4.2.4 Key board display status

EDS800 keypad display status is classified as waiting status parameter display,
function code parameter editing status display, malfunction alarm status display, run status
parameter display in total 4 kinds of status. LED indicator light will all be lit after the
inverter electrified, and digital display LED will display character"-EN-" ，then enter into
set frequency display. As shown in Fig.4-3 a.
(1) waiting parameter display status
The inverter is in waiting status and waiting status supervision parameter is displayed
on keyboard, normally parameter F3.28 decide which status supervision parameter to be
displayed. As shown in Fig.4-3 b，the unit is indicated by rightward unit indicator light.
To press
SHIFT
parameter circularly(display 15 kinds of supervision parameter of C group
acquiescently，whether the last 7 kinds of supervision parameter are displayed is
difined by function code F2.11，F2.12, for detail please see C group status
supervision parameter in function parameter schedule graph of chapter 5).
(2) run parameter display status
The inverter enters into run status when receiving effective run command and
normally parameter F3.28 decide which status supervision parameter to be displayed on
the keypad. As shown in Fig.4-3 c，unit is displayed by rightward unit indicator light.
To press
SHIFT
(defined by function code F2.11 and F2.12). During displaying, can press
switch to initial supervision parameter decided by F3.28, otherwise will display the
last displayed parameter all along.
EDS800 series Service Manual
reverse run indicator light, indicate that the
inverter output reversephase order and the
connected motor rotate in reverse direction
key，it can display different waiting status supervision
key，can display run status supervision parameter circularly
28
ENTER
to
DATA
