6.6 Terminal correlative function parameter group: F5

F5.00 Input terminal X1 function selection
F5.01 Input terminal X2 function selection
F5.02 Input terminal X3 function selection
F5.03 Input terminal X4 function selection
F5.04 Input terminal X5 function selection
F5.05 Reserved
F5.06 Reserved
F5.07 Reserved
Multi-function input terminal X1~X5 provides 43 kinds of selection mode for
the user，can choose based on spot requirement. For parameter function table please
see Table 6-3.
Table 6-3 multifunction input function selection table
item corresponding function
0 Leave control terminal unused
2 Multi-step speed control terminal 2
4 Multi-step speed control terminal 4
6 External reverse run jog control
8 Accel/Decel time selecting terminal 2
10 External device failure input
12 Free stop input
14 stop DC braking input command DB
16 Frequency increasing command( UP)
18 Accel/Decel prohibited command
20 Closed-loop ineffective
22 Simple PLC pause command
24 Frequency provision channel selection 1
26 Frequency provision channel selection 3
28 Command switched to terminal
EDS800 series Service Manual
item
1
3
5
7
9
11 External restoration input
13 External stop command
15 Inverter run prohibition
17 frequency descending command( DOWN)
19 Three-wire run control
21 PLC ineffective
23
25 Frequency provision channel selection 2
27 Frequency switched to CCI
29 Run command channel selection 1
81
Range：0~42
Range：0~42
Range：0~42
Range：0~42
Range：0~42
corresponding function
Multi-step speed control terminal 1
Multi-step speed control terminal 3
External forward run jog control
Accel/Decel time selecting terminal 1
Accel/Decel time selecting terminal 3
PLC stop status restoration (reset variable of PLC
interruption moment, make it restart from first
0
0
0
0
0
