Power Supply and AC Power Connectors
1
2
Power cords are accessed from the rear of the server.
1
2
Related Information
"Power Supply and AC Power Connector LEDs" on page 137
■
"Determine Which Power Supply Is Faulty" on page 138
■
"Remove a Power Supply" on page 138
■
136
SPARC T5-4 Server Service Manual • July 2016
Power Supply 0 (PS0)
Power Supply 1 (PS1)
Connector for Power Supply 1 (PS1)
Connector for Power Supply 0 (PS0)
