No. LED
Related Information
"Determine if the Main Module Is Faulty" on page 99
■
"Remove the Main Module" on page 99
■
"Install the Main Module" on page 102
■

Determine if the Main Module Is Faulty

Check the Service Required LED on the main module.
The Service Required LED is lit when the server detects a main module fault.
Related Information
"Main Module LEDs" on page 98
■
"Remove the Main Module" on page 99
■
"Install the Main Module" on page 102
■

Remove the Main Module

(Optional) If you are replacing a faulty main module, you must back up ILOM
1.
configuration settings.
a. Configure the SER MGT port to enable the configuration parameters to be
uploaded.
Refer to the ILOM documentation for network configuration instructions.
Back up the ILOM configuration parameters.
b.
See
Shut down the server.
2.
See "Removing Power From the Server" on page
Disconnect the power cords.
3.
See "Disconnect Power Cords" on page
Locate the main module in the server.
4.
Icon
Oracle ILOM documentation.
Description
■ Steady on, amber – A SP error has occurred and service is required.
51.
53.
Determine if the Main Module Is Faulty
Servicing the Main Module 99
