2> When the user see about failure parameter，can press
switch back to failure alarm display status (E0XX)
(7) keypad key-press locking operation
Under unlocked keypad situation， press
detailed operation please refer to 2
(8) keypad key-press unlocking operation
Under locked keypad situation，press

4.3 Inverter electrification

4.3.1 Check before electrification

Please carry on wiring based on operation requirement provided in "inverter
wiring" of this Service manual.

4.3.2 First electrification

Close input side AC power supply switch after correct wiring and power supply
confirmed, electrify the inverter and keypad LED display "-EN -", contactor closed
normally, LED displayed set frequency shows that electrification is finished. First
electrification operation process is shown as Fig. 4-12.
EDS800 series Service Manual
MENU
nd
bit of F2.13 function code.
ESC
MENU
33
ENTER
ESC
key for 5s to lock the keypad. For
key for 5s to unlock the keypad.
key directly to
DATA
