This function code defines varying rate of the set frequency when it's modified
by UP/DOWN terminal.
F5.10 Open collector output terminal OC output setting
F5.11 Reserved
F5.12 Reserved
F5.13 Reserved
OC open collector output terminal， Table 6-8 shows option of above 4 function
parameter，choosing same output terminal function repeatedly is allowed.
Table 6-8 output terminal function selection table
item corresponding function
0 Inverter running signal (RUN)
2 Frequency level detectingsignal (FDT1)
4 Overload warning signal( OL)
6 Output Freq. reach low limit( FLL)
8 Stop for exterior failure( EXT)
10 In PLC run process
12 PLC finish one cycle run
14 Inverter is ready for run( RDY)
16 traverse high&low limit restriction
18 Interior counter specified value arrive
20 Interior timer timing arrive
22 FWD running
24 reserved
Now introduce function listed in Table 6-8 as follows:
0: inverter during running( RUN). The inverter is in run status，output
indicator signal.
1: frequency arriving signal( FAR). Refer to function description of F5.14.
2: Frequency level detecting signal( FDT1). Refer to function description of
F5.15~F5.16.
3: reserved
4: overload warning signal( OL). Inverter output current exceed F9.05
overload detect level and time exceed F9.06 overload detect time，output
indicator signal.
EDS800 series Service Manual
item
1
3
5
7
9
11
13
15
17
19
21
23
89
Range： 0~24
corresponding function
Frequency arriving signal (FAR)
reserved
Output Freq. reach high limit( FHL)
Inverter stops for under voltage blockage (LU)
Inverter zero speed running
Simple PLC segment run finished
reserved
Inverter failure
Interior counter final value arrive
Set runtime arrive
reserved
REV running
0
