5 Function parameter schedule graph

5.1 Symbol description

× ---- parameter can't be changed in process of running
○ ---- parameter can be changed in process of running
* ---- read-only parameter, unmodifiable
5.2 Function parameter schedule graph
function
name
code
F0.00 Frequency input
channel selection
F0.01 Freq. digit setting Lower limit Freq.～upper limit Freq.
F0.02 Run command
channel selection
Run direction
F0.03
setting
Acce/Dece mode
F0.04
selection
S curve start
F0.05
section time
EDS800 series Service Manual
F0 –basic run function parameter group
0: keypad analog potentiometer setting
1: keypad digital setting
2: terminal UP/DOWN adjust setting (stored after
power off)
3: serial port setting
4: VCI analog setting (VCI-GND)
5: CCI analog setting (CCI-GND)
6: reserved
7: terminal pulse (PULSE) setting
8: combination setting
9: terminal UP/DOWN adjust setting
(not stored after power off)
10:provision serial port (stored after power off)
11:terminal PWM pulse setting freq.
0: keypad run control
1: terminal run command control
(keypad stop command ineffective)
2: terminal run command control
(keypad stop command effective)
3: serial port run command control
(keypad stop command ineffective)
4: serial port run command control
(keypad stop command effective)
st
1 bit: 0, forward run; 1, reverse run
nd
2 bit: 0, reverse run allowed
1, reverse run banned
rd
3 bit: REV/JOG key selection
0: as reverse run key
1: as jog key
0: linear accelerating decelerating mode
1: S curve accelerating decelerating mode
10.0（％）－50.0（％） （Acce/Dece time）
F0.05+F0.06≤90（％）
Set range
35
Factory Modificat-
unit
default ion
1 1
0.01Hz 50.00Hz
1 0
1 00
1 0
0.1(％) 20.0(%)
○
○
○
○
×
○
