Table 6-6 terminal frequency provision channel selection logic mode
frequency
provision channel
selection end 3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
27: switch frequency to CCI. Frequency provision channel is switched to CCI
provision compulsorily when this function terminal is effective, frequency provision
channel come back to previous status when this function terminal is ineffective.
28 : command switched to terminal. Run command channel is switched to
terminal run command channel compulsorily when this function terminal is
effective.
29~31: terminal select run command channel
Run command
channel selection
terminal 3
OFF
OFF
OFF
OFF
ON
ON
Can realize control command selection shown in Table 6-7 by ON/OFF
EDS800 series Service Manual
frequency
provision channel
selection end 2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
Table 6-7 run command channel logic mode
Run command
channel selection
terminal 2
OFF
OFF
ON
ON
OFF
OFF
frequency
provision channel
selection end 1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Run command
channel selection
terminal 1
OFF
ON
OFF
ON
OFF
ON
86
frequency provision channel
selection
hold freq. setting
potentiometer provision
keypad number provision
terminal UP/DOWN adjusting
provision
serial port provision
VCI
CCI
end PULSE provision
Run command channel
hold run command channel
keypad run command channel
end run command channel (keypad
STOP command ineffective)
end run command channel (keypad
STOP command effective)
serial port run command channel
(keypad STOP command ineffective)
serial port run command channel
(keypad STOP command effective)
