output The coordinate system currently attached to the selected <Job:>. <Codelist:> Choicelist No codes are stored in the selected job. All codelists from Main Menu: Manage...\Codelists can be selected.

  • Page 935: Configuring Hidden Point

    41.3 Configuring Hidden Point Access Select Main Menu: Programs...\Hidden Point. In HIDDEN PT Hidden Point Begin press CONF (F2) to access HIDDEN PT Configuration. Press PROG. Highlight TPS HIDDEN PT. CONT (F1). In HIDDEN PT Hidden Point Begin press CONF (F2) to access HIDDEN PT Configuration. Press SHIFT CONF (F2) in HIDDEN PT Survey Reflector 1.
  • Page 936 Hidden Point TPS1200 Description of fields Field Option Description <Display Mask:> Choicelist The user defined display mask to be shown in HIDDEN PT Measure Reflector n. All display masks of the active configuration set defined in CONFIGURE Display Settings can be selected. <Meas Tolerance:>...
  • Page 937 Field Option Description <Dist R1-R3:> User input Available for <No. of Reflectors: 3>. Spacing between the centres of reflector 1 and reflector 3. Reflector 3 is situated between reflector 1 and reflector 2. Next step CONT (F1) returns to the screen from where this screen was accessed from. Hidden Point TPS1200...

  • Page 938: Measuring Hidden Points

    Hidden Point TPS1200 41.4 Measuring Hidden Points Diagram Rod length Distance from reflector 1 to reflector 2 Distance from reflector 1 to reflector 3 TPS12_127 Measuring hidden point Step Description Refer to step-by-step chapter Refer to "41.2 Accessing Hidden Point" to access HIDDEN PT Hidden Point Begin.
  • Page 939 Step Description Refer to chapter HIDDEN PT Measure Reflector 1, Hidden Pt page <Aux Pt ID:> The point ID of the auxiliary point, the reflector on the hidden point rod. The Auxiliary Points ID template is used. The horizontal angle, vertical angle, slope distance and height differ- ence to reflector 1, the auxiliary point are displayed.
  • Page 940 Hidden Point TPS1200 Step Description Refer to chapter SHIFT INDIV (F5) for an individual point ID independent of the ID 16.2 template. SHIFT RUN (F5) changes back to the next ID from the configured ID template. ALL (F1) measures reflector 1 and accesses HIDDEN PT Measure Reflector 2.
  • Page 941 Step Description Refer to chapter SHIFT INDIV (F5) for an individual point ID independent of the ID 16.2 template. SHIFT RUN (F5) changes back to the next ID from the configured ID template. PAGE (F6) to change to Code page. HIDDEN PT Hidden Point Result, Code page <Point Code:>...
  • Page 942 Hidden Point TPS1200 Step Description Refer to chapter Position the tip of the hidden point rod on a mark that is directly visible from the instrument location. Repeat steps 4. to 14. from paragraph "Measuring hidden point step- by-step". Make sure the hidden point rod does not move between meas- urements.
  • Page 943 Hidden Point TPS1200...

  • Page 944: Reference Line

    Reference Line TPS1200 Reference Line 42.1 Overview Description The Reference Line application program can be used to set out or measure points relative to a reference line or a reference arc. Tasks The Reference Line application program can be used for the following tasks: •...
  • Page 945 • Local grid Heights and positions are always taken into account. Points must have full coordinate triplets. Properties The properties stored with staked points are: of measured points • Class: MEAS • Sub class: TPS • Source: RefLine (Grid), RefLine (Meas) or RefLine (Stake) •...
  • Page 946 Reference Line TPS1200 Defining A reference line can be defined in the following ways: a reference line/arc • Two known points • One known point, an azimuth, a distance and a gradient • One known point, an azimuth, a distance and a difference in height P0 Instrument station P1 Start point P2 End point...
  • Page 947 P0 Instrument station P1 Start point P2 End point P3 Known point Radius of arc TPS12_175 Defining chainage The chainage of the start point of a reference line/arc can be defined. It is possible to define an arc that has an opening angle of more than 180 Coordinate systems It is possible to use a valid coordinate system but have the line or part of the line lying outside of the projection or CSCS model being used.
  • Page 948 Reference Line TPS1200 Direction of values The following diagram shows the direction of positive and negative values for distance and height differences between the target point and the reference point for reference lines. P0 Instrument station P1 Start point P2 End point P3 Target point TPS12_176 P4 Reference point...

