response frame.
(5) EDS800 provides 485 interface.
1.2.3 Transport mode
Asynchronous serial，semiduplex transport mode. Default format and transport
rate: 8-N-1，9600bps.For specific parameter setting please see description for
F2.14～F2.17 group function code.
(remark ： Below definition is only effective under series port RS485
communication mode, and definition for other parameters are the same as original)
F2.14 Communication
configuration
F2.15 Local address
Communication timeout
F2.16
detection time
F2.17 Local response delay
F2.53 RS485/232
communication
frame format selection
EDS800 series Service Manual
LED first bit：baud rate selection
0：1200BPS
1：2400BPS
2：4800BPS
3：9600BPS
4：19200BPS
5：38400BPS
LED second bit：data format
0：1-8-1 format，no checkout
1：1-8-1 format，even checkout
2：1-8-1 format，odd checkout
0－127，127 is broadcast address
0.0－1000.0s
0－200ms
0: a ASCII frame of 14 byte or 18 byte
1: a hex frame of 8 byte or 10 byte,
original response not changed
2: a hex frame of 8 byte or 10 byte, 12
command has no response
3: a hex frame of 8 byte or 10 byte, 14
command has no response
4: a hex frame of 8 byte or 10 byte,
both 12 and 14
command have no response
124
1 03 ×
1 1 ×
0.1s 0.0s ×
1ms 5ms ×
1 0
×
