Table 6-5 Accel&Decel time terminal selection logic mode
Terminal 2
OFF
OFF
OFF
OFF
ON
ON
ON
Can realize selection for Accel&Decel time1~7 by ON/OFF combination of
Accel&Decel time terminal.
10 : external equipment fault input. Can input fault signal of external
equipment by this terminal to be convenient for the inverter to monitor fault of
external equipment. The inverter displays "E0.14" , namely external equipment fault
alarm after receiving the external equipment fault signal.
11 : exterior restoration input. After the fault alarm takes place in the
inverter, can restore the inverter through this terminal. Its function is same as
function of
RESET
12 : free stop input. This function is same as free stop during running defined
in F1.05，but it's realized by control terminal to be convenient for long-distance
control.
13 : exterior stop command. This command is effective to all run command
channel，when this function is effective the inverter stops running in mode set by
F1.05.
14 : DC injection braking input command DB during stop. Implement DC
injection braking to the motor during stop by control terminal，in order to realize
urgent parking and accurate orientation of the motor. Braking initial frequency,
braking time are defined in F1.06, F1.07.
15 : inverter run forbiddance. The inverter during running stops freely
when this terminal is effective and forbidden to start in waiting status. Mainly
applied to occasion needing safe linkage.
16~17: frequency increasing command UP/descending command DOWN.
EDS800 series Service Manual
Terminal 2
OFF
OFF
ON
ON
OFF
OFF
ON
key on the operation panel.
Terminal 1
OFF
ON
OFF
ON
OFF
ON
OFF
84
Accel/Decel time selection
Accel time 1/ Decel time 1
Accel time 2/ Decel time 2
Accel time 3/ Decel time 3
Accel time 4/ Decel time 4
Accel time 5/ Decel time 5
Accel time 6/ Decel time 6
Accel time 7/ Decel time 7
