F4.03
Step 2 setting
F4.04
Step 2 runtime
F4.05
Step 3 setting
F4.06
Step 3 runtime
F4.07
Step 4 setting
F4.08 Step 4 runtime
F4.09
Step 5 setting
F4.10
Step 5 runtime
F4.11
Step 6 setting
F4.12
Step 6 runtime
F4.13
Step 7 setting
F4.14
Step 7 runtime
F4.01~F4.14 utilize LED 1
setting，direction and accelerating decelerating time of PLC Run, see following for
detail:
st
LED1 bit: frequency setting
0: multi-step frequency i i=1~7 is defined by F2.30~F2.44.
1: frequency is determined by function code F0.00
nd
LED 2 bit: run direction selection
0: forward run
1: reverse run
2: determined by run command (FWD,REV)
rd
LED3 bit: accelerating decelerating time selection
0: accelerating decelerating time 1
1: accelerating decelerating time 2
2: accelerating decelerating time 3
3: accelerating decelerating time 4
4: accelerating decelerating time 5
5: accelerating decelerating time 6
6: accelerating decelerating time 7
EDS800 series Service Manual
Range：000－621
Range：0－6000.0
Range：000－621
Range：0－6000.0
Range：000－621
Range：0－6000.0
Range：000－621
Range：0－6000.0
Range：000－621
Range：0－6000.0
Range：000－621
Range：0－6000.0
st nd
bit, 2 bit, 3
80
rd
bit to separately define frequency
000
10.0
000
10.0
000
10.0
000
10.0
000
10.0
000
10.0
