Servicing Fan Modules

The server continues to operate at full capacity if one fan module is not operational. If the
server is operating with four fan modules installed and one or more of those four fan modules
fails, the server will power down to keep from overheating. You can perform a hot-service on a
fan module only when four or five fan modules are operational.
These topics describe service procedures for the fan modules in the server.
"Fan Module Locations" on page 145
■
"Determine Which Fan Module Is Faulty" on page 146
■
"Remove a Fan Module" on page 147
■
"Install a Fan Module" on page 149
■
"Verify a Fan Module" on page 150
■

Fan Module Locations

Part
1
Description
Fan module 0
Servicing Fan Modules 145
