6.
Pull the PCIe card carrier handle down to disengage the carrier from the card
cage.
7.
Remove the PCIe card carrier from the server.
Related Information
"Determine Which PCIe Card Is Faulty" on page 157
"Remove a PCIe Card" on page 161
"Remove a PCIe Carrier Extension" on page 165
"Install a PCIe Carrier Extension" on page 167
"Install a PCIe Card Carrier" on page 168

Remove a PCIe Card

This procedure requires that you handle components that are sensitive to electrostatic
Caution -
discharge. This discharge can cause failure of server components.
Ensure that you have already taken antistatic measures.
1.
See
"Prevent ESD Damage" on page
54.
Remove a PCIe Card
Servicing PCIe Cards
161
