SHENZHEN ENCOM ELECTRIC TECHNOLOGIES CO. enc eds800-2s0002n User Manual page 47

YCI run-in delay time
F3.29
PID feedback signal loss
detection
Failure relay TA, TB, TC
F3.30
function selection
Reserved
F3.31
Function
name
code
Simple PLC
F4.00
running setting
EDS800 series Service Manual
12: analog input CCI/PID feedback
13: analog input YCI
14: exterior pulse inputs
0.0－9.999s
0.0－9.999s
0: inverter running（RUN）
1: frequency arriving signal（FAR）
2: frequency level detect signal (FDT1)
3: reserved
4: overload warning alarm signal (OL)
5: output frequency reach high limit（FHL）
6: output frequency reach low limit（FLL）
7: inverter under voltage blockage stop (LU)
8: external failure stop-running（EXT）
9: inverter zero speed running
10: PLC running
11: simple PLC section running finished
12: PLC finish a cycle running
13: reserved
14: inverter ready to run (RDY)
15: inverter failure
16: traverse high and low limit restriction
17: interior counter reach final value
18: interior counter reach specified value
19: set run time arriving
20: interior timing arriving
21: reserved
22:FWD running
23: REV running
24: reserved
F4 –simple PLC function parameter group
LED first bit:
0: no action
1: stop after single circulation
2: keep final value after single circulation
3: consecutive circulation
LED second bit:
0: start again from first section
1: continue to run at mid-section frequency
LED third bit: PLC run time unit
0: second
1: minute
th
LED 4 bit: PLC running state power off treatment
method
0：power off no memory
Set range
42
○
0.1s 0.0s
○
0.1s 0.0s
○
15
Factory modif-
unit
default ication
×
1 0000
