Output frequency
Common set freq.
multisection speed control terminal 1
multisection speed control terminal 2
multisection speed control terminal 3
multisection speed control terminal 4
In Fig.6-27 see an example of terminal run command channel，can make forward,
reverse run control by K5, K6. In Fig.6-26, by different logic combination of K1, K2,
K3, K4，the inverter can run according to common set frequency or multi-step
frequency based on above table.
3 phase breaker
L1
power
L2
supply
L3
K1
K2
K3
K4
COM
Fig.6-27 multi-step speed run
5~6: external jog run control input JOGF/JOGR.When run command
channel is set to terminal run command channel F0.02=1，JOGF is jog forward
run， JOGR is jog reverse run， jog operation frequency, jog accelerating decelerating
time is defined in F2.06~F2.08 (remark: jog run command channel is determined by
F0.02)
7~9: Accel&Decel time terminal selection
EDS800 series Service Manual
Run command
on
on
on
on
EDS800
U
V
W
FWD
REV
COM
speed 2
speed 1
Fig.6-26 multi-step speed run
M
K5
K6
Fig.6-28 exterior device failure always-open input
83
speed 11
speed 7
speed 6
KM
EDS800
X5
COM
speed 9
speed 15
time
K1
K2
K3
K4
K5
