Server Upgrade Process
Processor modules are cold-service components that can be replaced only by qualified
service personnel. For the location of the processor modules, see
Components" on page
Caution -
electrostatic discharge. This discharge can cause failure of server components.
This table contains the steps for upgrading the server to a fully-populated configuration. You
can also view an animated demonstration of the upgrade process at:
http://download.oracle.com/SPARC/T5-4-Server/SPARC_T5-4-Server-Upgrade.mp4
or:
http://download.oracle.com/SPARC/T5-4-Server/T5-4_Demo.html
Step Description
1 Remove the upgrade components from their packaging, and
place them on an antistatic mat.
2 Remove the covers from the new processor module.
3 Remove all of the DIMM filler panels in the processor
module. The steps to remove the DIMM filler panels are the
same as the steps for removing DIMMs.
4 Verify that you have the correct DIMMs for your server. All of
the DIMMs must be either 16 or 32 GB, and they must match
the size and capacity of the DIMMs already installed in the
server.
5 Install the DIMMs.
6 Check the server for faults. If any fault is present, you must
correct the fault and clear it from the server before you can
continue with the upgrade.
7 Shut down the server.
8 Remove the processor filler module from Slot 1.
9 Install the new processor module in Slot 1.
10 Return the server to operation.
11 Verify the installation. If any fault is present, you must correct
the fault and clear it from the server.
12 Review the root complex changes.
13 Review the PCIe card load balancing changes. Even though
the load balancing guidelines change with the u;pgrade, you
do not need to move any existing PCIe cards.
58 SPARC T5-4 Server Service Manual • July 2016
14.
These service procedures require that you handle components that are sensitive to
"Front Panel
Link
"Remove a Processor Module or Processor Filler
Module" on page 61
"Remove a DIMM or DIMM Filler Panel" on page 77
"DIMM Population Rules" on page 69
"Install a DIMM" on page 79
"Check for Faults" on page 38
"Removing Power From the Server" on page 51
"Remove a Processor Module or Processor Filler
Module" on page 61
"Install a Processor Module or Processor Filler
Module" on page 64
"Returning the Server to Operation" on page 191
"Verify the Processor Module" on page 67
"PCIe Root Complex Connections (Dual-Processor
Configurations)" on page 153
"PCIe Card Installation Order" on page 155
