SHENZHEN ENCOM ELECTRIC TECHNOLOGIES CO. enc eds800-2s0002n User Manual page 124

10.5.2 control command and status word communication address
Variable Name
run command
word
Serial port
frequency provision
Inverter status
Alarm code
10.5.3 Monitor parameter communication address
Monitor
parameter
C-00
C-01
C-02
C-03
C-04
C-05
C-06
C-07
C-08
C-09
C-10
C-11
C-12
C-13
C-14
EDS800 series Service Manual
Communication
address
2000H
2001H
2100H
2180H
Name
Set frequency
Output frequency
Output current
Output voltage
DC bus-bar vlotage
Load motor speed
module temperature.
Power on running time
Accumulative running time
Input terminal status
Output terminal status
Analog input VCI value
Analog input CCI value
reserved
External impulse frequency
Reading-writing
attribute
1: inching run
2: inching stop
3: forward inching run
4: reversal inching run
5: run
Writing only
6: stop
7: forward run
8: reversal run
9: fault reset
10: emergency stop
Reading and
Lower frequency ~ upper frequency
writing
1: forwarder running
2: reversal running
Reading only
3: stop
4: alarm status
0: without alarm
Reading only
1~23:mean E001~E023 alarm
Communication address (Reading only)
119
Command data or response value
meaning
1000H
1001H
1002H
1003H
1004H
1005H
1006H
1007H
1008H
1009H
100AH
100BH
100CH
100EH
