Running speed stable state
precision
Frequency precision
Analog setting 0.1% of max. frequency-+96
Frequency
Digital setting 0.01Hz
resolution
Exterior pulse 0.5% of max. frequency
Torque boost
V/F curve (volt. frequency
characteristic)
Accelerating decelerating
curve
Powerconsumption
brake
brake
DC brake
Jog
Multisection speed running Realized by interior PLC or control terminal
Interior PID controller
Automatic energy save
running
Automatic volt. regulation
(AVR)
Automatic current limiting
Running order specified
channel
Running frequency
specified channel
pulse output channel
Analog output channel
LED display
Lock the button
EDS800 series Service Manual
≤±0.5% of rating synchronous speed
Digital setting: max. frequency×±0.01%; analog setting:
max.frequency×±0.5%
Automatic torque boost，manual torque boost 0.1%~20.0%
Set rating frequency randomly at range of 5~400Hz，can choose constant
torque, degressive torque 1, degressive torque 2, degressive torque 3 in total
4 kinds of curve
2 modes: straight line accelerating decelerating and S curve accelerating
decelerating; 7 kinds of accelerating decelerating time (unit
minute/second can be optioned), max. time 6000 minutes.
exterior brake resistance
Optional start-up and stop，action frequency 0~15Hz，action volt. 0~15%，
action time 0~20.0 s
Jog frequency range: 0.50Hz~50.00Hz; jog accelerating decelerating time
0.1~60.0s can be set
Be convenient to make closed-loop system
Optimize V/F curve automatically based on the load to realize power save
running
Can keep constant output volt. When power source voltage varies.
Limit running current automatically to avoid frequent over-current which
will cause trip
Key pad specified, control terminal specified, serial port specified
Digital provision, analog provision, impulse provision, serial port provision,
combined provision，can be switched at any time by kinds of method
Impulse square wave signal output of 0~20KHz，can realize output of
physical parameter such as setting frequency, output frequency etc.
1 channel of analog signal output，AO channel can be 4~20mA or 0~10V;
through it the inverter can realize output of physical parameter such as
setting frequency, output frequency etc.
Can display setting frequency, output frequency, output voltage, output
current etc. in total 14 kinds of parameter
Lock all or part of the buttons(analog potentiometer can't be locked)
