Related Information
"Determine Which DIMM Is Faulty (DIMM Fault Remind Button)" on page 75
■
"DIMM Configuration Errors" on page 84
■
Determine Which DIMM Is Faulty (DIMM Fault Remind
Button)
DIMMs are cold-service components that can be replaced by customers. For the location of the
DIMMs, see
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. This discharge can cause failure of server components.
1. Consider your first steps:
Familiarize yourself with DIMM configuration rules.
■
See "DIMM Population Rules" on page 69
Prepare the system for service.
■
See "Preparing for Service" on page
Remove the processor module containing the faulty DIMM. Place the processor module on
■
an ESD-protect work surface. Remove the processor module cover.
See "Remove a Processor Module or Processor Filler Module" on page
"Processor Module Components" on page

Determine Which DIMM Is Faulty (DIMM Fault Remind Button)

18.
45.
61.
Servicing DIMMs 75
