FWD/REV run mode
F5.08
selection
UP/DOWN velocity
F5.09
Open circuit collector
F5.10
output terminal OC
output setting
F5.11 reserved
F5.12 reserved
F5.13 reserved
Frequency arriving
F5.14
(FAR) checkout scope
FDT1 (frequency
F5.15
level) electric level
FDT1 lag
F5.16
Analog output (AO1)
F5.17
selection
Analog output (AO) gain
F5.18
EDS800 series Service Manual
0: double-line control mode 1
1: double-line control mode 2
2: three-line control mode 1
3: three-line control mode 2
0.01－99.99Hz/s
0: inverter running（RUN）
1: frequency arriving signal（FAR）
2: frequency level detect signal (FDT1)
3: reserved
4: overload warning alarm signal (OL)
5: output frequency reach high limit（FHL）
6: output frequency reach low limit（FLL）
7: inverter under voltage blockage stop (LU)
8: external failure stop-runnin（EXT）
9: inverter zero rotate speed running
10: PLC running
11: simple PLC section running finished
12: PLC finish a cycle running
13: reserved
14: inverter ready to run (RDY)
15: inverter failure
16: traverse high and low limit restriction
17: interior counter reach final value
18: interior counter reach specified value
19: set run time arriving
20: interior timing arriving
21: reserved
22:FWD running
23: REV running
24: reserved
0.00－50.00Hz
0.00－high limit frequency
0.00－50.00Hz
0: output frequency(0－high limit frequency)
1: set frequency(0－high limit frequency)
2: output current(0－2×rated current)
3: output voltage(0－1.2×load motor rated
voltage)
4: bus-bar voltage(0－800V)
5: PID provision (0.00-10.00V)
6: PID feedback (0.00-10.00V)
7: reserved
8: reserved
9: reserved
0.00－2.00
45
1 0
0.01Hz/s 1.00Hz/s
1 0
0.01Hz 5.00Hz
0.01Hz 10.00Hz
0.01Hz 1.00Hz
1 0
0.01 1.00
×
○
×
○
○
○
○
○
