F2.30 Multi-step freq. 1
F2.31 Multi-step freq. 2
F2.32 Multi-step freq. 3
F2.33 Multi-step freq. 4
F2.34 Multi-step freq. 5
F2.35 Multi-step freq. 6
F2.36 Multi-step freq. 7
Multi-step freq. 8
F2.37
VF freq. value 0
Multi-step freq. 9
F2.38
VF voltage value 0
Multi-step freq. 10 Range： Lower limit freq.－upper limit freq.
F2.39
VF freq. value 1
Multi-step freq. 11
F2.40
VF voltage value 1
Multi-step freq. 12 Range： Lower limit freq.－upper limit freq.
F2.41
VF freq. value 2
Multi-step freq. 13 Range： Lower limit freq.－upper limit freq.
F2.42
VF voltage value 2
Multi-step freq. 14 Range： Lower limit freq.－upper limit freq.
F2.43
VF freq. value 3
Multi-step freq. 15 Range： Lower limit freq.－upper limit freq.
F2.44
VF voltage value 3
These parameters are compound, two kinds of function can't be used
simultaneously, for details please check below:
When F0.15=4, F2.37~F2.44 are for V/F curve setting, for detailed function
description, please see that for F0.15.
When F0.15≠4, F2.37~F2.44 are used for multi-section frequency. Setting mode
EDS800 series Service Manual
Range： Lower limit freq.－upper limit freq.
Range： Lower limit freq.－upper limit freq.
Range： Lower limit freq.－upper limit freq.
Range： Lower limit freq.－upper limit freq.
Range： Lower limit freq.－upper limit freq.
Range： Lower limit freq.－upper limit freq.
Range： Lower limit freq.－upper limit freq.
Range： Lower limit freq.－upper limit freq.
Range:0.00－F2.39
Range： Lower limit freq.－upper limit freq.
Range:0.00－F2.40
Range:F2.37－F2.41
Range： Lower limit freq.－upper limit freq.
Range:F2.38－F2.42
Range:F2.39－F2.43
Range:F2.40－F2.44
Range:F2.41- high limit freq.
Range:F2.42－100.0%(rated voltage)
66
5.00Hz
10.00Hz
20.00Hz
30.00Hz
40.00Hz
45.00Hz
50.00Hz
5.00Hz
0.50Hz
10.00Hz
2.00%
20.00Hz
20.00Hz
30.00Hz
38.00%
40.00Hz
25.00Hz
45.00Hz
48.00%
50.00Hz
40.00Hz
50.00Hz
80.00%
