Run and operation explanation for inverter

4.1 Run of inverter

4.1.1 Running order channels

There are 3 kinds of order channel for controlling run action of the inverter
such as run, stop, jog etc.:
0: keypad
Control by key
1: control terminal
Use control terminal FWD, REV, COM to make of double-line control，or use one
terminal of X1～X5 and FWD or REV to make of three-line control.
2: serial port
Control run and stop of the inverter through upper machine or other device which
can communicate with the inverter.
Choose order channel by setting function code F0.02；and also can choose by
multi-function input terminal(F5.00~F5.07 choose function 29, 30, 31).
Please make switching debugging in advance when switch the order channel to check if it
can fulfil system requirement，otherwise have danger of damaging device and injuring
!
personal.

4.1.2 Frequency-provision channel

Under EDS800 common run mode there are 9 kinds of provision channel:
0: keypad analog potentiometer provision；
1: direct digital frequency provision；
2: terminal UP/DOWN provision(store after power-off or stop)；
3: serial port provision；
4: analog value VCI provision；
5: analog value CCI provision；
6: reserved；
7: terminal pulse(PULSE) provision；
8: combination set;
9: terminal UP/DOWN provision(not store after power-off or stop)

4.1.3 Work state

Work state of EDS800 is classified as waiting state and running state:
waiting state: If there is no running command after the inverter electrified or
after stop command during running state, the inverter enters into waiting state.
running state: the inverter enters into running state after receiving run
command.
