Chassis Subassembly Components

No. Description
1 Hard drives (8)
2 Front I/O assembly
3 Main module
4 System controls and indicators
5 Processor modules (2)
6 System chassis
7 Rear chassis subassembly (RCSA)
8 Fan modules (5)
9 PCIe carriers (16)
10 Rear I/O module
11 Power supplies (2)
Related Information
"Rear Panel Components" on page 15
■
Links
"Servicing Hard Drives" on page 87
"Servicing the Front I/O Assembly" on page 131
"Servicing the Main Module" on page 97
"Front Panel Controls and LEDs" on page 29
"Servicing Processor Modules" on page 57
"Servicing the Rear Chassis Subassembly" on page 183
"Servicing Fan Modules" on page 145
"Servicing PCIe Cards" on page 151
"Servicing the Rear I/O Module" on page 173
"Servicing Power Supplies" on page 135
