Programming Example - Siemens SINUMERIK 840D sl Programming Manual

Miscellaneous functions
7.2 Measuring cycle support in the program editor
7.2.1.4

Programming example

;Measuring a hole parallel to the axis
; with protection zone
;(generated with measuring cycle support)
N100 G17 G0 G90 Z20 F2000 S500 M3
N110 T=7 M6
N120 X50 Y50
N130 Z20
;
;The following is the NC code generated by the measuring cycle support
N130 _MVAR=1001 _SETVAL=100.000 _PRNUM=101
_KNUM=2002 _FA=2 _TSA=0.23
_VMS=0 _NMSP=1 _ID=-20.000 _SZA=50.000
_CORA=0.03 _TZL=0.01 _TDIF=0.2 _TUL=0.065
_TLL=-0.065 _CHBIT[4]=0 _K=1 _EVNUM=2
-TNUM=1 CYCLE977
;end of NC code generated by measuring cycle support
...
N200 M30
368
;Insert probe
;Position probe in X/Y
plane;on hole center
point;position
;Position Z axis in hole;
Position at measuring height
;Call measuring cycle
;End of program
Programming Manual, 03/2009 Edition, 6FC5398-4BP10-2BA0
Measuring cycles