  • Page 949: Accessing Reference Line

    42.2 Accessing Reference Line Access Select Main Menu: Programs...\Reference Line. Press PROG. Highlight Reference Line. CONT (F1). Refer to "35.2 Accessing the Programs Menu" for information on the PROG key. Press a hot key configured to access the screen REFLINE Reference Line/Arc Begin. Refer to "2.1 Hot Keys"...
  • Page 950 Reference Line TPS1200 Description of fields Field Option Description <Control Job:> Choicelist The original points to be staked and the reference lines/arcs are stored in this job. All jobs from Main Menu: Manage...\Jobs can be selected. <Job:> Choicelist The active job. All jobs from Main Menu: Manage...\Jobs can be selected.
  • Page 951 Field Option Description <Config Set:> Choicelist The active configuration set. All configuration sets from Main Menu: Manage...\Configuration Sets can be selected. <Reflector:> Choicelist The active reflector. All reflectors from Main Menu: Manage...\Reflectors can be selected. <Add. Constant:> Output The additive constant stored with the chosen reflector.

  • Page 952: Configuring Reference Line

    Reference Line TPS1200 42.3 Configuring Reference Line Description Allows options to be set which are used within the Reference Line application program. These settings are stored within the configuration set. Access step-by-step Step Description Refer to "42.2 Accessing Reference Line" to access the Begin screen. CONF (F2) to access REFLINE Configuration.
  • Page 953 SHIFT ABOUT (F5) To display information about the application program name, the version number, the date of the version, the copyright and the article number. Description of fields Field Option Description <Orientate:> The reference direction to be used to stakeout points. The stakeout elements and the graphical display shown in the Reference Line application program are based on this selection.
  • Page 954 Reference Line TPS1200 Field Option Description Polar Available for <Orientate: From Station> or <Orien- tate: To Station>. The horizontal distance and angle between the current position and the point to be staked, the height difference as defined in REFLINE Configuration, the height of the point to be staked and the check distances are displayed.
  • Page 955 Field Option Description <Display Mask:> Choicelist The user defined display mask to be shown in REFLINE XX Points. All display masks of the active configuration set defined in CONFIGURE Display Settings can be selected. <Use Chainages:> Yes or No Activates the use of chainages within the reference line application program.
  • Page 956 Reference Line TPS1200 Field Option Description Instrument does not position to the point to be staked out. Next step PAGE (F6) changes to the Checks page. The Checks page Description of fields Field Option Description <Pos Check:> Yes or No Allows a check to be made on the horizontal coordi- nate difference between the staked point and the point to be staked.
  • Page 957 Field Option Description <Beep near Pt:> Yes or No The instrument beeps when the horizontal radial distance from the current position to the point to be staked is equal to or less than defined in <Dist from Pt:>. <Dist from Pt:> User input Available for <Beep near Pt: Yes>.
  • Page 958 Reference Line TPS1200 Field Option Description Use Start Point Heights are computed relative to the height of the starting point. Use DTM The stake out height is computed from the DTM Model being used. Output Available unless this screen was accessed from REFLINE Reference Line/Arc Begin.
  • Page 959 The Logfile page Description of fields Field Option Description <Write Logfile:> Yes or No To generate a logfile when the application program is exited. A logfile is a file to which data from an application program is written to. It is generated using the selected <Format File:>.
  • Page 960 Reference Line TPS1200 Next step CONT (F1) returns to the screen from where this screen was accessed.

