electrification，
Fig.a
display-EN-
Fig.4-3 inverter electrification, waiting, run status display
(3) Failure alarm display status
The inverter enters into failure alarm display status upon
detecting failure signal and display failure code sparklingly
(as shown in Fig.4-4);
To press
SHIFT
stopping running；Can press
program status to see about Fd group parameter if want to search failure
information.
Can carry on failure restoration by
communication command on the keypad after troubleshooting. Keep displaying
failure code if failure exist continuously.
For some serious failure，such as inverse module protect，over current, over voltage
! etc., must not carry on failure reset forcibly to make the inverter run again without
failure elimination confirmed. Otherwise have danger of damaging the inverter！
(4) function code editing status
Under waiting, run or failure alarm status，press
editing status(If user password is set，can enter into editing status after inputting the
password，see also FF.00 description and Fig.4-10)，and editing status is displayed
according to three classes menu mode，as shown in Fig. 4-5. To press
can enter into one class by one class. Under function parameter display status，to
ENTER
press
DATA
can only come back to upper class menu without stroring modified parameter.
EDS800 series Service Manual
Fig.b
key can look over relative parameter after
ESC
MENU
key to carry on parameter storage operation； To press
waiting status，
display waiting
status parameter
key to enter into
STOP
key, control terminal or
RESET
29
run status, display
Fig.c
run status parameter
over current in
accelerating
Fig.4-4 failure alarm
ESC
key，can enter into
MENU
ENTER
DATA
key
ESC
key
MENU
