Realize frequency increasing or descending by control terminal, which substitute for
keypad to realize long-distance control. Effective during common run if
F0.00=2.Increasing descending speed is set by F5.09.
18 : Accel&Decel speed forbidden command. Let the motor not effected by
any foreign signal(except stop command)，keep running at current frequency.
Ineffective during normal decelerating stop.
note
19 : three-wire run control. Please refer to function description of F5.08
run mode (three-wire run mode).
20 : closed-loop ineffective. Realize flexible switch to lower level run
mode under closed-loop run status.
(1) can switch between closed-loop and lower level run mode only during closed-loop
run(F3.00=1).
(2) start stop control, direction and Accel&Decel time are subject to setting of corresponding
note
run mode when it's switched to lower level run mode.
21 : PLC ineffective. Realize flexible switch to lower level run mode under PLC
run status.
(1) can switch between PLC and lower level run mode only during PLC run(F4.00≠0).
(2) start stop control, direction and Accel&Decel time are subject to setting of
note
corresponding run mode when it's switched to lower level run mode.
22 : simple PLC pause command. Implement pause control to PLC process
during running，run at zero frequency when this terminal is effective，not time for
PLC run .after ineffective implement automatic speed tracking start and continue
PLC run. For application method please refer to function description ofF4.00~F4.14.
23 : PLC stop status restoration. Under stop status of PLC run mode, will
clear PLC run step, runtime, run frequency etc. recorded when PLC run stops if this
terminal is effective，please see F4 group function description.
24~26 : terminal frequency provision channel selection. Through ON/OFF
combination of frequency provision channel selection terminal 24, 25, 26，can
realize frequency provision channel switch shown in Table 6-6. For relation of
terminal switch and function code F0.00 setting, that is, latter effective.
