6.8 Frequency provision function parameter group: F7

F7.00 VCI minimum provision
Corresponding freq. to VCI
F7.01
minimum provision
F7.02 VCI max. provision
Corresponding freq. to VCI
F7.03
maximum provision
F7.04 CCI minimum provision
Corresponding freq. to CCI
F7.05
minimum provision
F7.06 CCI max. provision
Corresponding freq. to CCI
F7.07
max. provision
F7.08 Max. Input pulse width
F7.09 Min. Input pulse width
min. provision
F7.10
corresponding freq.
Max. provision pulse
F7.11
width
max. provision
F7.12
corresponding freq.
When choose F0.00=11(terminal pulse setting freq.).the function of above
parameter effective.
Pulse width in milliseconds ,the freq. of input pulse width can effect the precision
of output freq., to assure the precision of output freq.,customer advised use the freq.
of pulse width between 1Hz to 100Hz.
Please don't use these function for the application where there use close freq
control.
F7.13 PULSE max. pulse input
PULSE minimum
F7.14
provision
Corresponding freq. to
F7.15
PULSE min. provision
EDS800 series Service Manual
Range：0.00－F7.02
Range：0.00－high limit frequency
Range：0.00－10.00V
Range：0.00－high limit
Range：0.00－F7.06
Range：0.00－high limit frequency
Range：0.00－10.00V
Range：0.00－high limit frequency
Range:0.1-999.9ms(whenF0.00=11)
Range:0.0-F7.11(Max.provision
pulse)(whenF0.00=11)
0.00－high limit frequency
Rang:F7.09(Min.provision pulse)
-F7.08(Max.provision pulse)
Range: 0.00－high limit frequency
Range：0.1－20.0K
Range：0.0－F7.16
Range：0.00－high limit frequency
95
frequency
0.0V
0.00Hz
10.0V
50.00Hz
0.00V
0.00Hz
10.00V
50.00Hz
100.0ms
0.0ms
0.00Hz
100.0ms
50.00Hz
10.0K
0.0K
0.00Hz