  • Page 961: Starting Reference Line

    42.4 Starting Reference Line 42.4.1 Manually Entering a Reference Line/Arc Description • A reference line/arc can be defined by manually entering known parameters. • The line/arc is only temporary and is not stored when the program is quit or closed. Access step-by-step Step Description...
  • Page 962 Reference Line TPS1200 CONT (F1) To accept changes and continue with the subsequent screen. SLOPE (F3) To set a slope from a defined reference line/arc. Cut/Fill values can then be displayed to the slope when measurements are taken along the reference line/arc. OFSET (F4) To set horizontal and vertical offsets, shifts and rotations on the defined reference line or...
  • Page 963 Field Option Description Measure to Calculates the coordinates of a point from it’s posi- Line or tion relative to the reference line/arc. Measure to Stake to Line Allows points to be staked relative to the reference or Stake to Arc line/arc.
  • Page 964 Reference Line TPS1200 Field Option Description <Second Point:> Choicelist Available for <Method: 3 Points>. The second point of the reference arc. All points from REFLINE Data: Job Name can be selected. <End Point:> Choicelist Available for <Method: 2 Points>, <Method: 3 Points>...
  • Page 965 Field Option Description <∆Height:> User input Available for <Method: Pt/Brg/Dst/∆Ht>. The differ- ence in height from the start point to the end point of the reference line. <Radius:> User input Available for <Method: 2 Points/Radius>. The radius of the reference arc. <Arc Dist:>...
  • Page 966 Reference Line TPS1200 THEN <Task: Gridstake CONT (F1) accepts the changes and accesses REFLINE Define XX> Grid. Refer to "42.7 Gridstaking to a Reference Line/Arc".

  • Page 967: Selecting An Existing Reference Line/Arc

    42.4.2 Selecting an Existing Reference Line/Arc Description • Reference lines/arcs can be created, edited, stored and deleted in the <Control Job:>. Access step-by-step Step Description Refer to "42.2 Accessing Reference Line" to access the Begin screen. CONT (F1) to access REFLINE Choose Task & Reference Line. REFLINE Choose Task &...
  • Page 968 Reference Line TPS1200 Field Option Description <Ref Arc:> Choicelist Available for <Task: XX Arc>. The reference arc to be used. Accesses REFLINE Manage Reference Arcs. Next step PAGE (F6) to access REFLINE Choose Task & Reference Line, Map page. The Map page The Map page provides an interactive display of the data.
  • Page 969 THEN • for <Task: Gridstake XX> CONT (F1) to access REFLINE Define Grid. Refer to "42.7 Grid- staking to a Reference Line/Arc". offsets are to be OFSET (F4) to access REFLINE Define Offsets. defined Managing The screen name will be either REFLINE Manage Reference Lines for <Task: XX Line> or reference lines REFLINE Manage Reference Arcs for <Task: XX Arc>.
  • Page 970 Reference Line TPS1200 Description of columns Column Description Name Names of all the reference lines/arcs available in the <Control Job:>. Date Date that the reference line/arc was created. Next step IF a reference THEN line/arc is to be selected highlight the desired reference line/arc. CONT (F1) closes the screen and returns to REFLINE Choose Task &...
  • Page 971 Step Description Refer to chapter CONT (F1) to access REFLINE Choose Task & Reference Line, Reference page. REFLINE Choose Task & Reference Line, Reference page Select <Ref to Use: Select from Job>. Highlight <Ref Line:> or <Ref Arc:> and press ENTER to access REFLINE Manage Reference XX.
  • Page 972 Reference Line TPS1200 Step Description Refer to chapter • For <Task: XX Arc> <Method:> The method by which the reference arc will be defined. <Method: 3 Points> defines the reference arc using three known points. <Method: 2 Points/Radius> defines the reference arc with two known points and a known radius.
  • Page 973 Editing Step Description a reference line/arc Refer to "42.4.2 Selecting an Existing Reference Line/Arc" to access REFLINE step-by-step Manage Reference XX. EDIT (F3) to access REFLINE Edit Reference XX, Input page. All the following steps are identical with the creation of a new reference line/arc except for the following differences.

