F3.26 Water supply supervision Para. display
0: C-11, C-12 display voltage value of VCI, CCI.
1: C-11, C-12 display PID specified pressure and feedback pressure.
F3.27 Closed-loop adjusting characteristic
0: Forward function. motor speed increases as specified value increases.
1: Reverse function. motor speed decreases as specified value increases.
F3.28 LED initial supervision Para. selection
This parameter defines initial supervision parameter selection during running or
stop. For example F3.28=3, LED displays output voltage initially, please press
SHIFT key if you want to see about other supervision parameter.
0: set frequency:It displays set-frequency when standby and displays output
frequency when running.
1: output frequency:It displays output frequency while running and standby.
2: output current
3: output voltage
4: DC bus bar voltage
5: motor speed
6: heat sink temperature
7: run time
8: accumulative run time
9: input terminal status
10: output terminal status
11: analog input VCI/PID provision
12: analog input CCI/PID feedback
13: analog input YCI
14: exterior pulse input
YCI run-in delay time
F3.29
PID feedback signal loss detection
YCI input delay time: the inverter first run at RS485 set frequency after start-up
and change set frequency to RS485+YCI after delay time passed.
PID feedback signal loss detection: When F3.29=0.0, PID feedback signal loss
detection protection function invalid, when F3.29≠0, feedback signal<12.5% given
value and the constant time＞F3.29, then you can judge the feedback signal loss,
EDS800 series Service Manual
73
Range：0, 1
Range：0, 1
Range：0~14
Range: 0.0－9.999s
Range: 0.0－9.999s
0
0
1
0.0s
0.0s
