SHENZHEN ENCOM ELECTRIC TECHNOLOGIES CO. enc eds800-2s0002n User Manual page 42

Function
name
code
Analog filter time
F2.00
constant
Forward reverse run
F2.01
dead-section time
Automatic energy
F2.02
save run
AVR function
F2.03
Slip frequency
F2.04
compensation
Carrier wave
F2.05
freq.
Jog run frequency
F2.06
Jog Acc time
F2.07
Jog Dec time
F2.08
Frequency input
F2.09
channel combination
Principal subordinate
F2.10
EDS800 series Service Manual
F2 –auxiliary run function parameter group
0.00－30.00s
0.0－3600.0s
0: no action
1: action
0: no action
1: action all the time
2: no action only during Dec
0～150(％)0-no slip frequency
compensation
2－15.0K
0.10－50.00Hz
0.1－60.0s
0.1－60.0s
0: VCI＋CCI
1: VCI－CCI
2: reserved
3: reserved
4: reserved
5: reserved
6: exterior pulse provision＋CCI
7: exterior pulse provision－CCI
8: reserved
9: reserved
10: reserved
11: reserved
12: reserved
13: VCI, CCI any nonzero value effective,
VCI preferred
14: reserved
15: RS485+CCI
16: RS485-CCI
17: RS485+VCI
18: RS485-VCI
19: RS485+keypad potentiometer
20: RS485- keypad potentiometer
21: VCI+ keypad potentiometer
22: VCI- keypad potentiometer
23: CCI+ keypad potentiometer
24: CCI- keypad potentiometer
25: VCI*QWG（keypad potentiometer）
26: reserved
27: reserved
28: reserved
0（％）－500（％）
Set range
37
Factory
unit
default
0.01s 0.20s
0.1s 0.1s
1 0
1 0
1 0
depend on
0.1K
machine type
0.01Hz 5.00Hz
0.1s 20.0s
0.1s 20.0s
1 0
1(%) 100(%)
modif-
ication
○
○
×
×
×
×
○
○
○
×
○
