F5.18 Analog output（AO）gain
F5.19 Analog output（AO）offset
For AO analog output, the user can modify display measuring range or emend
meter head error by adjusting output gain if necessary.
F5.20 Reserved
F5.21 Reserved
F5.22 Reserved
F5.23 DO terminal output function selection
Same as F5.17 function parameter description.
F5.24 DO max. pulse output freq.
DO port max. output pulse frequency corresponds to maximum value optioned
by F5.23，for example 0: output frequency，then max. Output pulse frequency
corresponds to high limit frequency.
F5.25 Set interior count number arriving provision
F5.26 Specified interior count number arriving provision
F5.25, F5.26 is supplementary definition to No. 17, 18 function in Table 6-8.
Set count number provision，shows that when some number of pulse are
inputted to Xi(count triggering signal input function terminal), OC (open collector
Output terminal) output a indicator signal.
As shown in Fig.6-36，OC output an indicator signal when the 8th pulse is
inputted to Xi. Here F5.25=8.
Specified count number provision，shows that when some number of pulse are
inputted to Xi, Yi output a indicator signal，till set count number is reached.
As shown in Fig.6-36，TA, TB, TC start to output an indicator signal when the
5th pulse is inputted to Xi. Until set count number 8 is reached. Here F5.26=5.
Specified count number is ineffective when it is bigger than set count number.
EDS800 series Service Manual
Rang：0.00－2.00
Rang：0.00－10.00V
Range： 0.1－20.0（max. 20KHz）
92
Range：0~9
Range：0－9999
Range：0－9999
1.00
0.00
0
10.0
0
0
