Install the Main Module

Press the green button near the front edge of the cover and slide the cover back and up off the
main module.
10. Determine your next step.
■ If you are replacing a main module due to a faulty motherboard, remove all
of the internal components, and transfer them to the new main module.
If you are replacing a component inside the main module, use one of the
■
following links:
■
■
■
■
■
Related Information
"Main Module Components" on page 19
■
"Main Module LEDs" on page 98
■
"Install the Main Module" on page 102
■
Install the Main Module
1. Place the cover back onto the main module and slide the cover forward until the
latch clicks into place.
2. Open the levers so that they are fully open.
102 SPARC T5-4 Server Service Manual • July 2016
"Servicing the Service Processor Card" on page 115
"Servicing the System Battery" on page 125
"Servicing the System Configuration PROM" on page 121
"Servicing the Front I/O Assembly" on page 131
"Servicing the Storage Backplanes" on page 107
