F3.14 closed-loop preset frequency
F3.15 closed-loop preset frequencyholding time Range：0.0-6000S
This function can make closed-loop adjusting enter into stable phase quickly.
After closed-loop run starts, the inverter first accelerates to preset frequency F3.14
in terms of accelerating time, and after running at this frequency for a period of time
F3.15, it runs according to closed-loop characteristic. As shown in Fig.6-18.
Set preset freq. and holding time to "0' if closed-loop preset freq. function is not needed.
note
F3.16 Revival frequency
F3.17 Sleep frequency
Revival frequency define frequency limit from sleep status to work status. If set
frequency is bigger than this limit and the situation sustains for a revival delay time,
the inverter will enter into work status from sleep status.
Sleep frequency define frequency limit from work status to sleep status. If set
frequency is smaller than this limit and the situation sustains for a sleep delay time,
the inverter will enter into sleep status from work status.
This function can realize sleep function and make energy save run possible,
avoid the inverter staring at threshold frequency frequently.
F3.18 Sleep delay time
This parameter is to set delay time when entering into sleep function. EDS800
will stop running if the output frequency is lower than sleep frequency and holding
time longer than this sleep delay time.
F3.19 Revival delay time
This parameter is to set delay time when entering into revival function.
F3.20 Reserved
F3.21 Long-distance manometer range
To set 10V or 20mA by this parameter.
F3.22 Reserved
F3.23 Reserved
F3.24 Reserved
F3.25 Reserved
EDS800 series Service Manual
Range：0.00－400.00Hz
Range：0.00－400.00Hz
Range：0.0－6000.0s
Range：0.0－6000.0s
72
Range：0-high limit freq.
Range： 0.001－9.999Mpa
0.00Hz
0.0S
0.00Hz
0.00Hz
0.0s
0.0
1.000
