Table 2-2 EDS800-2S0002N~EDS800-4T0015N mounting size
Inverter type
EDS800-2S0002N
EDS800-2S0004N
EDS800-2S0007N
EDS800-2S0015N
EDS800-4T0007N
EDS800-4T0015N
2.7 Outer size of keypad and its fixing box (unit: mm)
Fig.2-5 outer size of keypad and outline of its fixing box

2.8 Product technic index and spec.

item
Rating volt.,frequency
Input
Allowed work volt. range
Voltage
Frequency
output
Over loading capacity
Control mode
Speed regulation range
Start-up torque
EDS800 series Service Manual
W H D
(mm) (mm) (mm)
89 148.5 112.5 124.7
3 phase 380V, 50Hz/60Hz; single phase 220V, 50Hz/60Hz
3 phase voltage: 320V~460V;
single phase voltage: 200V~260V
380V grade: 0~380V; 220V grade: 0~220V
0Hz-400Hz
150% of rating current for1 minute，200% of rating current for 0.5 second；
Optimum space voltage vector SVPWM constant volt. Frequency ratio V/F
control
1:100
100% of rating torque at low frequency
D1
A
(mm) (mm)
74
Item description
7
Fixing Gross
B
aperture weight
(mm)
(mm)
138 5
(kg)
1
1
1.1
1.2
1.1
1.1
