SHENZHEN ENCOM ELECTRIC TECHNOLOGIES CO. EN500 Series Service Manual

Table of Contents

Quick Links

Print version: V2.0-A2

Foreword

Thank you for purchasing EN500/EN600 series inverter developed and produced

by Shenzhen Encom Electric Technologies CO., LTD.

EN500/EN600 series hi-performance flux vector inverter adopt advanced control

mode to achieve high torque, high precision and wide-range speed regulation

drive, and it also support speed sensorless torque control and PG control torque.

It can meet customer all kinds of requirement to universal inverter. EN500/EN600

inverter is a organic combination for customer's universal and industrial control

purpose and provide practical main-auxiliary frequency provision, run channel

frequency binding, PID regulator, simple PLC, spinning traverse, programmable

input&output terminal control, pulse frequency provision and inbuilt Modbus,

Can bus, Profibus, 485 freedom protocol and other function and platform. It

provide high integration solution for most manufacturing and automation

customer and EN500/EN600 inbuilt input phase loss function, output phase loss

function, short circuit to earth grounding function and many other protective

function to improve effectively the system reliability and safety.

This brochure provide the installation and wiring, settings, fault check and

methods, maintenance and other relative issues to customer. To make inverter

assemble and operate rightly, and use its high performance to best, please read this

brochure carefully before installation usage and keep them well to the final users

of inverter.

Please contact our office or dealer anywhere at any moment when you have any

doubts or special demands in using these inverters, and you can also contact our

after service center in our Headquarters directly. We will serve you with all our

heart.

We reserve our right to notice you if we change contents of this manual.
