Verify a Fan Module

Verify a Fan Module
1. Ensure that you have completed the following:
Applied power to the server.
■
See
Powered on the server.
■
See
2. Check the front or rear panel LEDs for the following:
Green System OK LED – lit
■
Amber System Fault LED – not lit
■
Amber System Fan Fault LED – not lit
■
See "Front Panel Controls and LEDs" on page 29
LEDs" on page
If these conditions are met, continue to
If these conditions are not met, perform the actions described in
Process" on page
3. Log in to Oracle ILOM.
See "Log In to Oracle ILOM (Service)" on page
4.
Start the faultmgmt shell.
-> start SP/faultmgmt/shell
Are you sure you want to start the faultmgmt shell (y/n)?
faultmgmtsp>
5.
Use the fmadm faulty command to check for faults.
If faults are reported, see
■
If no faults are reported, then the fan module has been replaced successfully.
■
Related Information
"Determine Which Fan Module Is Faulty" on page 146
■
"Remove a Fan Module" on page 147
■
"Install a Fan Module" on page 149
■
150 SPARC T5-4 Server Service Manual • July 2016
"Connect Power Cords" on page
"Power On the Server (Oracle ILOM)" on page
31.
23.
"Diagnostics Process" on page
191.
192.
and "Rear Panel Controls and
Step 5.
26.
y
23.
"Diagnostics