  • Page 974: Defining The Offsets Related To A Reference Line/Arc

    Reference Line TPS1200 42.4.3 Defining the Offsets related to a Reference Line/Arc Description A reference line can be offset, shifted and rotated, a reference arc can be offset. Access step-by-step Step Description Refer to "42.2 Accessing Reference Line" to access the Begin screen. CONT (F1) to access REFLINE Choose Task &...
  • Page 975 Reference arc offsets P0 Instrument station P1 Start point P2 End point P1a Start point with <Height Offset:> P2a End point with <Height Offset:> P1b Start point with <Offset Arc:> P2b End point with <Offset Arc:> <Height Offset:> <Offset Arc:> TPS12_178 Radius before offset Radius after offset...
  • Page 976 Reference Line TPS1200 CONT (F1) To confirm the selections and to return to the previous screen. SHIFT CONF (F2) To configure the reference line/arc. Refer to "42.3 Configuring Reference Line". Description of fields Field Option Description <Offset Line:> or User input Distance to horizontally offset reference line/arc to <Offset Arc:>...
  • Page 977 Field Option Description <Height Offset:> User input Available for <Heights: Use Start Point> and <Heights: Use Ref Line>. The vertical offset of the reference line/arc. <DTM Offset:> User input Available for <Heights: Use DTM Model>. The vertical offset of the DTM model. <Rotate Line:>...

  • Page 978: Defining The Slope Related To A Reference Line/Arc

    Reference Line TPS1200 42.4.4 Defining the Slope related to a Reference Line/Arc Description • It is possible to measure points and stake points on slopes related to a reference line/arc. A slope can be defined and cut/fill values can then be displayed to the slope when meas- uring along the reference line/arc.
  • Page 979 Step Description Defining a slope type of <Slope Type: Left Down> creates a downward plane extending to the left of the defined reference line/arc. Defining a slope type of <Slope Type: Right Down> creates a downward plane extending to the right of the defined reference line/arc. Defining a slope type of <Slope Type: Left Up>...
  • Page 980 Reference Line TPS1200 Step 3) Step Description defining The slope is always defined as starting from a ’hinge line’. any necessary offsets The hinge line can be horizontally and/or vertically offset from the reference line/arc. The direction of the reference line/arc is always from the starting point. The offsets are always relative to the direction of the reference line/arc.
  • Page 981 Step 4) Step Description measuring the points Press CONT (F1) to close the Define Slope screen. Choose the appropriate Task and choose the relevant reference line/arc. Press CONT (F1) to access the Measure Points screen, move to the Slope page. Reference Line TPS1200...
  • Page 982 Reference Line TPS1200 Description of all fields from the Slope Display Mask Field Description <Chainage:> Displays the current chainage. <Current Slope:> Displays the current slope of the reflector position to the hinge. <Design Slope:> Displays the slope grade as defined by the user. <East:>...
  • Page 983 Field Description <∆Offset:> Displays the perpendicular offset from the line/arc to measured point. <∆Offset Hinge:> Displays the perpendicular offset from the hinge to measured point. Reference Line TPS1200...

  • Page 984: Measuring To A Reference Line/Arc

    Reference Line TPS1200 42.5 Measuring to a Reference Line/Arc 42.5.1 Measuring the Points Description The horizontal and vertical position of a measured point can be calculated relative to the defined reference line/arc. Access Select <Task: Measure to XX> in REFLINE Choose Task & Reference Line, Refer- ence page and press CONT (F1) to access REFLINE Measure Points.
  • Page 985 Measure to line - vertical measurements P0 Instrument station P1 Start point P2 End point P3 Measured point P4 Temporary point P5 Reference point ∆ < Ht-Line:> ∆ < Perp Dist:> ∆ < Spat Dist:> ∆ < Ht-Start:> TPS12_180 Measure to arc - hori- Target point inside arc zontal measurements P0 Instrument station...
  • Page 986 Reference Line TPS1200 Target point outside arc P0 Instrument station P1 Start point P2 End point P3 Measured point P4 Reference point ∆ < Offset:> ∆ < Arc:> ∆ < Arc-End:> <Check Dist 1:> TPS12_182 <Check Dist 2:>...
  • Page 987 Measure to arc - vertical measurements P0 Instrument station P1 Start point P2 End point P3 Measured point P4 Reference point <∆Ht-Start:> <∆Ht-Arc:> TPS12_187 The Ref Line page The pages shown are those from a typical configuration set. An additional page is available when a user defined display mask is used.
  • Page 988 Reference Line TPS1200 ALL (F1) To measure and record the current position. The point ID is incremented according to the configured point ID template. DIST (F2) To measure and display distances. The differ- ence between the current position and the point being staked is displayed.
  • Page 989 SHIFT 2FACE (F4) To take a measurement in Face I and Face II. The point stored is an average of the two measurements. When using instruments fitted with ATR, the point is automatically measured in both faces, the resulting point is stored and the instrument is returned to the first face.
  • Page 990 Reference Line TPS1200 Field Option Description <Reflector Ht:> User input The last used reflector height is suggested when accessing REFLINE Measure Points, Ref XX page. An individual reflector height can by typed in. <Chainage> Output Chainage of the current position along the line/arc. This is the chainage of the start of the reference line/arc plus <∆Line:>/<∆Arc:>.
  • Page 991 For <Task: Measure to Line> Description of fields Field Option Description <∆Line:> Output Horizontal distance along the reference line from the start point to the reference point. <∆Line-End:> Output Horizontal distance along the reference line from the end point to the reference point. For <Task: Measure to Arc>...
  • Page 992 Reference Line TPS1200 For <Task: Measure to Line>, <Heights: Use Ref Line> and <Edit Height: No> Description of fields Field Option Description <∆Ht-Line:> Output Height difference between the reference point on the line and the measured point. <Height:> Output Height of measured point. <∆Perp Dist:>...
  • Page 993 For <Task: Measure to XX>, <Heights: Use DTM Model> and <Edit Height: No> Description of fields Field Option Description <∆Ht-DTM:> Output Height difference between the measured point and the DTM. <Height:> Output Height of measured point. For <Task: Measure to XX>, <Heights: XX> and <Edit Height: Yes> Description of fields Field Option...
  • Page 994 Reference Line TPS1200 • the perpendicular offset from the reference line/arc measured from the reference point to the measured point. Refer to "34 MapView Interactive Display Feature" for information on the functionality and softkeys available. Next step PAGE (F6) changes to the first page on this screen.

  • Page 995: Working Example

    42.5.2 Working Example Description Application: The positions of stakes, indicating the corners of a house that is to be built, need to be measured relative to the title boundary of the property that the house is to be built on. This is done to check that the house is not being built too close to the title boundary in keeping with council regulations.
  • Page 996 Reference Line TPS1200 Step Description Refer to chapter Refer to "42.2 Accessing Reference Line" to access REFLINE Refer- ence Line/Arc Begin. REFLINE Reference Line/Arc Begin 42.2 Select a job and a configuration set with the settings mentioned above. CONT (F1) to access REFLINE Choose Task & Reference Line, Reference page.
  • Page 997 Step Description Refer to chapter <Point ID: S1> ALL (F1) measures and stores the point. The results are displayed on the screen. The values in the fields indi- cate the position of the measured point relative to the reference line. It may happen that a point with the same point ID exists in the job.

  • Page 998: Staking To A Reference Line/Arc

    Reference Line TPS1200 42.6 Staking to a Reference Line/Arc 42.6.1 Staking the Points Description Allows for the position of a point to be defined relative to a reference line/arc and then staked. Access Select <Task: Stake to XX> in REFLINE Choose Task & Reference Line, Reference page and press CONT (F1) to access REFLINE Enter Offset Values.
  • Page 999 Stake to line - vertical measurements P0 Instrument station P1 Start point P2 End point P3 Target point P4 Reference point <Height Offset:> for <Heights: Use Start Point> <Height Offset:> for <Heights: Use Ref Line> TPS12_185 Stake to arc - horizontal measurements P0 Instrument station P1 Start point...
  • Page 1000 Reference Line TPS1200 1000 Stake to arc - vertical measurements P0 Instrument station P1 Start point P2 End point P3 Target point P4 Reference point <Height Offset:> for <Heights: Use TPS12_187 Start Point> Entering offset values This screen is for typing in the stakeout values for a point relative to the reference line/arc. The screen contains different fields depending on the options chosen for <Heights:>...
